Page 1: Table Of Contents
CLS Manuals CLS Manuals CLS REVO Compact Basic / Compact Retail CLS Atmosphere LED-panel INDEX Index Introduction Included items Optional accessories Safety information Installation REVO Compact Basic Installation REVO Compact Retail Replace lenses Measurements Specifications List of symbols CLS REVO Compact Basic / Compact Retail Version 1.0 June 2011... -
Page 2: Introduction
CLS Manuals CLS Atmosphere LED-panel CLS REVO Compact Basic / Compact Retail INTRODUCTION Note: It is important to read this manual before you install this product. CLS’s brand new REVO Compact product line belongs to a revolutionary flexible new IP67 range of products that can be used for an enormous amount of applications. -
Page 3: Installation Revo Compact Basic
# 871992 CLS mold set 1. The CLS REVO Compact Basic can be installed by using the mounting hole. Drill a hole to secure it in the wall, floor, ceiling, etc. Drill a second hole for the power wire if the cable connection is indoors. -
Page 4: Replace Lenses
CLS Manuals CLS Atmosphere LED-panel CLS REVO Compact Basic / Compact Retail INSTALLATION REVO COMPACT RETAIL ATTENTION! When your CLS REVO Compact Retail is delivered with an assembled adapter, start with step 7. make sure that the rubber sealing is correctly in place! 1. -
Page 5: Measurements
CLS Manuals CLS Atmosphere LED-panel CLS REVO Compact Basic / Compact Retail MEASUREMENTS TECHNICAL SPECIFICATIONS LED: 4 x Luxeon / Cree 78mm Available colours: Extra warm white 2700K, warm white 3000K, neutral white 4000K, cold white 6300K, amber, royal blue, red and green... - Page 6 CLS Manuals CLS Atmosphere LED-panel CLS REVO Compact Basic / Compact Retail LYST OF SYMBOLS Protection class Colour One, two or three Available colours; Amber, blue, red or green Application area Colour temperature White in different Kelvin values; Indoor or outdoor...
