TIC AVP700 Instruction Manual

680w 6-zone 70v/100v/4-16? commerical mixer amplifer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE ANY FRONT/BACK COVERS OR
PANELS. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL
The lightning flash with an arrowhead symbol, within an equilateral triangle, is intended
to alert the user to the presence of uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN
OR MOISTURE.
SOUND WARNING:
Avoid hearing damage by establishing safe listening volumes. Listening to this product at high volumes
or for extended time periods may cause permanent hearing loss. Protect your hearing by establishing
safe volumes. Start with the volume setting control at its lowest setting. Slowly increase the volume until
you can hear it comfortably and clearly without distortion. Reduce the volume or stop listening if you
experience ringing in your ears or any discomfort. Consult with a physician if needed.
.
680W 6-Zone 70v/100v/4-16Ω
Commerical Mixer Amplifer
AVP700
Instruction Manual
MIC1
MIC2
MIC3
AUX1
MIC1
POWER
CH1
CH2
CH3
CHIME
CH4
CH5
CH6
EMER
BELL
MIN
MAX
MIN
MAX
MIN
MAX
MIN
MAX
VOLUME
VOLUME
AVP700
AUX2
BASS
TREBLE
MIN
MAX
-10
+10
-10
+10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVP700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TIC AVP700

Summary of Contents for TIC AVP700

  • Page 1 The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. AVP700 WARNING: Instruction Manual TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

  • Page 2: Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS: WARRANTY: TIC offers a limited one-year full parts and labor warranty for all of our new products. WARNING: Improper use may potentially cause injury, loss of property and Please visit TIC’s warranty page (http://www.ticcorp.com/warranty/ ) for detail to our /or death.

  • Page 3: Table Of Contents

    AVP700 Overview: TIC AVP-700 is a commerical-grade class A/B power amplifer with constant- voltage options. Table of Content Usage: Designed for broadcasting audio via a constant-voltage distributed sound system or 1. Safety Instructions.................1 high-impedance loudspeaker system. Perfect for public address (PA) and background music.

  • Page 4: Front Panel

    Front panel Rear Panel 7 8 9 AVP700 100V 70V 4-16Ω MIC1 MIC2 MIC3 AUX1 AUX2 BASS TREBLE MIC1 CHIME POWER EMER BELL VOLUME VOLUME Power switch LINE output Zone 1-6 switches & indictators AUX 1 input AUX 2 input...

  • Page 5: Operation

    70V 4-16Ω 100V 4-16Ω AVP700 can be set up in one of four options. Utilizing multiple options simutaneously may Note: cause issues and damage to the amplifier. Please ensure the polarity of speaker wires are 1. Please make sure that the power is turned off during speaker installation. When the power is on, correctly matched and connected.

  • Page 6: Troubleshooting

    Operation instructions: Troubleshooting Step-by-Step Instruction: Symptom Cause & Solution A. Connecting loudspeakers 1. Ensure power switch is at the OFF position. 2. Connect power cord to power soruce outlet. 1. Power source is disconnected or cut. 1. Power does not turn on. 3.
  • Page 7 Connection Diagram...

  • Page 8: Specifications

    Dimensions To keep the amplifier properly ventilated, a space of at least 4" should be cleared around the machine in order to provide enough air circulation and prevent overheating. Model AVP700 Output Power 680W 6-zone 70v, 4-16Ω, 70v, 100v Output Terminals Mic 1-3: 5mV/600Ω...
