CLS RGB LED Par Controller
introDuction
thank you for selecting the CLS rGb LeD Par Controller. the CLS rGb LeD Par Controller is an universal
controller that allows you to easely control a set of rGb LeD Par's.
included items
the CLS rGb LeD Par Controller is shipped in one package containing the following items:
• 1 x CLS rGb LeD Par Controller + power supply
• 1 x user manual
optional accessories
• CLS cable 80cm XLr 3P complete
• CLS cable 1,5mtr XLr 3P complete
• CLS cable 3mtr XLr 3P complete
• CLS cable 5mtr XLr 3P complete
• CLS cable 10mtr XLr 3P complete
• CLS cable 15mtr XLr 3P complete
• CLS cable 20mtr XLr 3P complete
NOTE: It is important to read this manual before you install this product.
saFety inForMation
Warning! this product is for professional use only, not for domestic use. read this manual before
powering up or installing the cls rGB leD par controller. Follow the instructions listed below
and observe all warnings in this manual.
protection from electric shock
• Disconnect the power supply from AC power before installing, dismounting or maintaining the unit.
• Make sure all connectors are connected properly.
• Use only a source of AC power that complies with local building and electrical codes and has both
overload and ground-fault protection.
• refer all service to a qualified technician.
protection from burns and fire
• Do not install the CLS rGb LeD Par Controller near a heat source.
• Do not install the CLS rGb LeD Par Controller in a corrosive, flammable or explosive area.
• Do not modify the CLS rGb LeD Par Controller, or install other than genuine parts.
• Do not operate the CLS rGb LeD Par Controller if the ambient temperature exceeds 40º C.
protection from injury due to falls
• Verify that all covers and mounting hardware is securely fastened.
• block the access around the work area whenever installing or removing the unit.
(item nr. 911200)
(item nr. 911201)
(item nr. 911203)
(item nr. 911205)
(item nr. 911206)
(item nr. 911207)
(item nr. 911209)
- 2 - www.cls-led.com
CLS Manuals
CLS Atmosphere LED-panel
3. Set your scene with reD, GreeN, bLUe & MASter faders to the desired setting.
4. Press the "reCorD" button to store the step. repeat steps 3 & 4 to store up to 20 steps / scenes per chase.
5. Press the "bLACKoUt" button twice to exit.
stroBe Function
the strobe function will mix with a running Colour Preset or Chase. Pressing the Strobe button will
temporarily incorporate a strobe effect over a running colour preset or chase.
1. Press the "Strobe" button when effect is desired.
- 7 - www.cls-led.com
