Quasar Science Q25R Quick Start Manual page 4

DMX Profiles
# Name
1 HSIC
2 HSIC-16
3 HSI
4 XFade with +/-G
5 XFade
6 CCT & RGB
7 CCT & RGB-16
8 RGB
DMX Profiles (FX)
Name
9
HSIC FX
10
HSIC-FX-16
11
CCT & RGB-FX
12
CCT & RGB
-16 FX
DMX Parameters
Parameter
Intensity
Color Temp
+/- Green
Crossfade
Hue
Saturation
Red
Green
Blue
# of
8/16 Channels
Chan
8 Bit 5 1:Intensity 2: Color Temp 3: +/- Green Control 4:Hue 5:Saturation
16 Bit 7 1+2:Intensity 3: Color Temp 4: +/- Green Control 5+6:Hue 7:Saturation
8 Bit 3 1:Intensity 2: Hue 3:Saturation
8 Bit 3 1:Intensity 2: Color Temp 3: +/- Green Control
8 Bit 2 1:Intensity 2: Color Temp
8 Bit 7 1:Intensity 2: Color Temp 3: +/- Green Control 4:Crossfade 5:Red
6:Green 7:Blue
16 Bit 9 1+2:Intensity 3: Color Temp 4: +/- Green Control 5+6:Crossfade
7:Red 8:Green 9:Blue
8 Bit 3 8: RGB – 8 bit – 3 Channels 1:Red 2:Green 3:Blue
Download Complete DMX Chart at QuasarScience.com/Rainbow
# of
8/16 Channels
Chan
8 Bit 8 1:Intensity 2: Color Temp 3: +/- Green Control 4:Hue 5:Saturation
6: FX 7:FX Rate 8:FX Size
16 Bit 10 1+2:Intensity 3: Color Temp 4: +/- Green Control 5+6:Hue 7:Saturation
8: FX 9:FX Rate 10:FX Size
8 Bit 10 1:Intensity 2: Color Temp 3: +/- Green Control 4:Crossfade 5:Red
6:Green 7:Blue 8: FX 9:FX Rate 10:FX Size
16 Bit 12 1+2:Intensity 3: Color Temp 4: +/- Green Control 5+6:Crossfade
7:Red 8:Green 9:Blue 10: FX 11:FX Rate 12:FX Size
DMX
Value
Value
0-255 0-100%
0-255 2000k-6000k
See Chart at right
0-255 0-100%
0-255 0°-360°
0-255 0-100%
0-255 0-100%
0-255 0-100%
0-255 0-100%
Q-Rainbow RGBX
+/- Green
DMX
%
Value
0-10 0-4
11-20 5-8 Full Minus Green
21-119 8-46 -99% to -1%
120-145 47-57
146-244 57-96
245-255 96-100 Full Plus Green
Linear LED
Effect
No Effect
No Effect
1% to 99%
