Meyer V-71 QUIK LIFT Parts & Installation Instructions

Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17A
18
19
20
21
22
23
24
25
26
27
28
29
30
Parts indented are included in the carton, bag or assembly under which they are indented.
Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details,
specifications and prices without notice or without incurring any obligation.
© 2011 Printed in the U.S.A.
PARTS & INSTALLATION INSTRUCTIONS
V-71 QUIK LIFT
Part No. Qty.
15130 1 V-71 Lift and P .A. Ass'y. (Complete) 12 volt
15132 1 •V-71 Lift Ass'y. (Unit only) 12 volt
15633 1 •• Cover
05815 1 • Lift Cylinder 1.75 x 8" SAE-6
22883 1 • Hose 1/4 x 22" SAE 6
07713 2 • Double Acting Wing Ram with Fittings & Hoses
05756 2 •• Double Acting Ram 1.25" x 12" SAE-6
22884 2 •• Hose 1/4 x 33" M-6 x Flat Face Seal
22886 2 •• Hose 3/8 x 22" M-6 x Flat Face Seal
22866 4 •• Elbow 90 SAE 6 Face Seal/Adapter
22696 1 • Super Vee Plow Side Harness
22691 1 • Universal Truck Side Harness
05024 1 • Power Cable
22869X 1 • V-71 Controller w/HFP
15370 1 • Starter Solenoid - 12 Volt
08366 1 • Hardware Bag 15130
15634 1 •• Cover Strap
20029 4 •• Bolt H 5/16-18 x 1-1/2" Gr. 2
20049 2 •• Bolt H 3/8-16 x 1" Gr. 2
20152 4 •• Bolt H 5/8-11 x 5" Gr. 5
20153 2 •• Bolt H 5/8-11 x 5-1/2" Gr. 5
20304 4 •• Locknut 5/16-18
20309 4 •• Locknut 5/8-11
20327 2 •• Lockwasher 3/8"
21398 2 •• Self Tapping Screw 1/4-14 x 3/4"
22866 1 •• Elbow 90 SAE 6 Face Seal/Adapter
22868 5 •• Straight Fitting SAE-6 Face Seal/Adapter
08202 1 • Hardware Bag Plug Bracket
19607 1 •• Plug Bracket
19609 1 •• Plate
20027 2 •• Bolt H 5/16-18 x 1 Gr. 2
22658 2 •• Bolt H 5/16-18 x 3 Full Thread Gr. 2
20326 4 •• 5/16 Lockwasher
20525 4 •• 5/16-18 Finish Nut
13333 1 • V-71 Mounting Bracket
15134 3 • M-1 Hydraulic Fluid Quart
®
PART LIST
Description
18513 Euclid Ave. • Cleveland, Ohio 44112-1084
www.meyerproducts.com• email info@meyerproducts.com
Form 1-1031
Meyer Products LLC.
Phone 486-1313 (Area Code 216)
June 2011
