with ELECTRO-TOUCH and 1-1/2" x 10" P .A. Rams
Parts indented are included in the carton, bag or assembly under which they are indented.
Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details,
specifications and prices without notice or without incurring any obligation.
Meyer Products LLC
18513 Euclid Ave. • Cleveland, Ohio 44112-1084
Phone 486-1313 (Area Code 216)
www.meyerproducts.com• email info@meyerproducts.com
© 2008 Printed in the U.S.A.
PARTS & INSTALLATION INSTRUCTIONS
E-58H ELECTRO- LIFT
Item Part No. Qty. Description
15988
1
Lift and P.A. Ass'y. (Complete) 12 volt
1
15995
1
• Lift Ass'y. (Unit only) 12 volt
2
15630
1
• E-58H Lift Unit Cover
3
15631
1
• Cover Strap
4
15370
1
• Starter Solenoid - 12 volt
07620
2
• Ram L.H. & R.H. with Hose & Fittings
5
07968
1
•• Ram (1-1/2" x 10")
6
22461
1
•• Hose Ass'y. SAE 1/4 x 38" Lg. M-6 Faceseal
7
22460
1
•• SAE 6 x 90 Degree Elbow
8
22691
1
• Universal Truck Side Harness
9
22692
1
• Plow Side Harness
10
05024
1
• Power Cable - 36"
11
08473
1
• Relief Valve Kit - Reservoir
15787
1
• Hardware Bag
07273
1
•• Tap Connector
12
21398
2
•• S. Tapping Screw 1/4 - 14 x 3/4"
13
21832
1
•• Bushing - Split
21953
1
•• Decal - Danger (Mount on Dashboard)
14
22690
1
• Pistol Grip Controller
08364
1
• Hardware Bag (P.A. Rams)
15
20146
2
•• Bolt H 5/8 - 11 x 3 1/4" Gr. 5
15
20150
2
•• Bolt H 5/8 - 11 x 4 1/2" Gr. 5
16
20309
4
•• Locknut 5/8 - 11
08202
1
• Plug Bracket Kit
17
19607
1
•• Plug Bracket
18
19609
1
•• Plate
19
20027
2
•• Bolt H 5/16-18 x 1 Gr. 2
20
22658
2
•• Bolt H 5/16-18 x 3 Gr. 2
21
20525
4
•• Finish Nut 5/16-18
22
20326
4
•• Lockwasher 5/16
*
08206
1
Complete Coupler Kit *Optional
23
22442
1
• Male P .A. Block Coupler
24
22443
1
• Female Hose Coupler
25
22444
1
• Male Hose Coupler
26
22445
1
• Female P.A. Block Coupler
®
Parts List
