Hurom Juicer Household Use (Warranty Included)
1. Read 'Precautions for safe use' (Page 6) and use the appliance properly.
2. After finish reading the manual, keep it in a convenient location for future reference.
3. Do not use it abroad which has different power supply and voltage.
4. Any quality improvements are subject to change without notice.
HN-SERIES
02
How to assemble
05
Cautions during operation
08
Assembling the spinning
brush
11
Before requesting for
repair
06
When auger stops during
operation
09
Assembling the chamber
seal
12
Product Specifications /
Warranty
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HUROM HN Series
Summary of Contents for HUROM HN Series
- Page 1 Warranty Hurom Juicer Household Use (Warranty Included) 1. Read ‘Precautions for safe use’ (Page 6) and use the appliance properly. 2. After finish reading the manual, keep it in a convenient location for future reference. 3. Do not use it abroad which has different power supply and voltage.
-
Page 2: Terms Of Parts
Terms of parts Terms of parts Pusher Juice Cap Hopper Base Auger Pulp Container Fine Strainer Juice Container Lid Coarse Strainer Juice Container Spinning Brush Small Cleaning Brush Silicone Brush Cleaning Brush Chamber Hopper Lid 08-1 Pulp Outlet Operating Switch 08-2 Juice Outlet Power Cord... -
Page 3: How To Assemble
Assemble the parts in the following order: STEP Chamber>Spinning Brush> Strainer. Make sure chamber arrow [ ] aligns with strainer arrow [ The spinning brush can be assembled regardless of the direction. STEP Place the chamber on the base. www.hurom.com |... -
Page 4: Precautions For Safe Use
1. You should read <Precautions for safe use> 2. You should follow <Precautions for safe use> Precautions for safe use 3. Precautions are classified as follows. Warning When violating the labeling requirement, it may cause serious injury or death. Do not plug in nor unplug with wet hanDs. It may cause electric shock or injury. - Page 5 6.2kg (13.6lB). when MoVing the applianCe, en- sure to MoVe it holDing grips tightly at the Base BottoM with Both hanDs. If attempting to hold chamber or the edge of the base, the base falls causing an injury or failure. www.hurom.com |...
-
Page 6: Cautions During Operation
Cautions during operation Ingredients which needs caution - Fruits with hard seeds such as persimmon, Japanese apricot, lemon, plum, peach etc. that are hard to chew with our teeth should be pitted before extraction. - For stalk vegetables with strong fiber such as water parsleys, celery etc. cut them into small size about 3~4cm before putting them into the hopper chute. - Page 7 From the feature of the product, even though you stop the operation, it doesn’t stop right away. It rotates slowly then stops. If the rotation stops completely, you may press the button to any direction you want. (Same as when pressing [On] during reverse operation) www.hurom.com |...
- Page 8 Disassembling and cleaning the spinning brush Remove the spinning brush from strainer. Detach the silicone brush from the spinning brush. spinning brush silicone brush As shown in the figure, hold the outer part of silicone brush and pull it out gently in the direction of the arrow. Silicone brush may be torn or damaged if it is pulled apart forcefully.
-
Page 9: Assembling The Spinning Brush
Make sure the silicone brush is placed firmly into the groove by holding the top and bottom part of the ‘outer wing’ and pulling it up and down in opposite directions. www.hurom.com |... -
Page 10: Assembling The Chamber Seal
ASSEMBLING THE CHAMBER SEAL Hold the chamber seal by pinching it between the thumb and index finger. As shown to the left in the dotted circle, let the pro- truding part on the chamber seal face upward when you hold it by pinching it between the thumb and index finger. -
Page 11: Assembling The Juice Cap Seal
Open the juice cap and fit the juice cap seal on to the inner disk. Be careful not to drop the chamber. Arrange the seal for a complete fit. If the seal is not placed correctly, it may cause juice leakage. www.hurom.com |... - Page 12 Please check the details below before contacting Technical Support for repair or service. If you need additional information, please contact the local Customer Care Center or visit www.hurom.com. When applying for after-sales service, please have the manufacturer’s serial number or bar code available.
- Page 13 Hurom provides warranty for ten (10) years for the motor and two (2) years for other parts from the date of purchase by the original purchaser. Coverage is valid only with proof of purchase from an Authorized Local Distributor.
- Page 14 MEMO...
- Page 15 MEMO www.hurom.com |...
- Page 16 Coarse strainer has larger holes so it is good to make thick juice with flesh in it. It is to make juice with soft fruits and thick juice like banana, strawberry, and also useful for smoothie, latte, or soup. www.hurom.com NmNENN140515A _V.03 Copyright© All Rights Reserved by huRom...
