Hitachi SB 10S2 Technical Data And Service Manual

100 mm 4" belt sander
Hide thumbs Also See for SB 10S2:
Table of Contents

Advertisement

Quick Links

100 mm (4") BELT SANDER
LIST Nos: SB 10S2: 0363
SB 10V2: 0362
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
SB 10S2
SB 10V2
Mar. 2007
MODELS
SB 10S2
SB 10V2
Hitachi
Power Tools
TECHNICAL DATA
SERVICE MANUAL
AND
S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB 10S2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hitachi SB 10S2

Summary of Contents for Hitachi SB 10S2

  • Page 1 MODELS SB 10S2 SB 10V2 Hitachi Power Tools 100 mm (4”) BELT SANDER TECHNICAL DATA SB 10S2 SERVICE MANUAL SB 10V2 LIST Nos: SB 10S2: 0363 Mar. 2007 SB 10V2: 0362 SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT...
  • Page 2 REMARK: Throughout this TECHNICAL DATA AND SERVICE MANUAL, a symbol(s) is(are) used in the place of company name(s) and model name(s) of our competitor(s). The symbol(s) utilized here is(are) as follows: Competitor Symbols Utilized Company Name Model Name 9401 MAKITA 9404 DW650 DEWALT...

  • Page 3: Table Of Contents

    9-3. Wiring Procedures .......................... 12 9-4. Wiring Diagram ..........................13 9-5. Tightening Torque ...........................14 9-6. Insulation Test ..........................14 9-7. No-load Current Value ........................14 10. STANDARD REPAIR TIME (UNIT) SCHEDULES ..............15 Assembly Diagram for SB 10S2 Assembly Diagram for SB 10V2...

  • Page 4: Product Name

    Hitachi 100 mm (4") Belt Sander, Model SB 10V2 (Variable speed) 2. MARKETING OBJECTIVE The new Models SB 10S2 and SB 10V2 are the upgraded versions of the current Models SB 10T and SB 10V. The key features of the Models SB 10S2 and SB 10V2 are as follows:...

  • Page 5: Selling Point Descriptions

    4-1. Selling Point Descriptions (1) Soft grip handles Each of the handle and the sub handle has a soft grip. The Models SB 10S2 and SB 10V2 are easier to operate than the conventional models and competitors. (2) Clear cover...

  • Page 6: Specifications

    5. SPECIFICATIONS Model SB 10S2/SB 10V2 Capacity 100 mm (4") Power source AC single phase 50/60 Hz Type of motor Single-phase series commutator motor Voltage (V) Current (A) Voltage and current Power input 1,020 W 240 to 420 m/min. (800 to 1,375 ft/min.)

  • Page 7: Specification Comparisons With Similar Products

    6. SPECIFICATION COMPARISONS WITH SIMILAR PRODUCTS HITACHI C1/C2 D1/D2 SB 10S2/SB 10V2 SB 10T/SB 10V 100 x 610 100 x 610 100 x 560 100 x 610 (mm) Belt size (4" x 24") (4" x 24") (4" x 22") (4" x 24")

  • Page 8: Precautions In Sales Promotion

    7. PRECAUTIONS IN SALES PROMOTION In the interest of promoting the safest and most efficient use of the Models SB 10S2 and SB 10V2 Belt Sanders by all of our customers, it is very important that at the time of sale the salesperson carefully ensures that the buyer seriously recognizes the importance of the contents of the Handling Instructions, and fully understands the meaning of the precautions listed on the caution plate attached to each tool.

  • Page 9: Dust Collection

    8. DUST COLLECTION 8-1. Dust Collector This is a system in which the housing is provided with a dust fan on its side so that air pressure from the dust fan causes grinding dust to be drawn in from the inlet and collected in a dust bag. 8-2.

  • Page 10: Precautions In Disassembly And Reassembly

    The [Bold] numbers in the descriptions below correspond to the item numbers in the Parts List and the exploded assembly diagram for the Model SB 10S2, and the <Bold> numbers to those in the Parts List and the exploded assembly diagram for the Model SB 10V2.
  • Page 11 (c) Loosen three Machine Screws M4 x 14 [50] <52> and remove the Gear Cover [54] <56> with Pulley (B) [53] <55>, Ball Bearing 6200VVCMPS2L [55] <57> and Pinion [56] <58>. (d) Hold the Pinion [56] <58> with a vice with care not to damage it, and turn Pulley (B) [53] <55> in a counterclockwise direction with a wrench.
  • Page 12 (3) Removal of the Housing Ass'y [21] <21> and the Body Ass'y [42] <44> (Fig. 3) (a) Loosen the two Machine Screws M4 x 10 [48] <50> and remove the Shoe Plate [63] <65> and the Shoe Cushion [62] <64>. (b) Put a Phillips-head screwdriver through a hole of the Body Ass'y [42] <44>...
  • Page 13 (5) Removal of the Stator Ass'y [11] <11> (Fig. 5) (a) Loosen the three Tapping Screws (W/Flange) D4 x 16 (Black) [29] <29> and remove the Handle Cover [17] <17>. (b) Loosen the Machine Screws (W/Washer) M3.5 x 6 [33] <33> which tighten the lead wires from the Stator Ass'y [11] <11>...

  • Page 14: Reassembly

    9-2. Reassembly Reassembly can be accomplished by following the disassembly procedures in reverse. However, special attention should be given to the following items. (a) Fill the gear cover with Shell Alvania RL3 Grease. (b) Impregnate the felt on the body and the idle pulley with 1.5 cc of Turbine Oil No. 90. (c) When tightening the Tapping Screw (W/Flange) D5 x 45 [15] <15>...

