Page 1 SAMSUNG COLOR LASER PRINTER CLP-510/XBH Basic Model : CLP-510/CLP-510N SERVICE Manual SAMSUNG COLOR LASER PRINTER CONTENTS 1. Precautions 2. Reference Information 3. Specifications 4. Summary of product 5. System Outline 6. Disassembly and Reassembly 7. Alignment and Adjustments 8. Troubleshooting 9.
Page 2: Precautions
High voltages and lasers inside this product are dangerous. This printer should only be serviced by a suitably trained and qualified service engineer. (2) Use only Samsung replacement parts There are no user serviceable parts inside the printer. Do not make any unauthorized changes or additions to the printer, these could cause the printer to malfunction and create electric shock or fire hazards.
Page 3: Caution For Safety
Take care not to cut or damage the power cable or plugs when moving the machine. (9) Use caution during thunder or lightening storms. Samsung recommend that this machine be disconnected from the power source when such weather conditions are expected. Do not touch the machine or the power cord if it is still connected to the wall socket in these weather conditions.
Page 4: Handling Precautions
1.2.4 Assembly / Disassembly Precautions Replace parts carefully, always use Samsung parts. Take care to note the exact location of parts and also cable routing before dismantling any part of the machine. Ensure all parts and cables are replaced correctly.
Page 5: Disregarding This Warning May Cause Bodily Injury
Precautions 1.2.5 Disregarding this warning may cause bodily injury (1) Take care - some parts may be hot. The fuser unit works at a high temperature. Use caution when working on the printer. Wait for the fuser to cool down before disassembly. (2) Take care not to trap fingers or hair.
Page 6: Esd Precautions
Precautions 1.3 ESD Precautions Certain semiconductor devices can be easily damaged by static electricity. Such components are commonly called “Electrostatically Sensitive (ES) Devices”, or ESDs. Examples of typical ESDs are: integrated circuits, some field effect transistors, and semiconductor “chip” components. The techniques outlined below should be followed to help reduce the incidence of component damage caused by static electricity.
Page 7 Precautions MEMO Service Manual...
Page 8: Reference Information
• Brush • Tweezers Standard : For general home use, small type. • Cotton Swab Standard : For general home use, for medical service. • Software (Driver) installation CD ROM Install Driver CD Network S/W CD Service Manual Samsung Electronics...
Page 9: Acronyms And Abbreviations
Enhanced Capability Port Inter Process CommunicationEPP Enhanced parallel Port Engine Control Unit Images Per Minute EEPROM Electronically Erasable Programmable Read Only Memory Image Transfer Belt Electro Magnetic Interference local area network Electro photographic Laser Beam Printer Service Manual Samsung Electronics...
Page 10: Specifications
Second Cassette Feeder/Second Cassette Tray MPF/MPT Multi Purpose Feeder/Multi Purpose Tray SMPS Switching Mode Power Supply Network Interface Card SPGP Samsung Printer Graphic Processor Network Printer Card Samsung Printer Language NVRAM Nonvolatile Random Access Memory SPL-C Samsung Printer Language-Color Organic Photo Conductor...
Page 11: Select A Location For The Printer
• Provide the proper environment : - A firm, level surface - Away from the direct airflow of air conditioners, heaters, or ventilators - Free of extreme fluctuations of temperature, sunlight, or humidity - Clean, dry, and free of dust Service Manual Samsung Electronics...
Page 12: A4 Iso 19752 Standard Pattern
Reference Information 2.4 A4 ISO 19752 Standard Pattern This test page is reproduced at 70% of the normal A4 size Service Manual Samsung Electronics...
Page 13: Wireless Lan
Most of the main wireless networking companies are attending including such companies as Lucent Technologies, Cisco, Intel/Symbol, 3Com, Enterasys (Cabletron), Compaq, IBM, Nokia, Dell, Philips, Samsung Electronics, Sony, Intersil, etc.. This mark certifies mutual compatibility amongst the product of these companies. Wi-Fi (IEEE 802.1) is certified as a standard of the wireless LAN market.
Page 14: General Specifications
Mono : More than 300,000 pages, Color : More than 75,000 pages * Print speed will be affected by Operating System used, computing performance, application software, connecting method, media type, media size and job complexity. * Cardstock/Envelope : Half Speed ** Sound Pressure Level, ISO 7779 Service Manual Samsung Electronics...
Page 15: Controller Specification
Specifications 3.2 Controller Specification Items Descriptions Processor (CPU) Samsung SPGPm (CLOCK SPEED 120Mhz), 32-bit RISC core (ARM 946ES) Memory FLASH ROM (PROGRAM) : 8MB flash *RAM : 64MB (Expandable to 320MB : With Option Option DIMM module : 64/128/256MB 100Pin SDRAM DIMM (Samsung Printer Only)
Page 16 802.11b Wireless LAN - IEEE802.3b support - speed : 11, 5.5, 2 ,1Mbps - WEP : 64bit, 128bit - Operating range : 30m(Indoors) , 100m(Outdoors) SDRAM DIMM - 64,128MB, 256MB 100Pin SDRAM DIMM(Use Samsung Part Only) Service Manual Samsung Electronics...
Page 17: Paper Handling Specifications
3.6.2 Input Capacity Items Descriptions Remarks Cassette(FCT) 250 sheets MP tray Paper 100 sheets Transparencies 30 sheets Envelopes 10 sheets Labels 10 sheets Option Cassette(SCT) 500 sheets 3.6.3 Output Capacity Items Descriptions Remarks Face Down 250 sheets Service Manual Samsung Electronics...
Page 18: Summary Of Product
Summary of product 4. Summary of Product This chapter describes the functions and operating principles of the main components. 4.1 System Structure 4.1.1 Main Parts of System Deve Cover Deve Cover Service Manual Samsung Electronics...
Page 19: Main Drive
Deve Drive Deve Drive PBA Deve Drive PBA Main Drive Main Drive Deve Cover Deve Cover Open S/W Open S/W Duplex Cover Duplex Cover SMPS SMPS Open S/W Open S/W Main Conrtoller PBA Main Conrtoller PBA Service Manual Samsung Electronics...
Page 20 * Capacity : 500 Sheets (Standard paper 75mg/m 20lb) * Paper Size : A4, Letter * Paper Weight (average) : 60~90g/m (16~24lbs) * Paper Type : General Printing Paper * Additional Function : Paper Empty Sensor Service Manual Samsung Electronics...
Page 21 12) LSU This is a core part of LBP. It forms a latent image on the surface of OPC drum using a static charge. * Resolution: Real 600 dpi Service Manual Samsung Electronics...
Page 22 Cleaning Solenoid activates and a cleaning blade removes waste toner from the ITB. Waste toner is transferred to the waste toner tank. The error message "Waste Toner Tank Full/ Not Install" is indicated on the LCD Panel. Replace the Waste Toner Tank immediately or the printer may be damaged Service Manual Samsung Electronics...
Page 23: Main Motor
Forces cold air into the printer and takes out heat from the fuser. Waste Toner Motor Transfers collected waste toner from the OPC drum and ITB to the waste toner tank. (Refer to front view picture on 4-2 page) Service Manual Samsung Electronics...
Page 24 T2 Home clutch This forces the transfer roller into contact with the ITB unit. ITB cleaning solenoid This brings the cleaning blade into contact with the ITB unit Service Manual Samsung Electronics...
Page 25 * Please, refer to the Chap. 7 Arrangement and Adjustment, "Paper Path diagram", for the location of the paper empty sensor, feed sensor, and exit sensor. * Please, refer to page 4-2 for the location of the waste toner sensor, DEVE cover open S/W, and duplex cover open S/W. Service Manual Samsung Electronics...
Page 26 Summary of product 4.1.5 Main Controller PBA Service Manual Samsung Electronics...
Page 27 Summary of Product Service Manual 4-10 Samsung Electronics...
Page 28 - System Bus with SDRAM * Integrated ARM946ES - 32-bit RISC embedded processor core - 16KB instruction cache and 16KB data cache - No Tightly Coupled Memory - Memory Protection Unit & CP15 control program Service Manual 4-11 Samsung Electronics...
Page 29 - 4 Channels are supported - ADC Interface Unit - 3 ADC Channels are available - ADC Core (ADC8MUX8) maximum clock frequency : 3 MHz - Coversion time : 4.3us (@3MHz) - LSU Interface Unit Service Manual 4-12 Samsung Electronics...
Page 30 - Only MultiICE logic support from ARM9 series - 5 JTAG connections : TCK, TnRST, TMS, TDI, TDO - Internal logic for synchronizing TCK and high speed CLK - Maximum TCK frequency : 20MHz (CLK x 1/6) Service Manual 4-13 Samsung Electronics...
Page 31 SODIMM connector. This is a user fit option, DIMMs from 64Mb - 256MB can be used giving a total of up to 320MB of memory. DIMM modules are non standard - only Samsung product should be used. The memory controller is located in the SPGPm controls the SDRAM memory connected using a 32 bit 60 MHz bus.
Page 32 3.3V ± 4% +5V ± 4% +24V + 15%/-10% +24V + 15%/-10% Rated outputting crrunt 2.5A 0.5A Uses MICOM,CMOS MICOM,CMOS MOTOR,FAN MOTOR,FAN LOGIC LOGIC CON4 CON4 CON4 CON3 CON3 CON3 CON1 Fuse CON2 CON1 CON2 Service Manual 4-15 Samsung Electronics...
