ADT Pulse MDC835 Installation Manual

ADT Pulse MDC835 Installation Manual

Outdoor mini dome camera
Hide thumbs Also See for MDC835:

Advertisement

ADT Pulse
Interactive Solutions
®
MDC835
Outdoor Mini Dome Camera
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MDC835 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADT Pulse MDC835

  • Page 1 ADT Pulse Interactive Solutions ® MDC835 Outdoor Mini Dome Camera Installation Guide...
  • Page 2: Table Of Contents

    Package Contents .................... 6 CHAPTER 2 BASIC SETUP ............... 7 Installation......................7 CHAPTER 3 ADT PULSE ENROLLMENT ..........9 Using a Wired Connection to Enroll the Camera ........9 Using WPS with PIN to Enroll the Camera ........... 11 CHAPTER 4 CEILING MOUNTING ............15 Ceiling Mounting Installation ..............
  • Page 3: Chapter 1 Introduction

    This chapter provides details of the mini dome camera’s features, components and capabilities. Overview The MDC835 is a wireless, weather-resistant, mini dome camera. It comes with an IP66 rated housing, with a F1.8 large aperture lens, Sony high sensitivity imaging sensor and high power IR LED illumination. The MDC835 displays high quality colorful images in low light conditions, enabling it to view distances of up to 20 meters at night.
  • Page 4: Physical Details

    Chapter 1 Introduction Physical Details Components Figure 1: Camera Components IR LEDs These are used to provide illumination for night time viewing. Ensure that the two IR LEDs are not obstructed beneath the transparent dome bubble. Light Sensor This is a hardware sensor to detect lux. Ensure that the light sensor is not obstructed beneath the transparent dome bubble.
  • Page 5 Chapter 1 Introduction On (Green) – Power on. Status LED (Green, Amber, Off – No power. Blue) Blinking (Green) – The LED blinks during start up or when not connected to the network. On (Blue) – Network connection is available (wired or wireless).
  • Page 6: Package Contents

    Chapter 1 Introduction Package Contents The following items are included: 1. Mini Dome Camera with pigtail (Power and LAN connectors) 2. Power Adapter 3. Wall Mount Screw Package 4. L Tool (T10) 5. Terminal Block 6. Mounting Template Sheet...
  • Page 7: Chapter 2 Basic Setup

    Chapter 2 Basic Setup This chapter provides details for installing and configuring the mini dome camera. Installation 1. Remove Bubble and Protective Foam a. Use the L tool to remove the three retaining screws and bubble. b. Remove the protective foam as shown in the figure below. Note: Leave the bubble detached for later access to the WPS button (Chapter 3) and for ceiling mounting (Chapter 4).
  • Page 8: Mount The Camera

    4. Make the Network Connection Using a Wired Connection If you are using a wired connection to the MDC835, connect a standard Ethernet cable (not included) from the LAN port of the camera cable to the Device LAN port on the Pulse gateway.
  • Page 9: Chapter 3 Adt Pulse Enrollment

    Camera to the gateway via the Pulse Portal or TS Installer App. (2) The second method uses WPS to wirelessly enroll the camera to the gateway via the ADT Pulse Portal or TS Installer App. The WPS method is described beginning on page 11.
  • Page 10 Chapter 3 ADT Pulse Enrollment 7. On the Add Camera screen, enter the camera’s MAC ID. Do not click Continue at this time. 8. Connect an Ethernet cable (not provided) from the RJ45 port on the camera cable to the Device LAN port on the gateway.
  • Page 11: Using Wps With Pin To Enroll The Camera

    Chapter 3 ADT Pulse Enrollment 13. The Cameras screen appears, now displaying the added camera. 14. At the top left of the screen, click Go Back. 15. You are returned to the Manage Devices screen. The total number of installed cameras has increased by one. Click Close.
  • Page 12 Chapter 3 ADT Pulse Enrollment 6. Identify the camera’s PIN number, which is located on the label on the removable protective film covering the dome bubble. 7. Enter the PIN number in the WPS PIN field. 8. Ensure that the camera is powered on and that the Status LED is flashing green.
  • Page 13 Chapter 3 ADT Pulse Enrollment 10. Press and hold the WPS/RESET/Image Flip button on the camera for 5 seconds to establish a wireless connection. The Status LED flashes amber as the gateway attempts to connect to the camera. The wireless connection is successful when the LED turns solid blue.
  • Page 14 Chapter 3 ADT Pulse Enrollment The Pulse enrollment is complete. The newly-added device appears Cameras in the list. 12. At the top left of the screen, click Go Back. 13. Disconnect the camera from power. 14. Install the camera in its final location.
  • Page 15: Chapter 4 Ceiling Mounting

    Ceiling Mounting Installation Ensure that the camera is configured and enrolled in ADT Pulse before permanently mounting it. NOTE 1. Locate an unused indoor outlet to plug in the power adapter. The outlet should be located as close as possible to the location where the camera will be permanently mounted.
  • Page 16 Chapter 4 Ceiling Mounting 4. If using the anchors, insert them into the mounting holes. 5. Align the three mounting holes of the camera stand with the three holes, and then mount the camera stand onto the ceiling using the provided screws.
  • Page 17 Chapter 4 Ceiling Mounting Make sure that the LVDS cable does not cover up or become caught on the antenna. CAUTION Figure 8: LVDS Cable 7. Attach the bubble to the camera, and then secure it using the three screws. Use the alignment marks to properly align the camera and bubble while attaching them together.
  • Page 18 Pulse. Smart IR Function The MDC835 uses a smart IR function for night viewing. This means that the camera automatically adjusts the IR light output and gain. As a result, if any objects are in the close foreground of the image, the camera lowers the IR light output to prevent overexposing those objects.
  • Page 19: Appendix A Specifications

    Appendix A Specifications MDC835 Mini Dome Camera Dimensions (DxH) 4.33” x 3.62” (110mm x 92mm) Lens F1.8. DFOV 75° Video Compression H.264 and MJPEG Image Resolution 16:9 720p (1280x 720), QHD (640x360), VGA (640x480), QVGA (320x240) Mixed Mode (720p, VGA, QVGA) Operating -40°F to 122°F (-40°C to 50°C)
  • Page 20: Regulatory Approvals

    Appendix Regulatory Approvals FCC Statement This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:...
