CRAIN 561 Instruction Manual

TAPPING TOOLS:
No. 561 Pull Bar
Hook the wide end of this tool onto the planks and tap
lightly on other end with a hammer. (See figure 6.)
No. 561
Fig. 6 - Pulling plank with No. 561
No. 563 Tapping Block:
Fit the groove of this tool onto the tongue of the plank
and tap it with a hammer. (See figure 7.)
No. 563
Fig. 7 - Tapping planks together
CUTTING TOOLS:
See detailed instructions packed with each tool.
No. 795 Toe Kick Saw:
1. Remove damaged underlayment at the toe kick
area. (See figure 9.)
2. Enlarge gap between wall and laminate planks as
required by laminate manufacturers. (See figure 10.)
Fig. 9 - Remove underlayment at
toe kick with No. 795
No. 812 Super Saw:
1. Door jamb moldings can be cut to allow the plank to
fit underneath. (See figure 11.)
2. A special blade is available for undercutting masonry,
such as around fireplaces. (See figure 12.)
with No. 563
Fig. 11 - Undercutting door jamb
Any parts found defective subject to the guarantee will
be replaced at no charge. Credit in full or part can not be
extended by the distributor, nor will a new tool be given
as a replacement or loaner.
Tools subject to this warranty must be accompanied by
the same, and returned freight PREPAID to Milpitas, CA,
and must be in assembled condition.
Guarantee covers the following tools:
Item No.
564
565
566
Printed by: HW
Fig. 10 - Enlarging gap with No. 795
Fig. 12 - Undercutting masonry
GUARANTEE
Description Warranty
Variable Wall Spacer
18' Strap Clamp
Floor Vise
CRAIN CUTTER CO., INC.
MILPITAS, CA 95035
TEL: 408-946-6100 FAX: 408-946-4268
INSTRUCTION
MANUAL
FOR
ENLARGING GAP
No. 561
No. 562
No. 564
No. 569
90 days
90 days
90 days
LAMINATE TOOLS
Made in
America
F1560-2-0404
No. 563
No. 566
No. 795
No. 565
No. 812