Page 33 T1,T2 and DEVE processes. For bests quality images these high voltages must be , controlled accurately to maintain the print quality. The high voltages produced are supplied to toner, OPC cartridge, ITB unit, and transfer roller. CHARGER (RED) (BLACK) (RED) SUPPLY (BLACK) CHARGER CHARGER SUPPLY SUPPLY Service Manual 4-16 Samsung Electronics...
Page 34 * Error type: 1. If this voltage is GND, print density is extremely low. 2. If this voltage is floating due to unstable contact point at the HV terminal, density becomes so low as that printing results are not visible to the naked eye. Service Manual 4-17 Samsung Electronics...
Page 35 Summary of Product MEMO Service Manual 4-18 Samsung Electronics...
Page 36: System Outline
* Waste tank sensors: LED type, detects tank present and tank full * OPC drum diameter: 120mm * Power: Main motor (BLDC) * Charging method: Charge roller * Eraser method: LED lamp (+5V/2Pin) * PTL: LED lamp (+5V/2Pin) Service Manual Samsung Electronics...
Page 37 OPC drum surface the charge is reduced to -50V, where the beam is switched off the charge on the OPC surface remains at -600V. In consequence a latent image is formed on the drum surface. Unexposed Expesed Unexposed -600V -600V -50V Polygon Motor Reflecting Mirror (30,000rpm) Service Manual Samsung Electronics...
Page 38 * Toner cartridge order: K, Y, M, C from top. * Developing sequence: Y, M, C, K * Life span: 7K(K) / 5K(C, M, Y) * Power: DEVE motor (BLDC) * Power transmission: Electric clutch * Dot counting method Service Manual Samsung Electronics...
Page 39 Image Transfer to page 6) The image on the page is then fused and the paper is ejected into the output tray. Fusing Cleaning of Image Transfer Belt 3) Toner cartridge empty detection Paper Exit Software Dot count. Service Manual Samsung Electronics...
Page 40 ITB Home Sensor This sensor is used to ensure that each of the 4 color images starts at exactly the same point on the ITB. It works by detecting a fixed point on the belt. Service Manual Samsung Electronics...
Page 41 It is arrayed LED on PCB Board. Main function is improving the T1 utility factor by reducing the adhesive strength of OPC and Toner by irradiation on the OPC Drum formatted the image. Image Transfer Belt (LED) OPC DRUM DUPLEX Image Transfer Roller Service Manual Samsung Electronics...
Page 42 (generated in the HVPS) to a charge removal plate >Type * Transfer method: Semi-conductive roller contact method * Effective transferring range: 218mm (i.e. maximum image length) Image Transfer Belt Charge Removal Bias Image Transfer Roller OPC DRUM Paper HVPS Image Transfer Bias Service Manual Samsung Electronics...
Page 43 * This machine keeps the surface temperature of the fuser unit cover under 180°C, and it has a caution label attached inside the exit cover where it can be easily seen by the user. Service Manual Samsung Electronics...
Page 44: Waste Toner Collection Process
When the waste toner tank is full to the level of the waste toner Waste Toner Sensor sensor, the senor LED light is blocked by waste toner indicating that the tank is full. Waste Toner Tank Waste Toner Tank Waste Toner Tank Waste Toner Tank Service Manual Samsung Electronics...
Page 45 Print Printer performs the actual printing job. Post-Print The finishing state of printing job. The printer puts all systems back into a state ready to start the next job and then enters the Ready state. Service Manual 5-10 Samsung Electronics...
Page 46 * Temperature below 130°C - heat unit fully on, * Temperature above 135°C temperature is controlled by reading the temperature value every 10msec. 3) Cleaning Transfer rollers, OPC and ITB are electrically and mechanically cleaned. Service Manual 5-11 Samsung Electronics...
Page 47 * Paper size, copies, cassette ... * Image pixels, image times, y-offset, x-offset * Flags 9) Check Print mode * Color print mode: - Except legal & OHP/Legal/OHP - Simplex/Duplex * Mono pint mode: Simplex/Duplex/OHP Service Manual 5-12 Samsung Electronics...
Page 48 5.2.6 Post-Print This is the last stage of the printing process. Its functions are described below. a) Clean transfer rollers b) Stop all virtual timers c) Initialize parameters used in the printing process. d) Stop motors Service Manual 5-13 Samsung Electronics...
Page 49 System Outline MEMO Service Manual 5-14 Samsung Electronics...
Page 50: Disassembly And Reassembly
6.4.19 Pick-Up Ass’y ........page(6-44) 6.4.20 Pick-Up Roller replacement ......page(6-46) Service Manual Samsung Electronics...
Page 51: Precautions When Replacing Parts
6.1.1 Precautions when assembling and disassembling * Use only approved Samsung spare parts. Ensure that part number, product name, any voltage, current or temperature rating are correct. Failure to do so could result in damage to the machine, circuit overload, fire or electric shock.
Page 52: Parts For Maintenance And Repair
When a part is replaced it is necessary to reset the 'life used' that is stored in memory. * How to initialize a the value of part's life span: From the control panel, select the following items in order: Menu-Setup - Maintenance - Check other - (Select a desired part) - Reset Service Manual Samsung Electronics...
Page 53: Printer Cleaning
* Do not touch transfer roller when cleaning inside of machine. If transfer roller gets dirty, printing quality could be low. * Please refer to the User Manual for cleaning instructions. Service Manual Samsung Electronics...
Page 54: Information Related To Disassembly And Assembly
(hot water sets the toner). Do not touch the developer roller surface as cont- amination will reduce print quality. Take care not to damage the roller's surface when installing or removing a toner car- tridge. Service Manual Samsung Electronics...
Page 55: Screws Used In The Printer
SCREW-TAPTITE 6003-000152 2*10, GOLD S17 SCREW-TAPTITE 6003-000301 4*6, GOLD SCREW-TAPTITE 6003-000179 3*6, GOLD SCREW-SPICIAL 6009-001396 3*10, BLACK SCREW-TAPTITE 6003-000196 3*10 SILVER S19 SCREW-TAPTITE 6003-000008 4*6, SILVER SCREW-TAPTITE 6003-000266 3*6, GOLD S10 SCREW-ASS’Y MACH 6006-001193 3*6, GOLD Traninung Manual Samsung Electronics...
Page 56: Opening Covers And Replacing Consumable Parts
2) Removing a toner cartridge (K, Y, M, and C) Black Toner Cartridge Yellow Toner Cartridge Margenta Toner Cartridge Cyan Toner Cartridge Caution: * Take care not to damage the rollers. * Keep the toner cartridge on a flat surface. Service Manual Samsung Electronics...
Page 57: Itb Unit
Caution: Before opening the exit over completely open the DEVE cover until it is at right angles to the main frame and the toner cartridges are ejected 4) Remove the ITB unit by releasing the ITB lock levers on both sides of the unit. Lever Lever ITB Unit Service Manual Samsung Electronics...
Page 58 OPC drum surface is not scratched or damaged. Do not touch the surface of the drum when lifting the drum handle or when removing the drum. OPC Drum Caution: The surface of the OPC drum could be damaged if the OPC drum is exposed to direct sunlight for more than 5 minutes. Service Manual Samsung Electronics...
Page 59: Replacing The Waste Toner Tank
2) Lift the hook at the top of the waste toner tank and gently pull the top edge of the waste tank forward. Lift the tank out. PULL Caution: Be careful not to let toner spill from the waste toner tank. Service Manual 6-10 Samsung Electronics...
Page 60 Disassembly and Reassembly 3) Remove the Toner Caps from the side of the tank and fit them to the tank inlets as shown below Toner Cap 4) Fit a new waste toner tank. Service Manual 6-11 Samsung Electronics...
Page 61: Disassembly Procedure
6.4.1 Top cover and Front cover 1) Remove the cassette. Cassette 2) Open all of the covers in the following order:- Duplex cover - DEVE cover - Exit cover (Refer to 6.3.3) Exit Cover Deve Cover Duplex Cover Service Manual 6-12 Samsung Electronics...
Page 62: Top Cover
Disassembly and Reassembly 3) Release 2 screws (4*10 silver). Screw Top Cover Screw 4) Take out the Top Cover as shown below. Service Manual 6-13 Samsung Electronics...
Page 63 PUSH 6) Lift the hook at the top of the waste toner tank and gently pull the top edge of the waste tank forward. Lift the tank out. Caution: Remember to fit the Toner Caps. Service Manual 6-14 Samsung Electronics...
Page 64 Screw 8) Release 2 hooks on the right and the left side with a flat bladed screwdriver and then remove the front cover. Take care to disconnect one harness connected to the frame. Hook Hook Service Manual 6-15 Samsung Electronics...
Page 65 Screw Screw Screw Screw Screw Screw A : OP Panel Screw, 3 X 8 Gold (4EA) B : Panel PBA Screw, 3 X 8 Black (7EA) C : LCD Screw, M2.6 X 6 Gold (1EA) Service Manual 6-16 Samsung Electronics...
Page 66: Rear Cover
C: Bottom 3 EA (4 * 10 Silver) D: Rear 2 EA (3 * 10 Silver) E: NPC(If fitted) 2EA(3 * 10 Silver) Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Service Manual 6-17 Samsung Electronics...
Page 67 Disassembly and Reassembly 2) Take out the Rear Cover as shown below. Service Manual 6-18 Samsung Electronics...
Page 68 2) Remove the duplex cover ass'y by pulling it in the direction shown by the arrows in A and B below. * A: Lift up the left side section. * B: Remove the duplex cover ass'y by pulling the right side section towards the left. Duplex Ass’y Service Manual 6-19 Samsung Electronics...
