Installing the DWL-AG530 Wireless
PCI Adapter in Your Computer
F.
Gently connect the antenna to the
antenna stand.
G.
Finished!
Antenna
802.11a and 802.11b networks
Screw Mount
Link / Activity LEDs
The screw that
Indicates that the card is
secures the
properly installed when
adapter to the
the computer is on and
back of your
blinks when data is being
computer fits
transmitted.
into this slot.
to wirelessly connect to
5
(cont.)
Antenna Cable
connects the DWL-
AG530 PCI board to
the external antenna.
