Dock controls, connectors, and indicator

1
Power button with indicator
3
5
USB-C connector (for connecting USB-C compatible
devices)
7
USB 2.0 connector
9
TM
HDMI
connector 1
11
13
USB 3.1 connector Gen 2
15
USB-C connector (for connecting computer)
1
Power button with indicator: The dock power button works differently in the following situations:
• When the dock is connected only to ac power but not the computer, press the dock power button to turn
off and turn on the dock. The indicator in the dock power button shows the dock status:
- Amber: The dock is on.
2
ThinkPad Hybrid USB-C with USB-A Dock User Guide
2
Security-lock slot
4
USB 3.1 connector Gen 2
6
USB 2.0 connector
8
®
DisplayPort
connector 1
10
DisplayPort connector 2
12
Always On USB 3.1 connector Gen 2
14
Ethernet connector
16
Power connector