Page 69 3) Release 4 hooks on the right and left side with a flat bladed screwdriver and then remove the duplex ass'y. Hook Hook Duplex Ass’y Hook Hook 4) Remove the transfer roller by turning the bush on each end of the roller Duplex Ass’y Transfer Roller Service Manual 6-20 Samsung Electronics...
Page 70 Caution: Before opening the exit cover, completely open the DEVE cover until it is at right angles to the main frame and the toner cartridges are ejected 2) Open the exit cover. Exit Cover Push Deve Cover Service Manual 6-21 6-21 Samsung Electronics Samsung Electronics...
Page 71 3) Release 5 screws (3*10 silver) and then remove the harness cover. Harness Cover Screw Screw Screw Screw Screw 4) Remove one harness. Harness 5) Remove the fuser by holding both sides of the fuser and then pulling the fuser upwards. Service Manual 6-22 Samsung Electronics...
Page 72 1) Support the Exit Cover and remove the 2 screws (4*10 Silver) indicated using a long blade screwdriver from inside the OPC cavity. Remove the Exit Cover. Screw Screw Screw Screw 2) Remove the exit cover. Service Manual 6-23 Samsung Electronics...
Page 73 6.4.7 SMPS and Main PBA >> Before disassembling it *Remove the rear cover (Refer to 6.4.3) 1) Release 5 screws (3*6 machine screw, gold) from the main PBA bracket. Screw Screw Screw Main PBA Bracket Screw Screw Service Manual 6-24 Samsung Electronics...
Page 74 1EA (3 * 10 Silver) C: Bottom 1EA (4 * 10 Silver) Screw SMPS Screw Screw Screw 3) Remove 4 harnesses from the SMPS. CON4 CON4 CON4 CON3 CON3 CON3 CON1 CON2 CON1 Fuse CON2 Service Manual 6-25 Samsung Electronics...
Page 75: Main Pba
CN26 BLDC1 CN27 Option : NIC CN28 FUSER_FAN CN29 SMPS CN30 For Test MP_EMPT CN31 MP SOL CN32 FEED CN33 PICK_UP DEVE_DRIVER DEVE_DRIVER CN25 CN16 CN12 CLT_FEED CN23 CN14 LSU SW OPC KEY EMPT CN21 Service Manual 6-26 Samsung Electronics...
Page 76 * Remove the rear cover (Refer to 6.4.3) * Remove the main PBA bracket. (Refer to 6.4.7) 1) Release 3 screws (3*10 silver) remove one harness from the main PBA and then take out the fuser fan. Screw Screw Fuser Fan Screw Service Manual 6-27 Samsung Electronics...
Page 77 * Remove the fuser fan (Refer to 6.4.8) 1) Remove all harnesses from the harness guides. 3) Look inside the OPC drum cavity and locate the T2 cam. Remove the washer using tweezers and then remove the T2 cam. Cam-Drive Washer-Plain Service Manual 6-28 Samsung Electronics...
Page 78 Pin-Drive Gear-Drive Washer-Plain Caution : Please don’t lose the Pin-Drive 5) Remove the motor harness. Release 5 screws (3*10 silver) and then take out the main drive ass'y. Screw Screw Screw Screw Harness Screw Service Manual 6-29 Samsung Electronics...
Page 79 1) Remove one harness from the main PBA HVPS CHARGER SUPPLY CN1(to Deve Driver) <HVPS> <Main PBA> 2) Remove one harness and 4 high-voltage harnesses from the HVPS. Harness Harness Black Black Black Black Harness Service Manual 6-30 Samsung Electronics...
Page 80 Disassembly and Reassembly 3) Remove 5 screws (3*6 machine screw, silver) and then remove the HVPS. Screw Screw Screw Screw Screw Service Manual 6-31 Samsung Electronics...
Page 81 (2 EA 3*6 machine screw, gold: 1 EA 4*10 silver). Screw Screw Guide Harness Bracket Screw 4 x 10 Silver 4 x 10 Silver Ground Harness 4 x 10 Silver 4 x 10 Silver Screw Service Manual 6-32 Samsung Electronics...
Page 82 4) Release 5 screws (3*10 silver) from the DEVE drive ass'y. Remove 4 harnesses connected to the DEVE drive PBA and then remove the DEVE drive ass'y. SUPPLY Screw Screw Screw CLT_4TH Screw CLT_3RD Screw Harness CLT-1ST CLT-2ND Service Manual 6-33 Samsung Electronics...
Page 83 Deve Cover Open S/W 2) Remove all harnesses and 6 screws (3*10 silver) and then take out the DEVE drive PBA. SUPPLY Screw Screw Screw BLCD_DEV SOL-3RD Screw SOL-2ND SOL_1ST SOL_4TH CLT_4TH CLT_3RD Screw Screw CLT-2ND CLT-1ST Service Manual 6-34 Samsung Electronics...
Page 84 Disassembly and Reassembly 3) Remove 4 high-voltage terminals. Terminal Terminal Terminal Terminal Service Manual 6-35 Samsung Electronics...
Page 85 1) Release 4 screws (3*6 gold) and then remove the DEVE drive motor. Screw Screw Screw Screw 2) Unplug one harness from the DEVE drive PBA and then remove the ITB cleaning solenoid. ITB Solenoid Service Manual 6-36 Samsung Electronics...
Page 86 1) Remove 2 screws (3*10 silver) and then remove the DEVE open link guide. Screw Deve Open Link Guide Screw Deve Open Link 2) Separate the DEVE cover by pulling it in the direction of the arrow. Deve Cover Service Manual 6-37 Samsung Electronics...
Page 87: Lsu Unit
Caution : When removing the 4 screws labeled “A” you will need to use a short screwdriver. 2) Release one screw (3*8 yellow). (Use a short length cross-head screwdriver.) LSU Ground LSU Ground LSU Ground Screw Service Manual 6-38 Samsung Electronics...
Page 88 Disassembly and Reassembly 3) Separate 2 harnesses and remove the LSU unit. Harness Harness Service Manual 6-39 Samsung Electronics...
Page 89 1) Separate one harness (CN1) from the Main PBA and one harness(CN2) from the DEVE OEM PBA. Remove 6 screws (3*8 black) and then take out the DEVE OEM PBA. Harness Screw Screw Deve OEM PBA Screw Screw Screw Screw 2) Remove 12 terminals. Terminals Service Manual 6-40 Samsung Electronics...
Page 90 Once the ass'y is released refer to the photograph and remove the ass'y. OPC Lifter Caution: * It is very likely that waste toner will be spilled when removing the waste toner ass'y. Service Manual 6-41 Samsung Electronics...
Page 91 Disassembly and Reassembly 3) Release one screw (3*10 silver) and then remove the sensor cover. Screw Service Manual 6-42 Samsung Electronics...
Page 92 * Disassemble the SMPS & main PBA. (Refer to 6.4.7) 1) Release 4 screws (3*10 silver) Screw Screw Screw Screw 2) Release the 2 clips located underneath the machine (see photograph). Pull the MP Ass'y upward and remove Snap -Fit Snap -Fit Service Manual 6-43 Samsung Electronics...
Page 93 Pick-Up Gear and also remove the gear wheel. Release the shaft retaining bearing. Pick-Up Solenoid Screw Screw 2) Remove the 3 screws (4*10 silver) in the “Pick-up Ass’y” Screw Pick-Up Ass’y Screw Screw Service Manual 6-44 Samsung Electronics...
Page 94 Guide Pick-Up Plate Ground Feed Screw 4) Remove the “ACTUATOR-EMPY (JC72-00465A)” sensor arm and then take out the “Pick-up Ass’y” by lifting the right hand side and sliding the shaft from the frame. Service Manual 6-45 Samsung Electronics...
Page 95 Pick-Up Gear and also remove the gear wheel. Release the shaft retaining bearing and remove it. 2) Remove the paper cassette. Use a vacume cleaner to remove any waste toner from the Waste Toner collectors inside the OPC space. Waste Toner Waste Toner Collectors Collectors Service Manual 6-46 Samsung Electronics...
Page 96 Release the shaft and bush from the end support. Note this support is fragile take great care. Then slide the shaft back away from the frame to remove it. B. Spring B. Spring A Shaft retaining bearing A Shaft retaining bearing C. Bush and Support C. Bush and Support Service Manual 6-47 Samsung Electronics...
Page 97 Disassembly and Reassembly MEMO Service Manual 6-48 Samsung Electronics...
Page 98: Alignment And Adjustments
DEV. - Magenta DEV. - Cyan DEV. - Cyan MPF Path MPT Path Feeder Feeder Pick-up Roller CASSETTE Paper Empty Sensor(MPT) FCT Path SCF Path SCT Path Paper Empty Sensor(SCT) Paper Empty Sensor(FCT) Paper Pick-Up Roller Service Manual Samsung Electronics...
Page 99 * The paper drive motor has been driving for longer than the time needed for the longest paper size and the exit sensor is not off. Service Manual Samsung Electronics...
Page 100 * After pickup, a paper has been fed, but it doesn't reach the feed sensor in a certain time. * Feed sensor is faulty and does not detect paper. Feed Sensor CASSETTE SCF Path MP Empty Sensor Service Manual Samsung Electronics...
Page 101: Jam Removal
- Cassette paper guides not correctly set (loose or too tight). - Foreign object or other contamination of internal paper path and paper guide ribs. - Badly damaged or folded leading or trailing edges of the paper. Service Manual Samsung Electronics...
