- Page 1 INSTALLATION MANUAL FT-VF-FRD3...
- Page 2 *Front camera is not available for vehicles without the original manufacturer’s rear camera. Important Notice: Video visualization is strictly forbidden to the vehicle’s driver. The visualization of video is reserved only to the passengers in the vehicle. FAAFTECH holds no responsibility over eventual damaged caused by the poor usage of this function.
-
Page 3: Camera Activation
Make sure the original radio is connected to the vehicle and the ignition is on before you do the following procedure. 1. Connect the FT-VF-FRD3 interface to the OBD whip that comes with the installation kit; 2. Setup the interface’s DIP Switches according to the picture below;... -
Page 4: Dip Switches
Up in case you are installing on a Ford Ranger DIP 1 Down in case you are installing on Ford Edge, Focus or Fusion FT-TV-1SEG DIP 2 and 3 up FT-TV-1SEGII TV Faaftech DIP 2/3 FT-TV-1SEGIII DIP 2 and 3 down FT-TV-HDII TV LBSat... - Page 5 CONNECTIONS Connect to the whip Connect to the monitor Note: if you are installing on a Ford Ecosport, this whip must be connected to the entertainment center, Connect to the console’s located behind the audio entry instrument dashboard. Note: if you are installing on a vehicle without auxiliary entry, you must use an FM audio...
- Page 6 CONNECTIONS 1 2 3 4 1 2 3 4 Entrada DVD (AV1) Utilize a entrada AV1 para ligar o DVD ou Espelhamento MOBILE MULTI-MEDIA PLAYER Entrada TV (AV2) Utilize a entrada AV2 para ligar a TV Receptor de TV Digital Entrada Camera camera input Entrada de câmera traseira...
- Page 7 Functions Follow the instructions below to use the accessories that you chose to install on the interface’s AV inputs: 1st Choose the AUX audio entry on the multimedia menu; Note: if your vehicle doesn’t have an AUX entry, choose the FM bandwidth from the FM transmitter used in the installation.
- Page 8 Functions Use the car’s commands to control the DVD and the TV (if the DVD and TV models are compatible with the interface). Dashboard Command Steering Wheel Command TV Commands DVD Commands Button # Simple touch 2-seconds touch Simple touch 2-seconds touch Button 1 Channel -...
-
Page 9: Front Camera
FRONT CAMERA When you put the car on reverse, then switch the gear to N or D, the front camera will automatically appear on the screen. The camera will remain turned on for 30 seconds, or until the car reaches the speed of 15 km/h (9.32 mph) or if you press the BACK button on the steering wheel. -
Page 10: Problem Solving
Problem Solving 1. After installing the interface, the multimedia won’t turn on. • Review the installation and check if the cables are connected according to the images on page 3; • Check if all the cables are well connected; • Turn off the ignition, unplug the whip from the entertainment center, wait for 1 minute and replug the whip on the entertainment center again. -
Page 11: Warranty
Warranty FAAFTECH assures their clients a 01 (one) year period against defects in materials and workmanship, proved by presenting both the receipt of purchase from the reseller to the costumer and the present Warranty Certificate filled, observing the following: 1. FAAFTECH will null the warranty if Faaftech or their authorized technical... -
Page 12: Technical Support
TECHNICAL SUPPORT Follow us on social media +55 0800 603 2330 or +55 62 3241 4600 suporte@faaftech.com.br www.faaftech.com.br Available from Monday to Friday, from 8 a.m. to 6 p.m. Brasilia time...
