AVG-HDWP70TX-IR
The AVG-HDWP70TX-IR is a Decora style
transmitter that installs in a double-gang wall
plate to provide a convenient interface for HDMI
and VGA input sources
Features
Selectable HDMI/VGA with audio input
Supports VGA output resolutions up to 1920x1200
High bandwidth: 10.2Gbps
In-built scaler function, supports scaling of
HDMI/VGA signals to match the native
resolution of the display
Transmits HDMI signals up to 4K
Compliant with HDMI 1.4, supports 1080p 3D
HDCP compliant, equipped with HDCP auto-
tracking function
Provides auto-switching capability
Supports multiple control methods
including front panel buttons, IR, and
RS232, supports bi-directional IR &
RS232 pass-through control.
Supports firmware upgrading via USB.
DC 12V power output
Powered by local a power pack or PoC connection
up to 60m
Aluminum design for efficient better cooling
Advertisement
Table of Contents
Related Manuals for AVGear AVG-HDWP70TX-IR
Summary of Contents for AVGear AVG-HDWP70TX-IR
- Page 1 Provides auto-switching capability Supports multiple control methods including front panel buttons, IR, and RS232, supports bi-directional IR & The AVG-HDWP70TX-IR is a Decora style RS232 pass-through control. transmitter that installs in a double-gang wall plate to provide a convenient interface for HDMI Supports firmware upgrading via USB.
- Page 2 AVG-HDWP70TX-IR PLEASE READ THIS PRODUCT MANUAL CAREFULLY BEFORE USING THIS PRODUCT. This manual is for operational use only, and not to be used in a maintenance capacity. The functions described in this version are current as at March 2015. Any changes of functions and operational parameters will be updated in future manual versions.
- Page 3 AVG-HDWP70TX-IR SAFETY OPERATION GUIDE In order to guarantee the reliable operation of the equipment and safety of the user, please abide by the following procedures in installation, use and maintenance: 1. The system must be earthed properly. Please do not use two blade plugs and ensure the AC power supply ranges from 100v to 240v and from 50Hz to 60Hz.
-
Page 4: Table Of Contents
AVG-HDWP70TX-IR TABLE OF CONTENTS Introduction ......................1 Introduction to the AVG-HDWP70TX-IR ............1.1 Features ....................... 1.2 Package List ....……………………………………………………………………2 Product Appearance ....................3 Front Panel ....................3.1 Side Panel ....................3.2 Rear Panel....................3.3 System Connection ....................4 System Application ..................4.1 Usage Precautions .................. -
Page 5: Introduction
The HDBaseT output supports 60m UHD video transmission with PoC, enables bi-directional IR and RS232 communication between HDWP70TX-IR and a remote device. With its PoC solution, the AVG-HDWP70TX-IR can be powered by a far-end PoC receiver. 1.2. Features Selectable HDMI/ VGA with audio input Supports VGA output resolutions up to 1920x1200 High bandwidth: 10.2Gbps... -
Page 6: Package List
AVG-HDWP70TX-IR 2. Package List 1 x AVG-HDWP70TX-IR 4 x Screws 3 x Pluggable Terminal Blocks (1 2-pin block, 1 3-pin block, and 1 4-pin block) 1 x Face Plate (Selectable) 4 x Screws (for the face plate) 1 x User Manual Note: Please confirm if the product and the accessories are all included, if not, please contact your dealer. -
Page 7: Product Appearance
AVG-HDWP70TX-IR 3. Product Appearance 3.1. Front Panel Note: Pictures shown in this manual are for reference only. Name Description Power Illuminates red when power is on ① indicator Connect with IR receiver, receive IR signals sent from ② IR IN... - Page 8 AVG-HDWP70TX-IR input source turns off when there is no VGA input signal Connect with the audio output socket of the VGA source ⑥ AUDIO IN device, delivers synchronous audio with the VGA signal source when VGA is the source signal.
