INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
INSTALLATION AND OPERATION INSTRUCTIONS FOR:
NATURAL GAS MODELS
PROPANE GAS MODELS
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
Installation and service must be performed by a qualified installer, service
Fax: (705)722-6031 Email: ask@napoleon.on.ca
Web: www.napoleon.on.ca
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.33, ANSI Z21.88
VENTED GAS FIREPLACE HEATER
Model CS280 is made up of Model CDVS280 and B-Vent Adapter Kit GS-150KT
FOR YOUR SAFETY
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
agency or the gas supplier.
Wolf Steel Ltd., RR#1, 9 Napoleon Rd.,
Barrie, ON., Canada L4M 4Y8 (705)721-1212
CDVS 280-N
and
CDVS 280-P and
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas suppli-
er's instructions.
• If you cannot reach your gas supplier, call
the fire department.
CS 280-N
CS 280-P
W415-0149 / B / 11.25.09
1
