OWNER / OPERATOR MANUAL
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
APPLICABLE SERIAL NUMBERS :
DRIVE UNIT 40400101 and up
LINE TRIMMER
BT250
ENGINE UNIT KU40001 and up
WARNING
Before using our products, please
read this manual carefully to
understand the proper use of your
unit.
BT25-00000 (404)
Advertisement
Table of Contents
Related Manuals for RedMax BT250
Summary of Contents for RedMax BT250
-
Page 1: Line Trimmer
California to cause cancer, birth defects or other reproductive harm. APPLICABLE SERIAL NUMBERS : DRIVE UNIT 40400101 and up LINE TRIMMER BT250 Before using our products, please read this manual carefully to understand the proper use of your unit. -
Page 3: Table Of Contents
SAFETY FIRST Instructions contained in warnings within this manual marked with a critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail. ■... -
Page 4: Parts Location
1. Parts location 2. Specifications ■ BT250 Overall size(LxWxH)······················································ 63.0(1600)x13.0(330)x12.0(305) in(mm) Dry weight w/o acc.····························································································· 11.1 lbs (5.05kg) Engine Type······················································································ Air-cooled 2-stroke gasoline Model······································································································ Zenoah GT25N2 Displacement ······················································································· 1.6cu-in (25.4cm Max. output·························································································· 1.2Hp at 8500 rpm Fuel ······················································································· Mixture(Gasoline 50 : Oil 1) Carburetor ···················································································... -
Page 5: Warning Labels On The Machine
3. Warning labels on the machine (1) Read owner's manual before operating this machine. (2) Wear head, eye and ear protection. (3) Warning/Attention (4) Keep all children, bystanders and helpers 15 meters away from the brushcutter IMPORTANT If warning label peel off or become soiled and impossible to read, you should contact the dealer from which you purchased the product to order new labels and affix them in the required location(s). -
Page 6: Symbols On The Machine
4. Symbols on the machine 6 For safe operation and maintenance, symbols are carved in relief on the machine. According to these indications, please be careful not to make a mistake. (a) The port to refuel the "MIX GASOLINE" Position: FUEL TANK CAP (b) The direction A to close the choke The direction B to open the choke... -
Page 7: For Safe Operation
5. For safe operation 1. Read this manual carefully until you completely understand and follow all safety and operating instructions. 2. Keep this manual handy so that you may refer to it later whenever any questions arise. Also note, if you have any questions which cannot be answered herein, contact the dealer from whom you purchased the product. -
Page 8: Working Plan
5. For safe operation 8 b. At night, at times of heavy fog, or at any other times when your field of vision might be limited and it would be difficult to gain a clear view of the working area. c. -
Page 9: Before Starting The Engine
5. For safe operation ■ BEFORE STARTING THE ENGINE 1. The area within a perimeter of 50 feet (15m) of the person using the product should be considered a hazardous area into which no one should enter. If necessary yellow warning rope, warning signs should be placed around the perimeter of the area. -
Page 10: Using The Product
5. For safe operation 10 WARNING Never place the throttle into the high speed position when starting the engine. 3. After starting the engine, check to make sure that the cutting attachment stops rotating when the throttle is moved fully back to its original position. -
Page 11: If Someone Comes
■ HANDLING FUEL 1. The engine of the RedMax product is designed to run on a mixed fuel which contains highly flammable gasoline. Never store cans of fuel or 11 ... - Page 12 5. For safe operation 12 refill the tank of the unit in any place where there is a boiler, stove, wood fire, electrical sparks, welding sparks, or any other source of heat or fire which might ignite the fuel. 2.
-
Page 13: Set Up
6. Set up ■ INSTALLING HANDLE (SE1) • Mount the handle to the shaft tube and clamp it at your best operating position. ■ INSTALLING DEBRIS GUARD (SE2) • Put the debris guard on the shaft tube near the gear box, attach it with the screw, washer and nut provided. -
Page 14: Fuel
3m (10ft) away from the fueling point before starting the engine. • The RedMax engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If RedMax oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle engine use. -
Page 15: Fueling The Unit
7. Fuel again for at least one minute. As some oils may be difficult to agitate depending on oil ingredients, sufficient agitation is necessary for the engine to last long. Be careful that, if the agitation is insufficient, there is an increased danger of early piston seizing due to abnormally lean mixture. -
Page 16: Operation
8. Operation 16 ■ STARTING ENGINE WARNING The cutting head will start rotating upon the engine starts. 1. Rest the unit on a flat, firm place. Keep the cutting head off the ground and clear of surrounding objects as it will start rotating upon starting of the engine. -
Page 17: Stopping Engine
8. Operation ■ STOPPING ENGINE 1. Release the throttle lever and run the engine for a half minute. 2. Shift the ignition switch to the STOP position. NOTE • Except for an emergency, avoid stopping the engine while pulling the throttle lever. ■... - Page 18 8. Operation 18 3. Use a slow, deliberate action to cut heavy growth. The rate of cutting motion will depend on the material being cut. Heavy growth will require slower action than will light growth. 4. Never swing the unit so hard as you are in danger of losing your balance or control of the unit.
