CLS Zense
CLS Zense
version 2.3 November 2010
- 1 - www.cls-led.com
INTRODUCTION
The CLS Zense is a DMX controller specially designed for LED applications. It supports up to 5 colour
control with or without a master channel. Besides the DMX, the CLS Zense is also able to directly drive
voltage-controlled LED products, such as Colourcove X-bright, Manon single colour and RGB, Safestairs etc.
The CLS Zense is designed to fit in the most common wall mount fittings. This makes the CLS Zense very
easy to install. The universal connection possibilities make it perfect for every installation. Because the CLS
Zense uses Capsense technology, the surface is totally flat.
Included items
The CLS Zense is shipped in one package containing the following items:
• 1 x CLS Zense
• 1 x manual
• 1 x black frame
• 1 x white frame
• 1 x power supply & 4 plugs (VDE + UL & PSE + SAA + BS)
• 1 x RJ45 to PWR cable
• 1 x RJ45 to XLR cable
• 1 x 3-way connection block RJ45
• 1 x UTP-CAT5 cable, 2mtr
Note: It is important to read this manual before you install this product.
SAFETY INFORMATION
Warning! This product is for professional use only.
Read this manual before powering up or installing the CLS Zense. Follow the instructions listed
below and observe all warnings in this manual.
Protection from electric shock
• Disconnect the power supply from AC power before installing, dismounting or maintaining the unit.
• Make sure all connectors are connected properly.
• Use only a source of AC power that complies with local building and electrical codes.
• Do not expose the unit to rain or moisture.
• Refer all service to a qualified technician.
Protection from burns and fire
• Do not install the CLS Zense near a heat source.
• Do not install the CLS Zense in a corrosive, flammable or explosive area.
• Do not modify the CLS Zense, or install other than genuine parts.
• Do not operate the unit if the ambient temperature exceeds 40 ºC.
• Operate in a well ventilated area
Protection from injury due to falls
• Verify that all covers and mounting hardware are securely fastened.
• Block the access below the work area whenever installing or removing the unit.