  • Page 15: Wiring Procedures

    Be careful not to crush the lead wires by putting them between the housing and the handle cover. (Figs. 8 (a) and (b)) Switch (E) (1P Screw Type) W/Lock [32] (a) Model SB 10S2 Switch (E) (1P Screw Type) W/Lock <30> Connector 50091 <31>...

  • Page 16: Wiring Diagram

    9-4. Wiring Diagram Wiring should be done in accordance with Figs. 9 (a) and (b). (a) Model SB 10S2 (b) Model SB 10V2 Fig. 9 --- 13 ---...

  • Page 17: Tightening Torque

    9-5. Tightening Torque Tapping Screw (W/Flange) D4 x 16 ..............2.0 0.5 N m (20 5 kgf • • Tapping Screw (W/Flange) D4 x 30 ..............2.0 0.5 N m (20 5 kgf • • Tapping Screw (W/Flange) D5 x 45 ..............2.9 0.5 N m (30 5 kgf...

  • Page 18: Standard Repair Time (Unit) Schedules

    10. STANDARD REPAIR TIME (UNIT) SCHEDULES Variable 60 min. MODEL Fixed Work Flow SB 10S2 Body Ass'y General Assembly Belt Dust Cover Handle Cover Housing Ass'y Pulley (B) Clear Cover Switch (E) Armature Ass'y Belt Cover Shoe Cushion Cord Ball Bearing...
  • Page 19 Variable 60 min. MODEL Fixed Work Flow SB 10V2 Body Ass'y General Assembly Belt Dust Cover Handle Cover Housing Ass'y Pulley (B) Clear Cover Switch (E) Armature Ass'y Belt Cover Shoe Cushion Controller Ball Bearing 6000VV Pinion Shoe Plate Cord Ball Bearing Gear Cover 608VV...

  • Page 20: Belt Sander

    Hitachi Power Tools LIST NO. 0363 ELECTRIC TOOL PARTS LIST BELT SANDER 2007 • • Model SB 10S2 (E1)
  • Page 21 PARTS SB 10S2 ITEM CODE NO. DESCRIPTION REMARKS USED 327-742 PULLEY (A) 600-0VV BALL BEARING 6000VVCMPS2L 327-739 DUST GUIDE 360-797C ARMATURE 110V 360-797U ARMATURE ASS’Y 120V INCLUD. 2, 5 360-797E ARMATURE 220V-230V 360-797F ARMATURE 240V 608-VVM BALL BEARING 608VVC2PS2L 935-196...
  • Page 22 PARTS SB 10S2 ITEM CODE NO. REMARKS DESCRIPTION USED 305-490 TAPPING SCREW (W/FLANGE) D4X30 (BLACK) 327-744 CLEAR COVER 995-578 KNOB NUT 327-780 BODY ASS’Y INCLUD. 57, 61 953-161 WASHER 995-577 SPRING 939-542 RETAINING RING FOR D12 SHAFT (10 PCS.) 995-587...
  • Page 23 STANDARD ACCESSORIES SB 10S2 ITEM CODE NO. DESCRIPTION REMARKS USED 323-011 DUST BAG (BLACK) OPTIONAL ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 995-550 SANDING BELTS 100X610 WA40 (10 PCS.) 995-551 SANDING BELTS 100X610 WA60 (10 PCS.) 995-553 SANDING BELTS 100X610 WA100 (10 PCS.) 995-554 SANDING BELTS 100X610 WA120 (10 PCS.)
  • Page 24 Hitachi Power Tools LIST NO. 0362 ELECTRIC TOOL PARTS LIST BELT SANDER 2007 • • Model SB 10V2 (E1)
  • Page 25 PARTS SB 10V2 ITEM CODE NO. DESCRIPTION REMARKS USED 327-742 PULLEY (A) 600-0VV BALL BEARING 6000VVCMPS2L 327-739 DUST GUIDE 360-797C ARMATURE 110V 360-797U ARMATURE ASS’Y 120V INCLUD. 2, 5 360-797E ARMATURE 220V-230V 360-797F ARMATURE 240V 608-VVM BALL BEARING 608VVC2PS2L 935-196 MACHINE SCREW (W/WASHERS) M4X12 (BLACK) 931-701 BEARING LOCK...
  • Page 26 PARTS SB 10V2 ITEM CODE NO. REMARKS DESCRIPTION USED 325-566 NOISE SUPPRESSOR EXCEPT FOR USA, CAN 953-043 WASHER 953-042 METAL 995-586 IDLE PULLEY ASS’Y INCLUD. 39 305-490 TAPPING SCREW (W/FLANGE) D4X30 (BLACK) 327-744 CLEAR COVER 995-578 KNOB NUT 327-780 BODY ASS’Y INCLUD.
  • Page 27 STANDARD ACCESSORIES SB 10V2 ITEM CODE NO. DESCRIPTION REMARKS USED 323-011 DUST BAG (BLACK) OPTIONAL ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 995-550 SANDING BELTS 100X610 WA40 (10 PCS.) 995-551 SANDING BELTS 100X610 WA60 (10 PCS.) 995-553 SANDING BELTS 100X610 WA100 (10 PCS.) 995-554 SANDING BELTS 100X610 WA120 (10 PCS.) 995-555...
