SoftBank 303ZT User Manual

Pocket WiFi 303ZT
Only for Domestic
◆Contact
03-6812-1288
Phone Number :
e-mail : info@luckywifi.net
*Customer is responsible for the charge for a telephone call.
*Before contact us, please read trouble shooting on the reverse side.
◆Return Address
Terralink Inc.
Meisho MG building 8F, 1-47-1 Higashi Ikebukuro,
Toshima-ku, Tokyo, 170-0013, Japan
◆Extend Rental period
・ You can apply online with Rental Extension to extend your rental period.
・ We apologize for not being able to comply with your extension request
over the phone.
◆Power on / off
■Power on
■Slide to on ■
1
■Flick up
2
OK appears.
■Tap "OK" button
3
Home screen appears.
*When lock screen appears, tap the lock icon.
Screen is unlocked and Home screen appears.
◆Parts and Functions
Display
1
1
External Device Port
2
3
Connect Micro USB Cable and AC charger (optional accessory)
2
USIM Card Tray
3
Battery cover
4
4
Lock Button
5
Turn Display on / off
6
5
Power Switch
6
Power on / off
Reset Button
7
Press five seconds or more with a pointed object to reset
settings to defaults.
7
◆Wi-Fi
a/b/g/n/ac
◆Communication Speed
Down Max 187.5Mbps
Up Max 37.5Mbps
◆Battery hours
approximately 9 hours
◆Number of concurrent
devices
Max 14 devices
(Weekday 10am-6pm)
■Power off
■Slide to off
1
◆Touchscreen Operations
■How to use Touchscreen
WiFi router Display is a touch screen. Tap and flick to operate it.
Tap
Tap item or key to open or
execute function operation.
◆SSID and Security Key
■Tap SSID
1
1
Introduction appears.
■Flick up
2
SSID and Security key appears.
◆Home screen
Levels of mobile networks connected
1
Strong
Weak
No Service
Roaming
Network operator name
2
Network name
3
Levels of Internet Wi-Fi connected
4
Strong
Weak
Status of Internet connected
5
Connected
Not connected
Software update notification
6
◆Charging
■Micro USB cable
Insert Micro USB cable ( Micro USB plug )
into External Device Port and Micro USB
Cable to a PC.
Flick
Flick to toggle
sheets, pages, etc.
※Two SSID are set to Wi-Fi router. Respective WPA
Security keys for SSID A and B are in Wi-Fi
router at the time of purchase.
・ Remove Battery from Wi-Fi router to check
default SSID and the security key.
・ If Wi-Fi router s SSID is changed, new SSID and
Security key are shown.
・ SSID B is not available at the time of purchase.
Limitation
7
Advance notice of communication speed
slowdown
Start of communication speed slowdown
Release of communication speed
slowdown
Unread notification
8
Battery
9
Battery charged
Battery low
Battery almost empty
Charging
Touch menu icons
10
Touch menu icons for various functions
Page indicator
11
Indicators which Home screen page you are in
■AC charger
Insert AC charger Micro USB plug into External
Device Port and power plug to AC outlet.
