Yealink VCR11 Quick Reference Manual

VCR11 Remote Control Quick Reference Guide

Parts of the Remote Control

Item
No.
Powers the system on and off.
1 Power Key
Puts the system to sleep or wakes the system.
Video Recording
2 Starts or stops recording video and audio.
Key
3 Layout Key Adjusts layout during a video call.
Assigns predefined functions to this key.
Off
Input key: press to select the video input
source.
Screencapture key: press to capture screen.
4 Custom Key
Mute Speaker key: press to mute or unmute
the speaker.
Presentation key: press to start or stop
presentation.
5
Vol+ Increases the system volume.
6 Vol- Decreases the system volume.
Increases the camera zoom.
Increases the captured image magnifications.
7 Zoom in Key
Behaves as page up in a multiple page
list.
Decreases the camera zoom.
Decreases the captured image
8
Zoom out Key magnifications.
Behaves as page down in a multiple
page list.
9
OK Key Confirms actions or answers incoming calls.
Navigate through menu items using the Up,
Down, Left, and Right keys..
10 Navigation Key
Pan and tilt the camera to adjust the viewing
angle.
Description
No.
11
12
13
14
15
16
17
18
19

Waking the System

1. To wake the system, press any key on the remote control.

Placing a Call

Entering the Calling Information

1. Select Dial menu or press
Description
Item
Mute Key Toggles the mute feature.
Returns to the idle screen when in the menu.
Home Key
Enters the Talk Menu during a call.
Back Key Returns to the previous menu.
Enters the pre-dialing screen.
Off-hook Key Places a call.
Answers a call.
Deletes one character at a time.
Long press to delete all characters in the
input field.
Delete Key
Long press it for 2 seconds to start capturing
packets and long press it for 2 seconds
again to stop capturing packets.
Ends a call or exits from a conference call.
On-hook Key
Returns to the idle screen.
Enters digits.
Keypad
Enters the pre-dialing screen.
Character Key
Generates special characters: .*@.
# Key Generates a pound key (#).
to enter the pre-dialing screen.