Page 102 If there is any resistance, and the paper to the slot and slide it into the printer. does not move immediately when you pull, stop pulling and go to step 4. 7. Close the right cover .The printer resumes print- ing. Service Manual Samsung Electronics...
Page 103 To avoid the paper tearing pull it out gently and slowly. NOTE : If the paper tears make sure that all of the paper fragments are removed from the printer. 3.Close the right cover. The printer resumes printing. Service Manual Samsung Electronics...
Page 104 CAUTION : Do not try to close the top cover with the left cover closed. This may cause damage to the machine. 6. Open and close the right cover to resume printing. Service Manual Samsung Electronics...
Page 105 5. Press the top cover release button to unlatch the top cover and open it all the way. Note : If the paper tears make sure that all of the paper fragments are removed from the printer. Service Manual Samsung Electronics...
Page 106 CAUTION : Do not touch the fuser it is hot and could cause burns! The fuser's operating temperature is 180 °C (356 °F). Take care when removing paper from the machine. Service Manual Samsung Electronics...
Page 107 To avoid the paper tearing pull it out 3. Close the right cover. The printer resumes gently and slowly. If there is any resistance, and printing. paper does not move immediately when you pull, stop pulling and continue to step 8. Service Manual 7-10 Samsung Electronics...
Page 108 8.Pull the optional tray, Tray 2, out of the printer. 10. Slide the tray back into the printer and close the two jam covers. 11. Open and close the right cover. The printer resumes printing. Service Manual 7-11 Samsung Electronics...
Page 109: Sample Pattern
Menu. 3. Press the scroll button until you see “Configuration ” on the bottom line. 4. Press the Enter button A demo page showing the printer ’s features and capabilities prints out. Service Manual 7-12 Samsung Electronics...
Page 110: Checking The Remaining Toner And Others
10. Press the Upper Level button to return to step 7 and select a different choice or press it a second time to return to step 6 and choose a different item. 11. To return to the Ready condition press the Upper Level button several times until 'Ready' appears in the display. Service Manual 7-13 Samsung Electronics...
Page 111: Understanding The Control Panel
•The printer is in Power Save mode, using less power.When a print job is received from the computer or if any button is pressed,the printer switches to on-line. •To deactivate the Power Save mode or change the power-saving time. Traninung Manual 7-14 Samsung Electronics...
Page 112 • sends you back to the previous option. • Press to cancel the current print job. • In menu mode,press to return to ready mode. In menu mode,press to go back to the upper menu level. Service Manual 7-15 Samsung Electronics...
Page 113: Using Control Panel Menus
Config. Network Print PS Error Typeface LCD Language Calibration Reset Network Symbol Emulation Custom Color Default Set Lines Power Save Print Net CFG Pitch Auto Continue Jam Recovery Altitude Adj. Auto CR Job Time Out Maintenance Service Manual 7-16 Samsung Electronics...
Page 114: Periodic Defective Image
Developing Roller 35.34 mm horizontal image band ITB(T1) same position in each page black spot Transfer Roller(T2) 75.36 mm ghost Heat Roller 109.9 mm Black spot and ghost, printing backside pollution Service Manual 7-17 Samsung Electronics...
Page 115 Upper Line : Upper Line messages mainly show the current test menu or sub-menu. [Main Menu] or [Function] is displayed. Lower Line : Lower Line messages mainly the current test and status. Buttorns Status Map Display : dispaly the printer status and job in progress. Service Manual 7-18 Samsung Electronics...
Page 116 Feed Clutch T2 Solenoid FCF Solenoid MPF Solenoid SCF Solenoid ITB Solenoid Duplex Solenoid HVPS Test Test Print Interface Test SCF Interface Charger Select Tray Select Pattern Print Pattern Dev DC Print Menu Map Dev AC Service Manual 7-19 Samsung Electronics...
Page 117: How To Operate
Waste Motor Operates Waste Motor Display motor status - "On" or "Off". SCF Motor Operates SCF Motor Display motor status - "On" or "Off". Fan Motor Operates Fan Motor Display motor status - "On" or "Off". Service Manual 7-20 Samsung Electronics...
Page 118: Solenoid Test
Operates SCF pick-up (Only if SCF is fitted) Displays solenoid status - "On" or "Off". ITB Solenoid Operates ITB cleaning Solenoid Displays solenoid status - "On" or "Off". Duplex Solenoid OperateS Duplex Solenoid Displays solenoid status - "On" or "Off". Service Manual 7-21 Samsung Electronics...
Page 119: Sensor Test
"Not Installed" is displayed when either the Waste toner tank is not installed or it is full. "Installed" is displayed when the Waste Toner tank is installed and is not full. Cover Left or Right Cover Sensor Status "Cover Opened" or "Cover Closed" is displayed. Service Manual 7-22 Samsung Electronics...
Page 120 Press the "<" or ">" key until "Interface Test" is displayed. b) Press the "Enter" key to select and run this function. c) "Succeed" or "Failed" is displayed.. d) Pressing the "Upper Level" key again will return to the EDC main menu. Service Manual 7-23 Samsung Electronics...
Page 121 For safety - after printing a test pattern if you need to return to EDC mode turn the printer off and then re-enter EDC Mode by turning power on whilst holding in the "Enter" key. Service Manual 7-24 Samsung Electronics...
Page 122 Duty 35% : -2134V ~ -2266V * The allowed tolerance is commonly +/- 3%, this is the value Displayed, in case of "Dev AC", it is the value of Vpp. * T2 Reverse Bias.(Tolerance : +/-20%) Service Manual 7-25 Samsung Electronics...
Page 123 Alignment & Adjustments MEMO Service Manual 7-26 Samsung Electronics...
Page 124: Troubleshooting
"8.1.1 Basic Check List" OP Panel - No Power - LCD Module - Main PBA Ready Indicate Refer to "Error Message" Power Save "8.5 Error Message" Print Printing Refer to guality is "8.2 Solution of Image Problem" normal? Service Manual Samsung Electronics...
Page 125: Basic Check List
6. Check consumables (toner etc.). •Using the keys print the Information Page. --> Refer to 8.1.4 below and to section 3.5 (Page 3-3) for expected life of various consumable parts, compare this with the figures printed and replace as required Service Manual Samsung Electronics...
Page 126: Initial Inspection
1. Use only paper which is of a suitable quality, weight and size? See the user guide. 4. Check the overall condition of the printer 1. Is the printer properly maintained ? Clean the Paper Transport Passages. Any rollers with dirt surfaces should be cleaned or replaced. Service Manual Samsung Electronics...
Page 127 2. In order to calculate the number of images printed 1 is added to the appropriate counter every 30 seconds. The amount of waste toner is calculated based on the number of pixels in the image. 3. When the user replaces any of the consumable parts and resets the appropriate counter it starts again from 0. Service Manual Samsung Electronics...
Page 128: Solution Of Image Problem
Replace the Toner Cartridge. toner cartridge OPC Drum surface contaminated or damaged. Replace the OPC Drum. ITB Unit belt is contaminated or damaged. Replace the ITB Unit Belt. Fuser Unit is contaminated. Clean or replace the Fuser Unit. Service Manual Samsung Electronics...
Page 129 If problem persists replace the OPC Drum Poor toner transfer to ITB Unit Check and clean ITB Unit contacts. Re-install or replace the ITB Unit. ITB Bias voltage incorrect. Check and clean ITB Unit contact. Replace the HVPS. Service Manual Samsung Electronics...
Page 130 Open the covers, check and clean the Paper Path. Problem transferring intermediate image onto Check and clean T2 roller contacts paper Check T2 Solenoid and cam operation - ensure T2 comes properly into contact when solenoid operates. Service Manual Samsung Electronics...
Page 131 1) Creases : Replace the Guide Input. 2) Replace the Fuser Unit. 3) Check OPC, Drum, Toner Cartridge and ITB Unit for contamination and replace as required. Fault occurs in Duplex Printing only. Replace the Duplex Unit. Service Manual Samsung Electronics...
Page 132 Replace T2 roller - Mark every 29.28 mm Replace Toner cartridge Laser Unit damaged Line repeats every 1~2 mm- Replace the LSU Unit. Damage or contemination of OPC drum Random line spacing- Replace the OPC Drum. Service Manual Samsung Electronics...
Page 133: Paper Feeding Problems And Troubleshooting
Roller with IPA or water. Paper Empty Sensor 4. Check the Feed Sensor is not 4. Replace the main PBA or Sensor. sticking by using the EDC Mode (When “JAM-0” occurs even though the paper feeds into the printer.) Service Manual 8-10 Samsung Electronics...
Page 134 • Check that the Exit unit is assem- bled properly and full functioning 4. If the Exit Sensor is defective. a and replace if necessary. Jam In Exit Area will occur and printing will stop. 4. Replace the Exit Sensor. Service Manual 8-11 Samsung Electronics...
Page 135: Jam Duplex
4. Adjust the Paper Guide and load paper under the adjusted and that paper is poperly loaded. Finger. 5. Influence of Static Electricity. 5. Fan paper before loading to reduce the effects of static electricity. Service Manual 8-12 Samsung Electronics...
Page 136 Exit Roller. 3. If the Bearing - Fuser or Gear - Fuser is damaged or 3. Check the SMPS and Main PBA if the Bearing Gear melted by excessive heat. is melted. Service Manual 8-13 Samsung Electronics...
