1. HARDWARE REVIEW

Top View

5V power connector

Mini Type-B USB port connec-

Mini Type-B USB port connector

RJ45 Ethernet port

2. HARDWARE INSTALLATION – HOW TO ASSEMBLE

1. Attach the antenna(s) to the evaluation board.

2. Connect the unit to the network via the supplied Ethernet

cable(RJ45) using the Ethernet port.

3. Supply power to the device by using the included power

adapter.

4. Easily connect to the PremierWave 2050 via a mobile device or a

computer with Wi-Fi capability as outlined below..

www.lantronix.com/product-registration.

PremierWave 2050

Evaluation Kit

tor for power

External RP-SMA

RJ-45 Ethernet

antennas

Straight Cat5 Cable

5V Power Supply

With Regional

Adapters

Serial Ports

Status LEDs