-
Page 19: Maintenance
• Never alter the brushcutter or take the engine apart. • When replacing parts, always be sure to use only RedMax products or products which have been certified by RedMax for use with the RedMax brushcutter. • Things to check before using brushcutter. - Page 20 9. Maintenance WIND LINE 20 THIS SIDE UP THIS SIDE UP...
-
Page 21: Air Filter
For a replacement plug, use the correct type specified by RedMax(See SPECIFI- CATIONS on the page 4). (MA3) • When you take off the spark plug, twist (1) and pull off the cap (2). -
Page 22: Spark Arrester
9. Maintenance 22 ■ MUFFLER WARNING • Inspect periodically, the muffler for loose fasteners, any damage or corrosion. If any sign of exhaust leakage is found, do not use the brushcutter and have it repaired immediately. • Note that failing to do so may result in the engine catching on fire. - Page 23 9. Maintenance hours of use for blockage, and remove any waste which has attached itself to the brushcutter. Note that it is necessary to remove the plug guard shown in Figure 20 in order to be able to view the upper part of the cylinder. IMPORTANT •...
-
Page 24: Storage
(exhaust port) ➞ carbon is built-up air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our RedMax service shop in your area. 24 • Aged fuel is one of major causes of engine starting failure. -
Page 25: Parts List
It is also possible that some parts may be available even after the limit of seven (7) years.] APPLICABLE SERIAL NUMBERS : DRIVE UNIT 40400101 and up LINE TRIMMER BT250 ENGINE UNIT KU40001 and up March. 2004 25 ... - Page 26 12. Parts list Fig.1 DRIVE UNIT BT250 (S/N 40400101 and up) 26 ...
- Page 27 Fig.1 DRIVE UNIT BT250 (S/N 40400101 and up) Key# Part Number Description BT25-50810 PIPE COMP. BT25-50710 DRIVE SHAFT BT25-50910 HOUSING ASSY BT25-50610 GRIP BT25-50510 LEVER ASSY BT25-50520 SCREW 1855-82100 CABLE ASSY BT25-80100 TUBE BT25-50400 HANDLE ASSY BT25-50410 • HANDLE 0263-90530 • SCREW 12 B1181-000504 •...
- Page 28 12. Parts list Fig.2 ENGINE UNIT BT250 (S/N KU40001 and up) 28 ...
- Page 29 Fig.2 ENGINE UNIT BT250 (S/N KU40001 and up) Key# Part Number Description 6634401 SCREW 3075406 FRONT HOUSING 6635301 SCREW CLUTCH 6969601 WASHER CURVED 3075603 CLUTCH ASSY 6969501 WASHER PLAIN 6968901 NUT 6457403 ROTOR 4309501 CRANKCASE&SHAFT ASSY 6968501 • BEARING 5987501 • SEAL 9071301 GASKET CASE 6968401 •...
-
Page 30: Limited Warranty
ZENOAH AMERICA INC. AT (770)-381-5147. IMPORTANT: YOU WILL RECEIVE A WARRANTY REGISTRATION CARD AT TIME OF PURCHASE.PLEASE FILL OUT THE CARD AND SEND IT TO RedMax / KOMATSU ZENOA AMERICA WITHIN SEVEN (7) DAYS.BE SURE TO KEEP A COPY FOR YOUR RECORDS. - Page 31 Telles sont les limites de la garantie. Le coût du transport de l'unité jusqu'au revendeur RedMax et depuis celui-ci sera à la charge de l'acheteur. L'acheteur ne supportera pas le coût de main d'oeuvre du diagnostic qui amène à la conclusion qu'une pièce garantie est défectueuse, si ce diagnostic est effectué...