Page 137 The fuser gears melt and the roller drive fails. Check and Cause Solution 1. The Fuser makes a noise and fails to operate, rollers - Replace the Fuser. may not rotate. - Replace the Main PBA. - Replace the SMPS. Service Manual 8-14 Samsung Electronics...
Page 138: Paper Empty
2. Check the Cover Open sensor, connectors and cable 2. Replace the harness or microswitch as necessary. harness. Ensure that a signal reaches the main PBA 3. Use the EDC mode to test the actuator. 3. Replace the Sensor Board. Service Manual 8-15 Samsung Electronics...
Page 139: Defective Motor
2. Replace cables or LCD Panel Ass'y. Replace the work check the display connectors and cable harness Main PBA. 3. Check if +24VDC or other Power Supplies are shorted 3. Replace the components used for +24VDC. out. Service Manual 8-16 Samsung Electronics...
Page 140 1. Replace the OPC Drum. Image Count value is over 50,000. Image Density may be reduced. It is possible to continue to print one Page at a time by pressing the “On-Line” button when it flashes. Service Manual 8-17 Samsung Electronics...
Page 141: Treatment Of Error Message
5. Check both of the fuser Heat Lamps. --> Replace any faulty lamps. 6. Check the Harness connected to the SMPS and Fuser. --> Refit the harness or replace if damaged. 7. Replace the Main PBA. 8. Replace the SMPS. Service Manual 8-18 Samsung Electronics...
Page 142 5) Check if the Motor Clock is generated at the No. 9 of CN27 on the Main PBA while Main Motor is powered on under the Mode EDC. --> Replace the Main PBA if isn't generated. Service Manual 8-19 Samsung Electronics...
Page 143 *This is caused by a wrong value of OEM Resistor in the OPC Unit. *It is also caused by miss-reading the value of the OEM Resistor because of contamination of the contact points. 1. Check that an original Samsung Drum Cartridge is fitted. --> If not replace the OPC drum.
Page 144 5. If the Clutch does not work check the condition of the cable harness to the Main PBA. 6. Replace the Main PBA if the voltage on Pin 2 of CN32, CN25 on the Main PBA is +24VDC. (Normal Output : Pin 1 = +24VDC, Pin 2 = 0V) Service Manual 8-21 Samsung Electronics...
Page 145 The size of paper in the tray and the size of paper required by the doc- Load [Size] In [Tray] ument being printed are different. *In this case the size of paper and tray is indicated. Load the correct size of paper. Service Manual 8-22 8-22 Samsung Electronics Samsung Electronics...
Page 146 * Press the [On-Line/Continue] button to continue printing. * Replace the ITB Unit when the image quality becomes unacceptable. * You can select if this message will be displayed on the LCD Pane or not. Service Manual 8-23 Samsung Electronics...
Page 147 * This occurs when the value of the OEM Resistor in the ITB Unit is incorrectly detected due to contamination of the contact. 1. Open the Top Cover and then check that the ITB Unit is installed and locked correctly. 2. Clean the contacts on the ITB Unit 3. Replace the ITB unit. Service Manual 8-24 Samsung Electronics...
Page 148 2. Check that the Waste Toner Sensor actuator lever is free and not damaged or distorted. 3. Check the condition of the waste toner sensor cable harness and refit or replace if it is damaged. Service Manual 8-25 Samsung Electronics...
Page 149 Troubleshooting MEMO Service Manual 8-26 Samsung Electronics...
Page 150: Exploded Views And Parts List
This format is used throughout Samsung on all product ranges. Typically it is used for small components and electronic parts. This format is controlled by individual Samsung Divisions and is used on specific products, typically for mechanical parts. Type 2 format part numbers fall into 2 categories: Assemblies consisting of 2 or more parts.
Page 151: Table Of Contents
Content 9.1 Main Exploded View 9.2 Cover Front Exploded View 9.3 Cover Top Exploded View 9.4 Cover Deve Exploded View 9.5 Exit Ass’y Exploded View 9.6 Duplex Ass’y Exploded View 9.7 Deve-Drive Ass’y Exploded View 9.8 Main-Drive Ass’y Exploded View 9.9 Fuser Ass’y Exploded View 9.10 Cassette Ass’y Exploded View 9.11 SCF Cassette Ass’y Exploded View...
Page 152: Main Exploded View
9.1 Main Exploded View...
Page 153: Cover Front Exploded View
9.2 Cover Front Exploded View 12-6 12-4 12-5 12-2 12-3 12-1...
Page 154: Cover Top Exploded View
9.3 Cover Top Exploded View...
Page 155: Cover Deve Exploded View
9.4 Cover Deve Exploded View 11 8...
Page 156: Exit Ass'y Exploded View
9.5 Exit Ass’y Exploded View 11-6 11-3 11-7 11-2 11-22 11-5 11-9 11-10 11-21 11-8 11-S8 11-1 11-4 11-S8 11-13 11-14 11-15 11-16 11-18 11-12 11-17 11-19 11-20-1 11-20 11-20-2 11-11 11-S8...
Page 157: Duplex Ass'y Exploded View
9.6 Duplex Ass’y Exploded View 1-1-29 1-1-8 1-1-6 1-1-10 1-1-9 1-1-7 1-1-28 1-1-1 1-1-5 1-1-16 1-1-3 1-1-14 1-1-11 1-1-2 1-1-22 1-1-15 1-1-10 1-1-20 1-1-16 1-1-21 1-1-4 1-1-14 1-1-19 1-1-15 1-1-26 1-1-31 1-1-12 1-1-16 1-1-23 1-1-13 1-1-32 1-1-24 1-1-25 1-1-12-6 1-1-12-1 1-1-12-8 1-1-12-2 1-1-27...
Page 158: Deve-Drive Ass'y Exploded View
9.7 Deve-Drive Ass’y Exploded View...
Page 159: Main-Drive Ass'y Exploded View
9.8 Main-Drive Ass’y Exploded View...
Page 160: Fuser Ass'y Exploded View
9.9 Fuser Ass’y Exploded View...
Page 161: Cassette Ass'y Exploded View
9.10. Cassette Ass’y Exploded View...
Page 162: Scf Cassette Ass'y Exploded View
9.11. SCF Cassette Ass’y Exploded View...
Page 163: Frame Scf Ass'y Exploded View
9.12. Frame SCF Ass’y Exploded View 3-14 3-13 3-18 3-16 3-13 3-10 3-17 3-11 3-12 3-20 3-13 3-19 3-13 3-15 1-S9 2-S9...
Page 164: Main Frame Exploded View
9.13 Main Frame Exploded View 1-17 1-1-2 1-21 1-10 1-1-5 1-14 1-1-3 1-15 1-1-1 1-1-4 1-20 1-11 1-18 17-2 17-1 17-5 17-6 1-16 17-4 1-12 17-9 17-8 17-7 1-19 17-3 1-13...
Page 165: Front Frame Exploded View
9.14 Front Frame Exploded View...
Page 166: Rear Frame Exploded View
9.15 Rear Frame Exploded View...
Page 167: Base Frame Exploded View
9.16 Base Frame Exploded View...
Page 168: Mp Ass'y Exploded View
9.17 MP Ass’y Exploded View...
Page 169: Pick-Up Ass'y Exploded View
9.18 Pick-up Ass’y Exploded View...
Page 170: Feederass'y Exploded View
9.19 Feeder Ass’y Exploded View...
Page 171: Guide Paper Exploded View
9.20 Guide Paper T2 Ass’y Exploded View...
Page 172: Itb Cam Ass'y Exploded View
9.21 ITB Cam Ass’y Exploded View...
Page 173: Dummy Fuser Base Ass'y Exploded View
9.22 Dummy Fuser Base Ass’y Exploded View...
Page 174 Parts List Parts List(Model code : CLP-510/XBH) SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 9.1 Main 9.1-1 JC96-03189A ELA UNIT-ITB_SET;CLP-510,SEC,XAA,ITB,SET 9.1-2 JC96-03190A ELA UNIT-OPC_SET;CLP-510,SEC,XAA,OPC,SET 9.1-3 JC96-03191B ELA UNIT-DEVE BK_2K;CLP-510,SEC,SEE,DEV 9.1-4 JC96-03194B ELA UNIT-DEVE C_1.5K;CLP-510,SEC,SEE,DEV 9.1-5...
Page 175 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 9.1-45 JC72-01147A PMO-COVER SENSOR BASE;CLP-500,HIPS,BLACK C0013 9.1-48 6502-001093 CABLE CLAMP;DAWS-3NE,ID11*L34.8,-,NYLON6 C0014 9.1-49 JC97-01838A MEA UNIT-LSU CLEANER;CLP-500,SEC,EXPORT, L7026 9.1-49-1 JC64-00093A SHUTTER-LSU CLEANER;CLP-500,PC/ABS,T2.5, C0016 9.1-49-2 JC66-00673A SHAFT-CLEANER;CLP-500,SUM 24L,L229.9,D3. S0007 9.1-49-3 6044-000121 RING-E;ID2,OD5,T0.4,PASS,STSC...
Page 176 JC66-00608A ROLLER-EXIT IDLE;CLP-500,TEFLON,PI10.5,L R0010 9.5-11-18 JC72-20901A PEX-ROLLER EXIT F_UP;ML-5000A,TEFLON,WHI E4091 9.5-11-19 JC70-00375A IPR-GROUND EXIT PLATE;CLP-500,SUS304-3/4 P5050 9.5-11-20 JC97-01410A MEA UNIT-TERMINAL:L;ML-5000A,SAMSUNG,KOR K3637 9.5-11-20-1 JC61-70930A SPRING ETC-HV SMALL;ML-5000A,-,D4.5,-,L4 Z4198 9.5-11-20-2 JC70-40912A ICT-SHAFT HV LARGE;ML-5000A,SWCH18A,-,¥÷ S4027 9.5-11-22 JC61-00974A BRACKET-P-EXIT UPPER;CLP-510,SECC,T0.5,- 9.5-13 JC61-00850A GUIDE-EXIT REAR;CLP-500,PC,T2.0,-,-,BLAC G0007 9.6 Duplex Ass'y...
