GUILD
300W Oscillating Tool
Original Instruction Manual
Important
- Please read these instructions fully before operating or maintaining your Guild High
Frequency Oscillating Tool
These instructions contain important information that will help you get the best from your Guild
Oscillating Tool, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 0333 3201989
After Sales Support
UK/Ireland 0333 3201989
Help@guildpowertools.co.uk
PMF300GH.1
Advertisement
Table of Contents
Related Manuals for Guild PMF300GH.1
Summary of Contents for Guild PMF300GH.1
- Page 1 - Please read these instructions fully before operating or maintaining your Guild High Frequency Oscillating Tool These instructions contain important information that will help you get the best from your Guild Oscillating Tool, ensuring it remains safe to operate. If you need help or have damaged or missing parts, call the Customer Helpline on 0333 3201989...
-
Page 2: Table Of Contents
Contents Safety Information ....................3 In The Box .........................7 Accessories ......................7 Operating Instructions ....................8 Troubleshooting ...................... 12 Maintenance ......................12 Technical Data ......................13 Environmental Protection ..................14 Guarantee ....................... 15 Plug Replacement (Uk & Ireland Only) ..............15 Customer Helpline 0333 3201989... -
Page 3: Safety Information
Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols The following warning symbols appear throughout this assembly manual and indicate the appropriate safety measures you should take when assembling and operating the multi function tool. To reduce the risk of injury, user must read instruction manual Wear eye protection Wear ear protection... - Page 4 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
- Page 5 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach.
- Page 6 Safety Information Important - Please read these instructions fully before starting assembly Safety instruction for cutting 1. Hold power tool by insulated gripping surfaces, when performing an operation where the cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a "live"...
-
Page 7: In The Box
Mesh sanding sheet Handing area Segment saw blade Venting slots Sanding pad Blade Interface Scraping Accessories PMF300GH.1 Sanding sheet (80/100/120grit) Sanding pad 3-1/8" Circular segment saw blade Scraper 1-1/8" Standard straight cutter 1-3/8" Standard straight cutter Customer Helpline 0333 3201989... -
Page 8: Operating Instructions
Operating Instructions Operation instructions NOTE: Before using the tool, read the instruction book carefully. Intended Use The power tool is intended for sawing and remodelling wooden materials, plastic, plaster, non-ferrous metals and fasteners (e.g. nails and clamps) as well as for working on soft wall tiles and for dry grinding of small surfaces. - Page 9 Operating Instructions Operation instructions Re-insert the flange(7) , press the flange(7) to keep the blade or other accessory temporarily secure. Flip the tool- free blade change lever (1) back to original position to secure the accessory. (SEE FIG. C1 C2) ASSEMBLING / CHANGING THE SANDING SHEET (SEE FIG.
- Page 10 Operating Instructions Operation instructions 3. USING THE VARIABLE SPEED DIAL (SEE FIG. G) Select oscillation frequency (speed) while the motor is running. The Variable Speed Dial can be used to set the optimum oscillating frequency according to the accessories used and the respective application. High oscillation frequency: Sanding, sawing, rasping and polishing stone and metal.
- Page 11 Operating Instructions Operation instructions APPLICATION WARNING: The saw teeth are very sharp. Do not touch during mounting and application. The workpiece must be clamped tightly before it is cut. UNIVERSAL ACCESSORIES NOTE: Accessories also work with other competitive oscillating tools. Name Application Bi-Metal Metal/...
-
Page 12: Troubleshooting
Troubleshooting 1. If your heat gun will not operate, check that it is pluggedi n, switched on and the fuse is intact. 2. If the gun has over-heated and is blowing only cool air, direct the flow away from your workpiece until the heat is restored. -
Page 13: Technical Data
Technical Data Technical Data Table Rated voltage 230-240V~50Hz Power 300W Oscillations speed 11000-20000/min Oscillations angle 3.2° Protection class Tool weight Noise Information A weighted sound pressure : 79.5dB(A) A weighted sound power : 90.5dB(A) & K =3.0dB(A) Wear ear protection when sound pressure is over 80 dB (A) Vibration Information Vibration total values (triax vector sum) determined according to EN 62841: Vibration emission value a... -
Page 14: Environmental Protection
Technical Data Helping to minimise your vibration and noise exposure risk. Always use sharp chisels, drills and blades. Maintain this tool in accordance with these instructions and keep well lubricated (where appropriate). If the tool is to be used regularly then invest in anti vibration and noise accessories. Plan your work schedule to spread any high vibration tool use across a number of days. -
Page 15: Guarantee
Guarantee This product is selected for DOMESTIC USE ONLY and not for business use. This product is guaranteed against manufacturing defects for a period of 24 months. This does not cover the product where the fault is due to misuse, abuse, use in contravention of the instructions, or where the product has been the subject of unauthorised modifications or alterations, or has been the subject of commercial use.
