Installation Manual
For your safety and comfort, read this manual carefully.
FT-VF-HND3
Scan this QR code to see which
vehicles are compatible.
Installation chart
Plug in to the original whip
FT-VF-HND3
TECHNICAL SUPPORT
0800 603 2330 or (62) 3241-4600
suporte@faaftech.com.br
www.faaftech.com.br
Available from Monday to Friday, from 8 a.m. to 6 p.m. Brasilia time
Plug in to the multimedia
Plug in to the IR input on Faaftech's TV-1SEGII
or TV-HD2. This will enable the channel switch
through the steering wheel commands.
ACC and GND outputs to power the mirroring module.
Note: ACC output has a low current. Use it only to power the
mirroring or the Digital TV module, we do not recommend its
usage to power any other accessories.
Follow us on social media!
ORIGINAL
MULTIMEDIA
Advertisement
Table of Contents
Related Manuals for FAAFTECH INSTALLATION MANUAL
Summary of Contents for FAAFTECH INSTALLATION MANUAL
- Page 1 MULTIMEDIA Plug in to the original whip Plug in to the multimedia Plug in to the IR input on Faaftech’s TV-1SEGII or TV-HD2. This will enable the channel switch through the steering wheel commands. ACC and GND outputs to power the mirroring module.
- Page 2 Steering Wheel Commands If you have installed a Faaftech Digital TV on the radio’s AV input, you can switch channels by using the steering wheel com- mands, as shown on the picture below: Press for 1 second: Channel +...
