  • Page 1 Digital Meter Satellite & Terrestrial STM-6000 User manual...
  • Page 2: Table Of Contents

    STM6000 Table of Contents Description ....................... 4 Safety instructions ..................4 Safety of persons....................4 General information ................... 5 Appropriate Usage ..................6 Delivery range ....................6 Device overview....................7 Start of operation..................... 9 Battery ....................... 9 Switch-on the Device ..................9 Lithium-ions-battery..................
  • Page 3 STM6000 Satellite setting .....................22 USB.......................25 Updating and Backup Data................25 Angle calculation ..................28 Spectrum Analyzer ..................29 Technical specifications ................31 Warrenty ......................33 COMBO Meter 3 | EN...
  • Page 4: Description

    Signal strength and quality are displayed as numerical values and bar graphs. Another measurement value is the forward error correction (FEC) and the bit error rate (BER). In addition, the picture quality can be revised on the high-resoluted 3.5-inch TFTLCD screen.
  • Page 5: General Information

    STM6000 General information Attention! The devise should only be operated with the supplied AC adapter at the mains. Do not open the meter or the included AC adapter. There is danger of life through electric shock! Wrong usage of the ports can lead to the destruction of the measuring device.
  • Page 6: Appropriate Usage

    STM6000 Appropriate Usage The measuring device meter was developed to measure signals of digital satellite antennas and satellite systems. It is exclusively for this purpose and should only be used for this purpose. Use the equipment only for the purpose, which is described in this manual. Follow all information in this manual, particularly the safety instructions on page 5.
  • Page 7: Device Overview

    STM6000 Device overview Figure 1: Front of the meter COMBO Meter 7 | EN...
  • Page 8 STM6000 Description LNB-IN Digital satellite signal input LC-Display Display of the TV picture, the menu and the measured values Display of the energy state: POWER-LED Operation: red: the measuring devise is switched on. Off: the measuring devise is switched off. In charge: Green: The battery is charged Red: The battery is full charged...
  • Page 9: Start Of Operation

    STM6000 Start of operation Battery Before the first operation with the measuring device charge the battery completely. (see also chapter “Lithium-Ion battery” on page 11). Load the accumulator during the first loading procedure at least 5 hours. The maximum battery charging time is approximately 12 hours. Switch-on the Device ð...
  • Page 10: Lithium-Ions-Battery

    STM6000 Lithium-ions-battery Explosion danger! Never the two poles (+ and -) connect with each other! Attention! Storing or operating accumulator no more than 40° C. Not burning or damaging accumulator. Not taking accumulator to contact with water. Charging the battery The maximum battery charging time is approximately 12 hours..
  • Page 11: System Setting

    STM6000 System setting è Press the MENU button. è Select the point system setting. è Confirm your selection using the OK button. Figure 2: System setting language Setup Press the SYSTEM button to change the menu language. _ Select the point Language setup. _ Choose your desired language using the ◄...
  • Page 12: Info

    STM6000 INFO Factory Default Press the SYSTEM button to change the menu language. _ Select the point Factory Default. _ Press OK to make the factory setting 12 | EN COMBO-Meter...
  • Page 13 STM6000 .Figure 3: Factory Default COMBO Meter 13 | EN...
  • Page 14: Factory Reset

    STM6000 Factory reset Attention! All programs and settings, configured by you, will be reset to delivery status. Note! After reset to factory default you will have to enter the 14 | EN COMBO-Meter...
  • Page 15: Satellite Finding

    STM6000 Satellite finding In this menu you have the option to search for single channels or using the display for lining a satellite dish up. ð Press the FIND button to display the Satellite Finding menu.. COMBO Meter 15 | EN...
  • Page 16: Finding Channels Manual

    STM6000 Figure 4: Satellite Finding Finding channels manual ð Press the S/S2 FIND button to display the menu satellite finding. ð Press the ◄ - or ► - button to select a satellite.. ð Press the ▼- button to choose between the following points.. ·...
  • Page 17 STM6000 Once a signal is found, the bar graph shows the signal strength and quality. In addition C/N, FEC and a.BER (after BER) are displayed. In addition an acoustic signal is represented. Notice! The satellite call sign (see Figure 4) registers which satellite you receive at the moment.
  • Page 18: T/T2 Finding

    STM6000 T/T2 finding In this menu you have the option to search for single channels or using the display for lining a T/T2 antenna up. ð Press the Menu to choice T/T2 Finer pic to display the T/T2 Finding menu.. Figure 5:T/T2 Finder munu 18 | EN COMBO-Meter...
  • Page 19: Finding Channels Manual