Page 177 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 9.6-1-1-13 JC70-00368A IPR-BRKT GROUND TR1;CLP-500,SUS304,-,T0. K3276 9.6-1-1-14 JC72-00764A PMO-SHAFT DUP DRIVER;SCX-5100,POM,BLACK, S4079 9.6-1-1-15 JC73-10203A RPR-RUBBER EXIT;ML-80,EDPM RUBBER,-,-,-, E4164 9.6-1-1-16 JG72-40744A PMO-BUSHING TX(B4);CF5700,POM,NTR+WHT(DE 9.6-1-1-17 JC72-40361A PMO-ROLLER_EXIT;SCF(XR),POM,NATURAL,-,M9 R0015 9.6-1-1-18 JC61-70976A SPRING ETC-FUSER EXIT;ML-7000,SUS304-WPB...
Page 178 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 9.7-15 6044-000125 RING-E;ID4,OD9,T0.6,PASS,STSC T2001 9.7-16 JC31-00021A MOTOR DC-MAIN(BLDC);50M8432021,CLP-500,1 M0010 9.7-17 6003-000301 SCREW-TAPTITE;BH,+,S,M4,L6,ZPC(YEL),SWRC 9.7-18 JB70-00168A ICT-PIN ADF;SCX-1110F,STS303,D2.0,-,-,-, A2006 9.7-19 JC66-00465A GEAR-DEVE DRIVE 2_Z20;CLP-500,POM,DE8903 G0545 9.7-20 6031-001255 WASHER-PLAIN;NYLON,CUTTING,ID5,OD9,T0.5, 9.7-21 JF68-10532B LABEL(P)-BAR CODE;CLP-500,-,YUPO PAPER,1...
Page 179 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 9.9-5 6107-001193 SPRING-CS;SUS304-WPB,YEL,PI1.1,D6.1,L19. S0032 9.9-6 JC72-01061A PMO-FUSER UPPER;CLP-500,PET+GF30%,BN9030 F0004 9.9-7 JC72-01062A PMO-FUSER LOWER;CLP-500,PET+GF30%,BN9030 F0005 9.9-8 JC70-00355A IPR-GROUND FUSER;MLC-500,SUS304 CSP 1/2H G0037 9.9-9 JC71-00043A NPR-ELECTRODE AC WIRE;-,CLP-500,C5210P,- E0003 9.9-10 JC71-00047A NPR-ELECTRODE GEAR;-,CLP-500,C5210P,T0.6...
Page 180 O0023 9.13-3-1 JC70-00388A IPR-BRKT LSU;CLP-500,SECC,-,T1.6,-,-,-,- L7020 9.13-3-2 JC72-01169A PMO-LSU BASE;CLP-500,HIPS,BLACK,-,HR-136 L7037 9.13-3-3 JC70-00444A IPR-GROUND LSU;CLP-500,SUS304-1/2H,-,T0. L7022 9.13-3-5 JC75-00049A MEC-TERMINAL;SF-5100,SAMSUNG,IVR K3739 9.13-3-6 JC72-01146A PMO-COVER OEM UPPER;CLP-500,HIPS,BLACK,- Z2643 9.13-3-7 JC39-00229A CBF HARNESS-OPC_FUSE;SCX-5312F,WIRE HARN H0023 9.13-5 JC97-02038A MEA UNIT-BRKT HVPS;CLP-510,SEC,EXPORT,-, 9.13-5-1 JC61-00975A GUIDE-M-HVPS BOARD;CLP-510,HIPS,HB,-,-,- 9.13-5-2...
Page 181 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 9.13-23 JC63-00165A GROUND-FUSER FRAME;CLP-500,SUS304CSP,T0. F2125 9.13-24 JC63-00247A SHEET-ERASER LAMP;CLP-500,PC,T0.5,W220.5 L1033 9.13-25 JC66-00334A GEAR-GEAR FUSER DRV OUTER;SCX-5100,POM,M F4097 9.13-26 JC66-40911A GEAR-DP,IDLE;ML-165,POM,M1.0,Z21,-,WHITE G0198 9.13-27 JC66-40964A GEAR-EXIT,IDLE(Z17);ML-5000,NYLON66,M1.0 E4040 9.13-28 JC61-00984A BUSH-M-D8 L5;CLP-510,POM,ID8.0,OD12.0,L5...
Page 182 9.15-31 JC72-01158A PMO-LINK LOCK OPC;CLP-500,POM,BLACK,-,M9 O0045 9.15-32 JC72-01168A PMO-LOCK ITB;CLP-500,POM,BLACK,-,M90-44, K4045 9.15-33 JC70-00446A IPR-GROUND PAPER GUIDE;CLP-500,SUS304-1/ G2110 9.15-34 JC75-00049A MEC-TERMINAL;SF-5100,SAMSUNG,IVR K3739 9.15-35 JC39-00302A CBF HARNESS-100M_GND;CLP-500,-,-,1 PIN,5 H1015 9.15-36 JC96-02876A ELA UNIT-COVER OPEN SENSOR;CLP-500,SEC,E Z2296 9.15-36A JC61-00706A PLATE-S/W DEVE;CLP-500,SUS304 1/2H,T0.2, P5155 9.15-36B...
Page 183 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 9.16-2 JC97-01755A MEA-PICKUP;CLP-500,SEC,EXPORT,-,-,-,- P2104 9.16-3 JC39-00082A CBF HARNESS-SCF;ML-6060,WIRE HARNESS,UL1 H1227 9.16-4 JC39-00280A CBF HARNESS-SMPS_INLET;CLP-500,WIRE HARN H1252 9.16-5 JC61-00710A PLATE-GUIDE RAIL;CLP-500,SUS304 1/2H,T0. P5140 9.16-6 JC61-40001A FOOT-ML80;ML-80,NBR,-,GRAY,-,-,- F1013 9.16-7 JC63-00167A GROUND-SCF;CLP-500,SECC,T0.8,-,-,-,-...
Page 184 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 9.18-3 JC70-00360B IPR-GUIDE-P-INPUT;CLP-510,SECC,-,T0.5,-, 9.18-6 JC72-00719A PMO-ACTUATOR EMPTY;SCX-5100,-,ABS,BLK,HB K3816 9.18-7 JC72-00729A PMO-SHAFT PICK UP;SCX-5100,PC,BLACK,-,-, P2134 9.18-8 JC72-01076A PMO-GUIDE PAPER;CLP-500,HIPS,BLACK,-,HB, K3913 9.18-9 JC92-01453A PBA SUB-P.EMPTY SENSOR;CLP-500,SEC,-,P.E M0405 9.18-10 JC72-41191A PMO-BEARING SHAFT;ML-6000,POM,BLACK,-,DE...
Page 185 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 9.20-7 JC61-00050A SPRING ETC-ACTUATOR;ML-6060A,SUS304-WPB, Z4132 9.21 ITB Cam Unit 9.21-0 JC96-03216A ELA UNIT-ITB CAM;CLP-510,SEC,EXPORT,ITB I2131 9.21-1 JC72-01154A PMO-DUMMY ITB CAM LOWER;CLP-500,HIPS,BLA D2090 9.2-12 JC96-03242A ELA UNIT-OPE PANEL;CLP-510,SEC,EXPORT,-, Z2649 9.21-2 JC92-01651A PBA SUB-PTL_THER;CLP-510,SEC,KOREA,PTL_T...
Page 186 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92 0501-000457 TR-SMALL SIGNAL;MMBT2222A,NPN,350MW,SOT- 0502-000245 TR-POWER;KSB1151-Y,PNP,1.3W,TO-126,-,16 0502-001048 TR-POWER;KSD1691,NPN,1.3W,TO-126,BK,160 0601-000353 LED;ROUND,RED/Y-GRN,5mm,630/570nm 0601-001138 LED-IR;ROUND,5mm,150mW,4V,950nm,BK 0601-001383 LED;ROUND,RED,3.0MM,700NM 0601-001444 LED;SMD,GRN,1MM,560NM,3X1.5X1.4MM 0603-001021 PHOTO TR;NPN,20V,5V,20mA,75mW,TP 0604-001154 PHOTO-INTERRUPTER;TR,0.2-1.0MA,80MW,DIP, 0604-001257 PHOTO-INTERRUPTER;TR,-,-,DIP-4,BK 0803-001097 IC-TTL;7407,BUFFER/DRIVER,DIP,14,300MIL, 0803-001393 IC-TTL;7407,BUFFER/DRIVER,SOP,14,150MIL, 0803-003263 IC-CMOS LOGIC;74LCX07,HEX BUFFER,SOIC,14...
Page 187 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 2007-000608 R-CHIP;240ohm,5%,1/10W,TP,1608 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 2007-000736 R-CHIP;30Kohm,1%,1/10W,TP,1608 2007-000839 R-CHIP;39ohm,5%,1/10W,TP,1608 2007-000842 R-CHIP;3Kohm,1%,1/10W,TP,1608 2007-000939 R-CHIP;47Kohm,1%,1/10W,TP,1608 2007-000965 R-CHIP;5.1Kohm,5%,1/10W,TP,1608 2007-001002 R-CHIP;510ohm,5%,1/10W,TP,1608 2007-001044 R-CHIP;56ohm,5%,1/10W,TP,1608 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608...