-
Page 9: Side Panel
AVG-HDWP70TX-IR 3.2. Side Panel Description Name RJ45 port, connect with receiver via a CAT5e/6 cable to ① HDBT OUT deliver Audio/ Video signals, supports PoC. Note: Pictures shown in this manual are for reference only. 3.3 Rear Panel Name Description Power in port, 2-pin pluggable terminal block, connect with a ①... -
Page 10: System Connection
AVG-HDWP70TX-IR 4. System Connection 4.1. System Applications Reliable performance for control and transmission makes the AVG-HDWP70TX-IR ideal in the IT computer space, signal monitoring, big screen displays, conference systems, television broadcast, education, banking and security institutions etc. 4.2. Usage Precautions 1. -
Page 11: Connection Procedure
Connect HDMI source device (e.g. Blu-ray DVD) to the HDMI input port of the AVG-HDWP70TX-IR with HDMI cable. Connect a VGA source device (e.g. PC) to the VGA input port of AVG-HDWP70TX-IR with VGA cable Step 2. Connect an AVG-HD402PR to the HDBT port on the rear panel with twisted pair. -
Page 12: Dc Output
AVG-HDWP70TX-IR 4.5. 12V DC Output AVG-HDWP70TX-IR has a 12V power output port on the rear panel. Connect the 12V power output port of AVG-HDWP70TX-IR to the power port of a 3 Party Device for convenient localized powering. Note: Pictures shown in this manual are for reference only. -
Page 13: System Operations
38400, 57600 or 115200 5.2.1 Connection with the RS232 Communication Port As well as the front control panel, the AVG-HDWP70TX-IR can be controlled by a 3 Part control system through the RS232 communication port. This RS232 communication port is a female 9-pin D connector. The definition of its pins is listed in the table below. -
Page 14: Basic Settings
Removal Delete all the control software files in corresponding file path. 5.2.3. Basic Settings Firstly, connect the AVG-HDWP70TX-IR with an input device and an output device. Then, connect it with a computer which is installed with RS232 control software. Double-click the software icon to run this software. - Page 15 AVG-HDWP70TX-IR The interface of the control software is shown below: Parameter Configuration area Monitoring area, indicates whether the command sent works. Command Sending area Please set the parameters of COM number, baud rate, data bit, stop bit and the parity bit correctly, only then will you be able to send commands in the Command...
-
Page 16: Rs232 Communication Commands
AVG-HDWP70TX-IR 5.3. RS232 Communication Commands Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none Command Function Feedback Example System Commands Switch to HDMI input Switch to HDMI 50701% 50704% Switch to VGA input Switch to VGA 50770%... - Page 17 AVG-HDWP70TX-IR Command Function Feedback Example Color Temperature: xx (xx 50607% Adjust the color temperature can be medium, warm, user, or cool) Aspect Ratio: xx (xx 50608% Set the aspect ratio can be 16:9, 4:3, or auto.) 50614% Set the picture mode...
- Page 18 AVG-HDWP70TX-IR Command Function Feedback Example Check the image aspect ratio Aspect Ratio: xx 50635% 50636% Check the brightness Brightness: xx 50637% Check the contrast Contrast: xx 50638% Check the saturation Saturation: xx 50639% Check sharpness Sharpness: xx 50640% Check the color temperature...
- Page 19 AVG-HDWP70TX-IR Command Function Feedback Example Set EDID data to 1080i PCM 2.0ch EDID:1080i&PCM 50776% Set EDID data to 4K*2K PCM 50777% EDID:4K&PCM 2ch 2.0ch EDID:1080P& CM 2ch 50778% Check EDID data EDID:1080P& .1ch EDID:1080P3d &5.1ch EDID:4K&PCM 2ch Program EDID file, send EDID data...
-
Page 20: Firmware Update Via Usb
To meet the needs of different users or further additional functions, the firmware of the AVG-HDWP70TX-IR can be upgraded via USB. If the unit needs upgrading please download the latest firmware file and then you are able to upgrade it through the update .exe file. -
Page 21: Specification
AVG-HDWP70TX-IR 6. Specification Audio Input Input Signal 1 HDMI, 1 VGA, 1 AUDIO, 1 IR, 1 Input Signal RS232 1 19-pin Type A HDMI female; 1 Connector Connector 15-pin VGA; 1 3.5mm stereo jack; 1 3.5mm IR socket;1 3-pin pluggable terminal block... -
Page 22: Panel Drawing
AVG-HDWP70TX-IR 7. Panel Drawing 88.72 mm 46.00 mm Note: Pictures shown in this manual are for reference only. -
Page 23: Troubleshooting & Maintenance
AVG-HDWP70TX-IR 8. Troubleshooting & Maintenance Problems Causes Solutions Colour loss or no video signal output on HDMI display The connecting Check whether the cables are No HDMI signal cables may not connected correctly and in good output in the device be connected working condition.
