- Page 1 QUASAR SCIENCE Q-Rainbow RGBX Linear LED Da ta DM X V1.0 Firmware - V 0.82 ©2018 Quasar Science, LLC 687 S. Anderson St. Los Angeles, CA 90023 info@quasarscience.com (800) 876-0665...
-
Page 2: Table Of Contents
Q-Rainbow RGBX Linear LED Table of Contents TABLE OF CONTENTS FEATURES INTRODUCTION UNPACKING OVERVIEW BASIC OPERATION TATUS IGHTS ANUAL HORT ONFIG EFAULT ALUES MODES ANUAL IRED IRELESS IRELESS AIRING OLLOW CONTROL OVER DMX DMX PROFILES DMX S TANDARD ROFILES P a g e... - Page 3 Q-Rainbow RGBX Linear LED . 16 BIT VS 1: HSIC – 8 B – 5 C HANNELS 2: HSIC – 16 B – 7 C HANNELS 3: HSI – 8 – 3 CHANNELS 4: C +/- G – 8 B...
- Page 4 Q-Rainbow RGBX Linear LED POWER AC P OWER DC P OWER ATTERY SAGE UPDATING FIRMWARE TROUBLESHOOTING WARRANTY CONTACT P a g e...
-
Page 5: Features
Q-Rainbow RGBX Linear LED Features 2000k-6000k Crossfade White Light with RGB Color Mixing (RGBX) Wireless by DMX over Cat5 Manual Interface with OLED Screen Universal AC Power 90v-256v DC Battery Option 10v-26v Lead / Follow Mode On Board Effects RDM Compatible Lengths: 2’... -
Page 6: Introduction
Q-Rainbow RGBX Linear LED Introduction Based on the Crossfade Linear LED (X) which utilizes our 2000k and 6000k diodes to create variable broad spectrum white light, the Rainbow adds red, green and blue (RGB) diodes to the mix. RGB + Crossfade = RGBX When desaturating a color, such as red, using only RGB systems, the desired light level is achieved by mixing in the green and blue diodes. -
Page 7: Unpacking
Q-Rainbow RGBX Linear LED As illustrated above with RGB derived white light, wide gaps in the spectral distribution compromise color response. With the RGBX system, the broad spectral curve provides a more balanced distribution, leveling the peaks and valleys, which more accurately renders natural colors and skin tones. -
Page 8: Overview
Q-Rainbow RGBX Linear LED Overview The Rainbow Layout The Control Screen Controller Endcap P a g e... -
Page 9: Basic Operation
Q-Rainbow RGBX Linear LED Basic Operation The menu system is design to be easy an intuitive. Select a Parameter: Press the Left and Right arrows until desired function is selected. Edit a Parameter: When a Parameter is selected, there will be selection carets next to it. -
Page 10: Status Lights
Q-Rainbow RGBX Linear LED Status Lights The Rainbow Status Lights Solid Red Light - Data Received No Red Light - No Data Received or Wireless/Status Lights are turned off. Solid Green Light - Lamp is paired and receiving transmission. Slow Flashing Green Light - Wireless DMX is paired but transmitter not found. - Page 11 Q-Rainbow RGBX Linear LED > Hue 0° to 360° > CT Preset (Color Temperature Presets – Automatically changes the Color temperature to desired setting and sets the saturation at 0%). 3200k 4000k 5000k 5600k 6000k 2000k 2800k > Color Preset (Hue Color Presets – Automatically changes the Hue to desire setting and sets...
-
Page 12: Menu Short Cuts
Q-Rainbow RGBX Linear LED Menu Short Cuts See Short Cuts Page 34. Config Menu DMX Address 001 to 508 (Does not allow address to be outside of 512) DMX Profiles 1. HSIC – 8bit, 2. HSIC - 16 bit 3. HSI - 8bit 4. -
Page 13: Default Values
Q-Rainbow RGBX Linear LED Firmware Displays the Firmware Version of the Rainbow Lamp Hours Displays the Hours the Rainbow has been powered on Reset to Default Sets the Rainbow back to all its default values Default Values Parameters Intensity:100% Color Temp: 3200k... -
Page 14: Modes
Q-Rainbow RGBX Linear LED Modes The Rainbow can operate in several modes. • Manual mode with on screen controls • DMX through the Cat5 ports • Wireless DMX with on board Lumen Radio chip • Lead / Follow Mode for controlling many Rainbows from one. -
Page 15: Wireless Pairing
Q-Rainbow RGBX Linear LED Wireless Pairing To Link a Rainbow lamp to a transmitter, Go to Config->Wireless, Set to ON, Config->Status Lights to ON If the Wireless DMX is flashing, press and hold the Link button to Unpair. On the DMX Transmitter, tap the Link button to Pair. -
Page 16: Control Over Dmx
Q-Rainbow RGBX Linear LED When in Lead / Follow mode, the lamp is set to the following config: Lead / Follow: Lead DMX Profile: 10 – HSIC + Effects – 16 bit Lead / Follow: Follow 1 DMX Profile: 10 – HSIC + Effects – 16 bit... -
Page 17: 1: Hsic - 8 Bit - 5 Channels
Q-Rainbow RGBX Linear LED 1: HSIC – 8 Bit – 5 Channels HSIC – Hue, Saturation, Intensity, Color Temperature and +/- Green Control. This mode is great if all you have are sliders. 2: HSIC – 16 Bit – 7 Channels Hue, Saturation, Intensity, Color Temperature and +/- Green Control. - Page 18 Q-Rainbow RGBX Linear LED Profile 1 HSIC – 8 Bit 5 DMX Channels Channel Function Value Percentage Description Default % / DMX Intensity 0-255 0-100 Color Temp 0-255 0-100 2000K to 6000K G +/- Plus and Minus Green 50% / 128...