Page 188 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 3301-001240 BEAD-SMD;120ohm,1.6x0.8x0.8mm,200mA,TP,- 3301-001258 BEAD-SMD;600ohm,1608,100mA,,,,1.8ohm 3301-001594 BEAD-SMD;90ohm,2.0*1.2*1.3mm,-,TP,-,-,- 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST 3702-001121 CONNECTOR-RIBBON;60P,MALE,STRAIGHT,AUF 3704-000349 SOCKET-IC;8P,DIP,SN,2.54MM 3708-001408 CONNECTOR-FPC/FFC/PIC;12P,1MM,STRAIGHT,S 3709-001131 CONNECTOR-CARD EDGE;100P,1.27MM,STRAIGHT 3711-000164 CONNECTOR-HEADER;1WALL,2P,1R,2.5mm,STRAI 3711-000198 CONNECTOR-HEADER;1WALL,3P,1R,2.5mm,STRAI 3711-000225 CONNECTOR-HEADER;1WALL,4P,1R,2.5mm,STRAI 3711-002000 CONNECTOR-HEADER;BOX,18P,2R,2mm,STRAIGHT 3711-002003 CONNECTOR-HEADER;BOX,26P,2R,2mm,STRAIGHT 3711-002808 CONNECTOR-HEADER;BOX,7P,1R,2mm,STRAIGHT, 3711-002809 CONNECTOR-HEADER;BOX,8P,1R,2mm,STRAIGHT,...
Page 189 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location 6902-000606 BAG CONDUCTIVE;PE+CARBON,T0.1,W305,L475, 6902-000655 BAG PE;HDPE,T0.03,W800,L1300,TRP,28,6M T JB13-00004A IC ASIC-OPE;SF-3100,HT48C5,SSOP,48P,16.1 JB68-00072A LABEL(R)-BAR RIBON;SF-3000,PY,80X91000,T JB68-00073A LABEL(R)-BAR CODE;SF-3000,PY,38X6.5,T0.1 JB68-00916A LABEL RATING-BLANK;SF-340,SEC,TETRON,0.0 JB75-10028A MEC-RIBBON BARCODE S;-,-,PW-2,PI1, D4.9, JB75-10029A MEC-RIBBON BARCODE S;COLUMBUS,KISCOM,BLK JC02-00017A TONER-GRINDED BLACK;CLP-500,SA-79EK-B,BL JC02-00018A TONER-GRINDED YELLOW;CLP-500,SA-79EK-Y,Y...
Page 190 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location JC61-00839A BLADE-CLEANING;CLP-500,URETHAN,TRP,W15*L JC61-00869A FRAME-M-DRAWER CONNECTOR;CLP-500,PET+GF3 JC61-00977A HOLDER-M-TR REAR;CLP-510,POM,-,-,-,BLACK JC61-00980A HOLDER-M-SHAFT_OPC;CLP-510,POM,5,16,PI 1 JC61-00981A GUIDE-M-BRACKET_C;CLP-510,ABS,4,4.4,239. JC61-00982A BRACKET-P-SEAL_C;CLP-510,SECC,0.8,239.6, JC61-00983A BUSH-TR;CLP-510,BRONZE+ST,ID6.0,OD10.0,L JC61-00985A BRACKET-P-SEAL_BK;CLP-510,SECC,0.8,239.6 JC61-00986A GUIDE-M-BRACKET_BK;CLP-510,ABS,4,6,239.6 JC61-00989A STOPPER-M-ITB SPACER F/R;CLP-510,ABS,V0, JC61-00989B STOPPER-M_REAR;CLP-510,ABS,V0,T3.0,-,-,G JC62-00091A SEAL-MANUAL SHEET;CLP-500,PE FOAM,-,T=10 JC62-00092A SEAL-SIDE BLADE DEVE;CLP-500,PE FOAM,-,T...
Page 191 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location JC63-00241A SHEET-ITB BLADE;CLP-500,PE SHEET,T=0.2,W JC63-00248A SHEET-HV HARNESS;CLP-500,PC,T0.5,W33.5,L H1336 JC63-00278A SHEET-REAR BLACK;CLP-500,PET FILM,T0.054 JC63-00279A SHEET-REAR COLOR;CLP-500,PET FILM,T0.054 JC63-00280A SHEET-RECYCLE BLACK;CLP-500,PET FILM,T0. JC63-00281A SHEET-RECYCLE COLOR;CLP-500,PP FILM,T0.1 JC63-00282A SHEET-SUPPLY COLOR;CLP-500,URETHANE SHEE JC63-00283A SHEET-TONER RECYCLE;CLP-500,PET FILM,T0.
Page 192 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location JC68-01228A LABEL(P)-OPC NOTICE;CLP-500,-,YOPO PAPER JC68-01229A LABEL(R)-COLOR YELLOW;CLP-500,-,FASCAL40 JC68-01230A LABEL(R)-COLOR CYAN;CLP-500,-,FASCAL400P JC68-01231A LABEL(R)-COLOR MAGENTA;CLP-500,-,FASCAL4 JC68-01428A MANUAL-QIG;CLP-510,SEE,16 LANGUAGE,GERMA JC68-01483A MANUAL-SHEET ITB;CLP-510,SEC,ENGLISH,-,A JC68-01484A MANUAL-QRG;CLP-510,XEROX,EN+FR+IT+GE+SP+ JC68-01488A MANUAL-DOC POCKET;CLP-510,SEC,ENGLISH,U. JC68-10914D LABEL(P)-SERIAL NO;ML-85,ART,70X15,G100, JC68-10914E LABEL SERIAL-YELLOW;CLP-510,SEC,ART,0.1, JC68-10914F LABEL SERIAL-CYAN;CLP-510,SEC,ART,0.1,70...
Page 193 Parts List SA : Service Available, SNA : Service not Available Draw# Part Code Description Location JC72-01031A PMO-ITB BUSH GUIDE CF;CLP-500,POM,WHITE, JC72-01032A PMO-ITB BUSH GUIDE CR;CLP-500,POM,WHITE, JC72-01034A PMO-ITB BUSH GUIDE DR;CLP-500,POM,BLACK, JC72-01035A PMO-ITB BUSH NIP R;CLP-500,POM,BLACK,-,M JC72-01036A PMO-ITB BUSH T1;CLP-500,POM,BLACK,-,DE85 JC72-01037A PMO-ITB BUSH TENSION;CLP-500,POM,BLACK,- JC72-01038A PMO-ITB COVER LOWER;CLP-500,ABS+GF20%,BL JC72-01039A PMO-ITB COVER MAIN;CLP-500,ABS+GF20%,BLA...
Page 194 JC97-01820A MEA UNIT-SUS BLADE COLOR;CLP-500,-,SECC+ JC97-01821A MEA UNIT-WASTE TONER TANK;CLP-500,SEC,EX T2130 JC97-01828A MEA UNIT-DUPLEX;CLP-500,SEC,EXPORT,-,-,- D0010 JC97-01835A MEA UNIT-CLEANING BLADE;CLP-500,OPC,SECC JC97-01836A MEA UNIT-CLEANING BLADE;CLP-500,ITB,SECC JC97-01874A MEA UNIT-OPC FLANGE;CLP-500,SEC,OPC FLAN JC99-01744Q INA-ACCESSORY(XAA);CLP-510/XAA,SAMSUNG,A JC99-01810A PAA MAIN-PACKING;CLP-510,SAMSUNG,EXPORT, JC99-01813A INA-ACCESSORY(XAA);CLP-510/XAA,SAMSUNG,A JC99-01824J PAA-LABEL_XBH;CLP-510/XBH,SAMSUNG,BIGBAN JG07-20001A LCD;SF4000,UC-162937-TNAR5-A,BLK/G L3015 JK72-00058A PCT-SILP WASHER;SRP-350,P.A+GRAPHITE,T0.
Page 195: Block Diagram
Block Diagram 10. Block Diagram Service Manual 10-1 Samsung Electronics...
Page 196: Connection Diagram
Connection Diagram 11. Connection Diagram Service Manual 11-1 Samsung Electronics...
Page 197 CONNECTION DIAGRAM Service Manual 11-2 Samsung Electronics...
Page 198 Connection Diagram Service Manual 11-3 Samsung Electronics...
Page 199 CONNECTION DIAGRAM Service Manual 11-4 Samsung Electronics...
Page 200 Connection Diagram Service Manual 11-5 Samsung Electronics...
Page 201 CONNECTION DIAGRAM Service Manual 11-6 Samsung Electronics...
Page 202 Connection Diagram Service Manual 11-7 Samsung Electronics...
Page 203 CONNECTION DIAGRAM Service Manual 11-8 Samsung Electronics...
Page 204 DGND BG_A19 3.3V BG_A20 +3.3V STS104B 1203-002220 3_3V2 +3.3V 1.8V 2901-001178 DGND STS104B 2007-007004|R1608_RES CONFIDENTIAL LD1117DT ’04.09.02 DATE C200 SAMSUNG ELECTRONICS 100uF 470uF 470uF 100nF SIGN 100nF 100nF 100nF 100nF 100nF 100nF 100nF 100nF 100nF 100nF 100nF 100nF 100nF 100nF...
