- Page 1 HWA09R HWA13R IMPORTANT Please read this owner’s manual carefully and thoroughly before installing and operating your room air conditioner. Please retain this owner’s manual for future reference after reading it thoroughly.
-
Page 2: Table Of Contents
Table of Contents Page Introduction Operating Instructions Electrical Specifications Installation Instructions Care and Maintenance Trouble Shooting Guide - 1 -... -
Page 3: Introduction
Introduction For remote control model Front Cover Air inlet grille (Indoor) Cabinet Air outlet grille (Indoor) Air inlet grille (Outdoor) Vent Lever Control Panel Air filter Fig.1-1 SLEEP TIMER ON TMIER OFF FEEL AUTO COOL HIGH SWING SLEEP TIMER SWING MODE ON/OFF Control Panel... -
Page 4: Operating Instructions
Operating Instructions For remote control model You can easily operate this air conditioner by press relevant button on the control panel as well as the remote controller. Button Function Used to adjust airflow direction. Used to set or cancel timer operation. When the unit is in operation, you can set OFF TIMER.When the unit is off, you can set ON TIMER. -
Page 5: Remote Controller
Operating Instructions Remote controller The remote controller transmits signals to the system. Button Function (TEMP UP) Increase the temperature or time by 1 unit (TEMP DN) Decrease the temperature or time by 1 unit ON/OFF To switch the conditioner on and off. To select the fan speed of auto/low/mid/high To set automatic switching-on/off TIMER... -
Page 6: Electrical Specifications
Electrical specifications 1. All wiring must comply with local and national Electric Shock Hazard electrical codes and must be installed by a qualified electrician. If you have any questions The air conditioner has a serial rating regarding the following instructions, contact a volts. -
Page 7: Installation Instructions
Installation instructions REMOVE ALL THE SHIPPING PARTS BEFORE INSTALLATION LOCATION Select a location that can support the weight of the air conditioner and one that will not cause increased operation noise and vibration. Direct sunlight is unfavorable for efficient cooling. Select a place where there is no obstacles near the air inlet and outlet. - Page 8 Installation instructions CAUTION The installation parts must be strong against corrosion,especially in case the air conditioner will be installed near the sea or hot spring. Do not install air conditioner in the place where inflammable gas leaks are a possibility. he minimum clearance from the appliance to combustible surfaces is 100mm (Only for Electric heating ) he range of external static pressures at which the appliance was tested is 0-5Pa...
- Page 9 Installation instructions 1) Remove the front panel. (Fig.5) Remove the air filter. (Fig.6) Remove screw at the botton of the front panel. (Fig.7) Open the panel cover. Fig.5 2) Remove the screws fix the chassis-fixing board and cabinet. some Models have two more screws on the back of the cabinet.
-
Page 10: Care And Maintenance
Care and Maintenance AIR FILTER The air filter should be washed at least once a month. lf the air filter remains full of dust, the air flow will decrease and the cooling capacity will be reduced. The filter is behind the cover and to be pulled out from right hand side. Wash the air filter with water an detergent. -
Page 11: Troubleshooting Guide
Troubleshooting Guide Never use hot water above 50 ,benzine,gasoline,acid,thinner or brush to wipe off dirt because they will damage the plastic surface and the coating. LONG OFF PERIOD MAINTENANCE Operate the fan alone ("LOW FAN"or"HIGH FAN") for half a day to dry out the inside of the unit.
