headboard bracket installation guide (optional)
A 9/16" (14 mm) & 1/2" (13 mm) socket and crescent wrench are necessary to complete installation.
Headboard Bracket (2)
STEP 1
a.) Align the hole in the bracket to the brass sleeve into which the leg threads. Hold the bracket in place and screw
the leg into the base until it is snug. DO NOT OVERTIGHTEN. Too much force may cause the leg to spin freely.
b) The headboard bracket will have 2 tabs to accomodate any frame type. Align the appropriate tab on the
bracket with the hole on the base. Use a short bolt and nut to secure the bracket. Make sure the bolt is tight.
8
HEADBOARD BRACKET COMPONENTS
T-Bracket (2) Spacer (2) Long Bolt (8) Short Bolt (10) Nut (18)
