AVGear AVG-HDWP70TX-B User Manual

Hdbase t wallplate transmitter button control
Hide thumbs Also See for AVG-HDWP70TX-B:
Table of Contents

Advertisement

Quick Links

Download this manual
AVG-HDWP70TX-B
The AVG-HDWP70TX-B is a Decora style
transmitter that installs in a double-gang wall
box to provide a convenient interface for
HDMI/VGA input sources.
Features
Selectable HDMI/VGA with audio
input
Supports VGA output resolution up to
1920 x1200
High bandwidth: 10.2Gbps
In-built scaler function, supports
scaling of HDMI/VGA signals to match
the native resolution of the display
Transmits HDMI signals up to 4K
Compliant with HDMI 1.4, supports
1080p 3D
HDCP compliant, equipped with
HDCP auto-tracking function
Provides auto-switching capability
Supports multiple control methods
including front panel buttons and
RS232, supports bi-directional RS232
pass-through control.
Supports firmware upgrade via USB.
DC 12V power output
Powered by local power pack or PoC
connection up to 60m
Aluminum design for efficient cooling
