Link-One L1-AW1UHD User Manual page 29

High Power Wireless N150 USB Adapter
Push-Button Configuration(PBC)
For example: If you wish to configure WPS-PBC between your wireless adapter and the router whose SSID is
Link _One_0815.
Follow below instructions:
1. To join a wireless network using WPS hardware button:
a. Enable WPS-PBC on your wireless router. (Press the WPS button on your wireless router or enable PBC
from your router's management UI. For details, see the router's User Guide.)
b. Run Link-One adapter UI and press and hold the WPS button on the side of the adapter for about 2
seconds.
2. To join a wireless network using WPS PBC from Link-One adapter UI:
a) Enable WPS on the router;
b) Configure PBC on the wireless adapter;
Click WPS Profile, select Push-Button Configuration and click Next;
On the appearing dialog box click Start;
29
