REPLACEMENT PARTS:
B
X1
A
S
F
E
H
No. 245 DELUXE CARPET TRIMMER:
Order No. Description
Order No. Description
1245-A
Mounting Bracket
1245-T1
1245-B
Ratchet Handle
1245-U
1245-D
3 Arm Knob Set (3)
1245-V1
1245-E
Base Only
1245-F
Base & Mt. Bracket
1245-X1
Assembly
1245-H
False Bottom
1246-D
1245-S
Carriage Bolt
BLADES INFORMATION:
Use Crain No. 184 or 184C Trimmer Blades
D
V1
T1
U
1246-D
NEW Wall Runner
NEW Runner Pad
NEW Blade Clamp,
Right
NEW Blade Clamp,
Left
Universal Shim
Set (6)
This Carpet Trimmer is guaranteed to be free of defects
in workmanship or quality of materials for a period of
36 months.
Any parts of the tool found to be defective subject
to the guarantee will be replaced at no charge. Credit
in full or part cannot be extended by the distributor, nor
will new tools be given as replacements or loaners.
Tools subject to this warranty must be accompanied
by same, and returned freight PREPAID to Milpitas, CA,
and must be in assembled condition.
CRAIN CUTTER CO., INC.
1155 Wrigley Way, Milpitas, CA 95035
Printed by: HF
GUARANTEE
TELEPHONE (408) 946-6100
FORM F1245-Rev 10/11
INSTRUCTION
MANUAL
FOR
CRAIN
No. 245 DELUXE CARPET TRIMMER
ALL TRIMMERS COVERED BY
U.S. PATENT No. 6,421,923 B1
Made in
America
