Introduction
DN-200BR is a Bluetooth
outputs. It lets you add wireless stereo Bluetooth audio reception to any
professional audio system. Once you pair your Bluetooth device to DN-
200BR, you can send your device's audio signal out DN-200BR's
balanced XLR or unbalanced 1/4" (6.35 mm) outputs to your mixer,
loudspeakers, or amplification system.
Please see this guide's
200BR with your audio system, and then refer to the
start using DN-200BR.
Box Contents
DN-200BR
Power Adapter
Support
For the latest information about this product (system requirements,
compatibility information, etc.) and product registration, visit denonpro.com.
®
audio receiver with professional-grade audio
Set up
chapter to learn how to integrate DN-
User Guide
Safety & Warranty Manual
Operat ion
chapter to
Advertisement
Related Manuals for Denon DN-200BR
Summary of Contents for Denon DN-200BR
- Page 1 It lets you add wireless stereo Bluetooth audio reception to any professional audio system. Once you pair your Bluetooth device to DN- 200BR, you can send your device’s audio signal out DN-200BR’s balanced XLR or unbalanced 1/4” (6.35 mm) outputs to your mixer, loudspeakers, or amplification system.
- Page 2 2. Bluetooth Antenna: The antenna receives and transmits the Bluetooth signal from a paired Bluetooth device. DN-200BR has a range of up to 82 feet (25 meters). 3. Pair Button: Press and hold this button for 3 seconds to make DN- 200BR available for pairing to a nearby Bluetooth device.
- Page 3 4. Status Light: This LED indicates the DN-200BR’s Bluetooth pairing status: Flashing slowly (approximately twice every 2 seconds): DN- • 200BR is not paired to a Bluetooth device. Flashing quickly (approximately twice per second): DN-200BR • can be paired to a Bluetooth device.
- Page 4 Important: For stereo operation, make sure all left (L) and right (R) outputs are connected to left and right inputs, respectively. 2. Use the included pow er adapter to connect DN-200BR’s power input to your power source. Important: Do not use DN-200BR near a microwave oven, which can interfere with the reception.
- Page 5 Example PA loudspeakers Loudspeakers Mixer DN- 200BR OUTPUT BLUETOOTH AUD IO RE CEIVER BAL. UNBAL. UNBAL. LEVEL 5V 3A STATUS PAIR Power Smartphone, tablet, etc.
-
Page 6: Operation
“ connected” wirelessly. You can play audio on your Bluetooth device, and it will be sent out of DN-200BR’s outputs (balanced and unbalanced). Important: DN-200BR will not receive audio from a phone call. While using it, we • recommend disabling your cellular connection, if possible. - Page 7 To pair your Bluetooth device to DN-200BR: 1. If DN-200BR is off, use the included power adapter to connect its power input to your power source. The Status Light will flash slowly. 2. Make sure your desired Bluetooth device has its Bluetooth connectivity on and is within range.
- Page 8 Important: DN-200BR will not receive audio from a phone call. While using it, we recommend disabling your cellular connection, if possible. To unpair your Bluetooth device from DN-200BR, do one of the following: Enter your Bluetooth device’s Bluetooth settings menu, and •...
-
Page 9: Troubleshooting
If you encounter a problem, try doing these things first: Make sure all cables and other connected devices are properly and • securely connected. Make sure you are using DN-200BR as described in this User Guide. • Make sure your other devices or media are working properly. •... - Page 10 Operation does not play Improve the Bluetooth signal through DN-200BR. reception by moving your Bluetooth device closer to DN-200BR. Also, remove obstacles (walls, furniture, etc.) so there is a clear line of sight between your Bluetooth device and DN-200BR. Pairing my Bluetooth Enter 0000 as the PIN.
