Appendix E: Technical Specification
E Technical Specification
E.1

Front View

E.1.1 Front View, PROFIBUS Connector
# Item
1 Operation Mode
2 Status
3 PROFIBUS Connector, 9-pin
female D-Sub
E.1.2 Front View, M12 Connectors
# Item
1 Network Status LED
2 Module Status LED
3 M12 Female Connector
4 M12 Male Connector
E.1.3 Operation Mode
LED State
Off
Green
Flashing Green
Flashing Red (1
flash)
Flashing Red (2
flashes)
E.1.4 Status
LED State
Off
Green
Flashing Green
Red
®
Anybus CompactCom ™ 40 PROFIBUS DP-V0/DP-V1 Network Guide
1
1
Indication
Not online / No power
Online, data exchange
Online, clear
Parameterization error
PROFIBUS Configuration
error
Indication
Not initialized
Initialized
Initialized, diagnostic event
(s) present
Exception error
5 1
3
9 6
3 4
Comments
-
-
-
See Parameterization Data Handling, p. 14
See Configuration Data Handling, p. 15
Comments
Anybus state = SETUP or NW_INIT
Anybus module has left the NW_INIT state
Extended diagnostic bit is set
Anybus state = EXCEPTION
57 (72)
2
2
HMSI-27-210-EN 2.3