    STM6000 Finding channels manual Figure 6:T/T2 Finding ð Press the T/T2 Finder button to display the menu T/T2 finding. ð Press the ◄ - or ► - button to select Scan method at Manual/Auto.. ð Press the ◄ - or ► - button to select Kind of service at All services/Only free services/Only encrypted services ð...
  • Page 20: Lining T2 Antenna Up

    STM6000 Figue 7:T/T2 Signal info ð Press the ◄ - or ► - button to select the T/T2 frequency ð Press the F1 button to back T/T2 Finder menu ð Press F2 button to screen capture Lining T/T2 antenna up ->...
  • Page 21 STM6000 indicated in general always. ð Set up the satellite antenna exactly to receive the best signal. Notice! The C/N value should amount 6dB at least. Values of 10dB and more are urgently if you liked to have a certain bad weather reserve. Or in the case if the signal about a multicounter should be distributed to several buyers.
  • Page 22: Satellite Setting

    STM6000 Installation Satellite setting _ Press the MENU button to display the main menu. _ Press the ▲- or ▼- button to move the cursor. _ Select the point satellite setup and press the OK button Figure 8:Satellite setup _ Select the point Edit satellites and press the OK button. 22 | EN COMBO-Meter...
  • Page 23 STM6000 Figure 9: Edit satellites ð Select the point Dish Set-up and press OK-button. Figure10: Dish set-up settings _ Press the ▲- or ▼- button to move to the desired item COMBO Meter 23 | EN...
  • Page 24 STM6000 _ Press the ◄ - or ► - button to modify the value of the selected item. Use the NUMERIC buttons if necessary. · Satellite · LNB- · Low L.O.F. · Hight L.O.F. Type · 22K · LNB · DiSEqC-Level ·...
  • Page 25: Usb

    STM6000 _ Press the USB button to display the Updating and Backup Data menu. Figure 11: USB _Press the File viewer to play usb file _ Press the Updating- button or use the updating the sw _ Press the Backup Data to backup data COMBO Meter 25 | EN...
  • Page 26 STM6000 Figure 12: SW upatng Figure 13: Backup Data 26 | EN COMBO-Meter...
  • Page 27 STM6000 COMBO Meter 27 | EN...
  • Page 28: Angle Calculation

    STM6000 Angle calculation _ Press the ANGLE button to display the Calculation menu. _ Press the ◄ - or ► - button or use the NUMERIC keys to change the configuration of the selected menu point. Figure 14: Angle Calculation _ Press the ▲- or ▼- button to select the following points: ·...
  • Page 29: Spectrum Analyzer

    STM6000 Spectrum Analyzer In this menu you can control the transponders over the whole spectrum. ð Choose Spectrum analyzer in the main menu, or Start the Spectrum- analyzer by choosing SPTRUM Figure 15: Spectrum analyzer Adjustment Changes the sampling-frequency between 4MHz und 16MHz Changes between 13V and 18V (horizontal, vertical) ▲...
  • Page 30 STM6000 Disposal Attention! Never throw the receiver and the batteries in normal household waste. They may contain toxic agents that are hazardous to health and environment. Therefore dispose of the device and the batteries immediately according to the prevailing statutory regulations. Never throw the batteries in normal household waste.
  • Page 31: Technical Specifications

    STM6000 Technical specifications LNB/Tuner input F-type connector IEC 169-24 Frequency range 950 MHz ~ 2150 MHz Input level -65 dBm bis -25 dBm LNB power supply 13/18 V, max. 400 mA LNB control signal 22 kHz DiSEqC control Version 1.0 Demodulator Front-end-modul QPSK/8PSK...
  • Page 32 STM6000 Tuner input F-type connector IEC 169-24 Frequency range 110 MHz ~ 862 MHz RF Input/Output impedance: -75W Unbalance Demodulator Front-end-modul QPSK/16QAM/64QAM FFT mode 2K/8K Channel Bandwidth: 6MHz/7MHz/8MHz Corde Rate: 1/2,2/3,3/4,5/6,7/8 Guard Internal: 1/4,1/8,1/16,1/32 SCPC- und MCPC Spectral inversion Auto conversion System resource Processor FUJITSU[MB86H60]...
  • Page 33: Warrenty

    STM6000 Power supply Supply voltage 14 V Li-oN battery 2450 mA Charger 90 – 240 V Supply voltage (charger) 175 - 250 V ~, 50/60 Hz Dimensions Length x width x height Gross-weight 0,5 Kg Temperature Operating temperature 0° C to +40° C Storage temperature -40°...