Page 205 DGND DGND DGND 1203-002233|sot_23_R 2804-001568 3301-000325|R3225_BEAD RESERVED DGND DGND DGND [ VCLK SYSCLK ] [ RESET ] CONFIDENTIAL ’04.09.02 DATE SAMSUNG ELECTRONICS SIGN Size: ARP. S.D AN TITLE: Bingbang Plus CHK: C.B.LEE MAIN ENG. C.B.LEE Rev 1.0 DRW. C.B.LEE Page: RESET &...
Page 206 VSSQ1 +3.3V VSSQ2 100nF 100nF 100nF DGND DGND SD_CLK0 VSSQ3 D_CLKE VSSQ4 CONFIDENTIAL K4S561632B-TC1L DGND ’04.09.02 DATE 1105-001384 SAMSUNG ELECTRONICS 100nF SIGN Size: ARP. S.D AN TITLE: M93C86-WBN6T DGND Bingbang Plus 100pF 100pF 100pF 100pF 1103-001328 CHK: C.B.LEE MAIN ENG.
Page 207 RA11 1/16W S_DATA(16) DATA(16) S_DATA(17) DATA(17) DATA(18) S_DATA(18) S_DATA(19) DATA(19) 3702-001121 2011-001094 DGND DGND CONFIDENTIAL ’04.09.02 DATE SAMSUNG ELECTRONICS SIGN * FACTORY OPTION Size: ARP. S.D AN TITLE: Bingbang Plus CHK: C.B.LEE MAIN ENG. C.B.LEE Rev 1.0 DRW. C.B.LEE Page:...
Page 208 C276 C277 C267 C268 2.2uF 2.2uF 100nF 100nF 100nF 100nF 100nF 2.2uF 2.2uF 100nF 100nF CONFIDENTIAL ’04.09.02 DATE SAMSUNG ELECTRONICS DGND SIGN AGND_USB DGND Size: AGND_USB ARP. S.D AN TITLE: Bingbang Plus CHK: C.B.LEE MAIN ENG. C.B.LEE Rev 1.0 DRW.
Page 209 DGND +3.3V MMBT2222ALT1 0501-000457 MMBT2222ALT1 R225 DGND DGND CLP-511/511G ONLY LED5 0601-001444 SLS-NNGR202TS R182 TEST_LED1 CONFIDENTIAL ’04.09.02 DATE SAMSUNG ELECTRONICS DGND SIGN Size: ARP. S.D AN TITLE: Bingbang Plus CHK: AGND C.B.LEE DGND MAIN ENG. C.B.LEE 3301-000325|R3225_BEAD Rev 1.0 DRW.
Page 210 ENB_DEVE_AC ENB_T2 nLDON_LSU R123 nVDO_LSU nCUT_OPC nSH_LSU CRUM_SEL1 CLK_SCF CRUM_SEL0 CMD_SCF STS_SCF CONFIDENTIAL C128 DATE ’04.09.02 nCLT_DEV_1ST SAMSUNG ELECTRONICS 100pF nCLT_DEV_2ND SIGN nCLT_DEV_3RD nCLT_DEV_4TH Size: ARP. S.D AN TITLE: DGND nSOL_DEV_1ST Bingbang Plus CHK: nSOL_DEV_2ND Y.S EOM nSOL_DEV_3RD MAIN ENG.
Page 211 DGND 10nF U22-5 R150 DM7407MX DGND R244 DGND nSTART_LSU C296 10nF DGND AGND CONFIDENTIAL +24V ’04.09.02 DATE SAMSUNG ELECTRONICS SIGN Size: ARP. S.D AN TITLE: 100nF 100uF Bingbang Plus CHK: Y.S EOM MAIN ENG. Y.S EOM AGND Rev 1.0 DRW.
Page 212 A_WST_AGT B600 DEVE_CRUM_SCL B600 DEVE_CRUM_SDA C197 C251 C252 C243 C291 C285 CONFIDENTIAL 10nF 100nF 100nF nFUSERON ’04.09.02 DATE SAMSUNG ELECTRONICS C171 C182 SIGN 470uF DGND DGND DGND 100nF Size: DGND AGND ARP. S.D AN TITLE: 3711-002003 Bingbang Plus CHK: Y.S EOM MAIN ENG.
Page 213 R171 U26-4 1.2K nFAN_FUSER_ON R180 nFAN_FUSER MMBT2222ALT1 0501-000457 C209 74LCX06M 100nF 0803-003264 R179 5.1K CONFIDENTIAL ’04.09.02 DATE SAMSUNG ELECTRONICS AGND AGND DGND SIGN Size: ARP. S.D AN TITLE: Bingbang Plus CHK: Y.S EOM MAIN ENG. Y.S EOM Rev 1.0 DRW.
Page 214 10nF C150 C290 10nF DGND DGND 100nF 3711-000225 3711-003410 DGND DGND DGND CONFIDENTIAL ’04.09.02 DATE SAMSUNG ELECTRONICS SIGN Size: ARP. S.D AN TITLE: CHK: Bingbang Plus Y.S EOM MAIN ENG. Y.S EOM Rev 0.21 Y.S EOM DRW. Page: REV:...
Page 215 C215 3711-000198 100nF R189 C173 74LCX06M 5.6K 100nF 0803-003264 AGND AGND CONFIDENTIAL ’04.09.02 DATE DGND SAMSUNG ELECTRONICS SIGN Size: ARP. S.D AN TITLE: Bingbang Plus CHK: Y.S EOM MAIN ENG. Y.S EOM Rev 1.0 DRW. Y.S EOM Page: SOLENOID...
Page 216 INSTPAR INSTPAR 10nF ITB_CRUM_SCL 3301-001258 30K,1% 2007-000736 3301-001240|R1608_BEAD C168 INSTPAR ITB_CRUM_SDA GNDA GNDA CONFIDENTIAL ’04.09.02 DATE SAMSUNG ELECTRONICS SIGN Size: ARP. S.D AN TITLE: Bingbang Plus CHK: Y.S EOM MAIN ENG. Y.S EOM Rev 1.0 DRW. Y.S EOM Page: ANALOG...
Page 217 AN_MUX2 100nF AN_READ_T2 AN_READ_T1 R332 GNDA nS_TONER_RX AN_WST_AGT ADC0 CONFIDENTIAL A_TEMP ADC1 A_TEMP2 ADC2 ’04.09.02 DATE SAMSUNG ELECTRONICS SIGN Size: S.D AN ARP. TITLE: 1001-000170 Bingbang Plus CHK: Y.S EOM MAIN ENG. Y.S EOM GNDA GNDA Rev 1.0 Y.S EOM DRW.
Page 218 INSTPAR DGND ITB_SCL_OUT ITB_CRUM_SCL DEVE_SDA_OUT 3301-001240|R1608_BEAD C246 DGND DGND DGND U23-6 CONFIDENTIAL DA204K 74LCX07M ’04.09.02 DATE INSTPAR SAMSUNG ELECTRONICS DEVE_SCL_OUT DEVE_CRUM_SCL SIGN 3301-001240|R1608_BEAD Size: C244 ARP. S.D AN TITLE: Bingbang Plus CHK: Y.S EOM MAIN ENG. Y.S EOM Rev 1.0 DGND DRW.
Page 219 C319 10nF DGND DGND DGND U28-4 U28-3 74LCX07M 74LCX07M DGND R330 BLDC_CLK2 CONFIDENTIAL C262 ’04.09.02 DATE SAMSUNG ELECTRONICS SIGN Size: ARP. S.D AN TITLE: DGND DGND Bingbang Plus CHK: Y.S EOM MAIN ENG. Y.S EOM Rev 1.0 DRW. Y.S EOM...
Page 225 Bigbang-v1 Power Supply 1/2W100mJ +24V 9.10 1.5A 200V20A L3-1 CON3 1/2W40mJ 250V4A +24VF L5856 3.5A 1.2.3.4 1W22J 200V1A 1/4W1KJ 104K 1KV222K 4.7KJ 1/4W AR2 1KV PC3-2 BTA12-600B 1KV102K 1W6.8J 15.16 250V8A 1W560KJ 250V5A L5858 L5861 600V5A CON1 13SP10 50V1uF 13.14 1W22J TNR1 510J...
Page 226 1/2W100mJ +24V 9.10 1.5A 200V20A L3-1 Bigbang-v2 Power Supply CON3 250V4A +24VF 3.5A L5856 1/2W40mJ 1.2.3.4 1W22J 200V1A 1/4W1KJ 104K 1KV222K 4.7KJ 1/4W AR2 1KV 1KV102K PC3-2 BTA12-600B 1W6.8J 15.16 L5857 250V8A 1W560KJ 250V5A L5842 0610V 600V5A CON1 13SP10 1W22J 50V1uF 13.14 TNR1...
Page 227 1/2W100mJ +24V 9.10 1.5A 200V20A L3-1 Bigbang-v2c Power Supply CON3 250V4A +24VF 3.5A L5856 1/2W40mJ 1.2.3.4 1W22J 200V1A 1/4W1KJ 104K 1KV222K 4.7KJ 1/4W AR2 1KV 1KV102K PC3-2 BTA12-600B 1W6.8J 15.16 L5857 250V8A 1W560KJ 250V5A L5842 0610V 600V5A CON1 13SP10 50V1uF 13.14 1W22J TNR1...
Page 228 * This Service Manual is a property of Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable International and/or domestic law. * This service manual is also provided on the web, © Samsung Electronics Co.,Ltd. May 2005 the ITSELF system f Samsung Electronics Co., Ltd.
