Getting Started

To Set the Intensity, Color Temp, +/- Green, Saturation and Hue:
Press the
Press
The selection carrots > < will move from the >Function< to the >Value<
Press the
To Link a Rainbow lamp to a transmitter,
Go to Config->Wireless, Set to ON, Config->Status Lights to ON
If the Wireless DMX is flashing, press and hold the
On the DMX Transmitter, tap the Link button to Pair.
The Wireless DMX Light will start to Flash and turn solid once paired.
Main Menu - Manual Mode Main Menu - Manual Mode
> Intensity 0 to 100%
> Color Temp 2000k to 6000k by 100k increments
> CT Preset 3200-4000-5000-5600-6000-2000-2800
> Saturation 0 to 100%
> Hue 0° to 360°
> +/- Green 100M to 0G to 100G
> Color Preset Blue-Cyan-Green-Red-Yellow-Orange-Magenta
> Effects Rainbow-Short Circuit-Paparazzi-Fire1-Fire2-Fire3-Coplight1-Coplight2-Demo
> Config DMX Address-DMX Profile-Lead/Follow/Wireless On/Off-StatusLights On/Off
-FirmwareVersion-Lamp Hours-Reset to Default-BACK to Main Menu

Config Menu

> DMX Address
> Profile
> Lead /Follow
> Wireless
> Status Lights
> Firmware
> Lamp Hours
> Reset to Default
-
+
Left or Right arrows until desired function is selected.
Enter to Select.
-
+
or buttons to set the value. Press
001 to 508 (Does not allow address to be outside of 512)
1:HSIC-8 bit, 2:HSIC-16 bit, 3:HSI-8 bit, 4: XFade with CC-8 bit, 5: XFade-8 bit,
-6: CCT & RGB-8 bit, 7: CCT & RGB-16 bit, 8: RGB-8 bit
Lead-Follow1-Follow2-Follow3-Follow4-Follow5
On/Off - Disables the wireless transceiver
On/Off - Turns off the status lights for use on camera
Displays the Firmware Version on the Lamp
Displays the Hours the lamp has been powered on
Sets the lamp back to all its default values
Q-Rainbow RGBX
Enter to Save.
Link button to Unpair.
-
+
Linear LED
Data
DMX