- Page 19 Q-Rainbow RGBX Linear LED Profile 4 Crossfade & CC - 8 bit 3 DMX Channels Channel Function Value Percentage Description Default % / DMX Intensity 0-255 0-100 Color Temp 0-255 0-100 2000K to 6000K G +/- Plus and Minus Green...
- Page 20 Q-Rainbow RGBX Linear LED Profile 7 CCT & RGB – 16 Bit 9 DMX Channels Channel Function Value Percentag Description Default % / DMX Intensity 0-65.535 0-100 Color Temp 0-255 0-100 2000K to 6000K G +/- Plus and Minus 50% / 128...
-
Page 21: Dmx Fx Profiles
Q-Rainbow RGBX Linear LED DMX FX Profiles The Rainbow allows for direct access to the Built in FX from with the DMX Parameters. Through DMX, the user can set the effect and parameters of the effect. 9: HSIC + FX – 8 Bit – 8 Channels Hue, Saturation, Intensity, Color Temperature and +/- Green Control, FX Selection, FX Rate, FX Size. - Page 22 Q-Rainbow RGBX Linear LED FX Profile 9 HSIC+FX – 8 Bit 8 DMX Channels Channel Function Value Percentage Description Default % / DMX Intensity 0-255 0-100 Color Temp 0-255 0-100 2000K to 6000K G +/- Plus and Minus Green 50% / 128...
- Page 23 Q-Rainbow RGBX Linear LED FX Profile 10 HSIC+FX – 16 Bit 10 DMX Channels Channel Function Value Percentage Description Default % / DMX Intensity 0-100 0-65,535 Color Temp 0-255 0-100 2000K to 6000K G +/- Plus and Minus Green 50% / 128...
- Page 24 Q-Rainbow RGBX Linear LED FX Profile 11 CCT & RGB+FX – 8 Bit 10 DMX Channels Channel Function Value Percentage Description Default % / DMX Intensity 0-255 0-100 Color Temp 0-255 0-100 2000K to 6000K G +/- Plus and Minus Green...
- Page 25 Q-Rainbow RGBX Linear LED FX Profile 12 CCT & RGB + FX – 16 Bit 12 DMX Channels Channel Function Value Percentage Description Default % / DMX Intensity 0-65.535 0-100 Color Temp 0-255 0-100 2000K to 6000K G +/- Plus and Minus Green...
-
Page 26: Effects
Q-Rainbow RGBX Linear LED Effects The Rainbow LED has built in effects with control of the options. Effect Types Rainbow Effect The Rainbow Effect Scrolls through all the colors. The Rate at 100% will scroll though all the saturated colors in 6 seconds. The Rate at 0% will be 36 seconds. The Rate at 200% will be 1 second. -
Page 27: Manual Effects
Q-Rainbow RGBX Linear LED Manual Effects Intensity: Control the Intensity of the Effect from 0% to 100% Rate: Rate is the speed that the effect is running. 100% is normal speed. It can go from 0% to 200% For Fire Effects:... -
Page 28: Invisible Green
Q-Rainbow RGBX Linear LED Ex. Intensity 50% with Size of 10 will be an effect from 40% to 60% Coming Soon in a firmware update, selectable effects colors. Invisible Green Integrated into our Rainbows is a feature called “Invisible Green.” Invisible Green automatically manages the White Light CCI with any Green or Magenta bumps while traveling across the black body curve between 2000k and 6000k This ensures a clean white light output at all times. -
Page 29: Shortcuts
Q-Rainbow RGBX Linear LED Shortcuts 1. On parameter menus such as intensity, saturation, and hue, when pressing and holding button to increase the value, tap the button will jump to the next value or max value. 2. On parameter menus such as intensity, saturation, and hue, when pressing and holding... - Page 30 Q-Rainbow RGBX Linear LED Power AC Power The Rainbow can be powered from AC power through a True 1 Power connector. The AC side has a power switch. It accepts Universal Power from 90 to 265 volts for all power systems throughout the world.
-
Page 31: Updating Firmware
Linear LED Updating Firmware To Update the Firmware on the Q-Rainbow LED, you will need to use our Q-Upgrade Cable and the Quasar Science Update Utility. 1. Download the Update Utility for your computer PC or Mac at www.QuasarScience.com/rainbow 2. Run the Program. If a popup opens and asks you to confirm running the program, press yes. - Page 32 If this product fails to work as warranted, customer's sole and exclusive remedy shall be repair or replacement according to the terms of this limited warranty. Quasar Science, LLC does not assume any responsibility for incidental or consequential damages. This warranty gives you specific legal rights and you may also have other rights which vary from state to state, province to province or country to country.
- Page 33 Q-Rainbow RGBX Linear LED Contact Please do not return your Rainbow to your STOP retailer. Please contact Quasar Science with any questions, problems or concerns. Please Register your Rainbow at QuasarScience.com 687 S. Anderson St. Los Angeles, CA 90023 info@quasarscience.com...
