Page 1 ® NVR32xx-P Series Network Video Recorder User Guide...
Page 2: Typographic Conventions
©2014 ADT LLC dba ADT Security Services. All rights reserved. ADT, the ADT logo, 800 ADT.ASAP and the product/service names listed in this document are marks and/or registered marks. Unauthorized use is strictly prohibited.
Page 3: Table Of Contents
Table of Contents NVR Overview ........................... 1 Front Panel ................................ 1 Rear Panel ................................. 3 Alarm Connection ............................4 1.3.1 Alarm Port .............................. 4 1.3.2 Alarm Input Port ............................ 5 1.3.3 Alarm Input and Output Port ......................6 1.3.4 Network Connection ..........................7 Remote Control ..............................
Page 4 Information (Info) ............................40 3.7.1 HDD Information (Info) ........................41 3.7.2 BPS .................................42 3.7.3 Log .................................42 3.7.4 Version ..............................45 3.7.5 Online Users ............................45 3.7.6 Remote Device Information ......................46 3.7.7 Network Information ..........................48 3.7.7.1 Network Load ......................... 48 3.7.7.2 Network Test ........................... 48 Setting ................................50 3.8.1 General ..............................50...
Page 5 3.8.8 Pan/Tilt/Zoom (PTZ) .........................94 3.8.8.1 Cable Connection ........................94 3.8.8.2 PTZ Setup ..........................94 3.8.8.3 PTZ Menu ..........................96 3.8.8.4 Speed ............................96 3.8.8.5 Direction Keys ......................... 97 3.8.8.6 3D Intelligent Positioning Key ..................... 97 3.8.8.7 Zoom, Focus, Iris ........................97 3.8.8.8 PTZ Trace ..........................
Page 6 4.4.3 Real-time Monitor ..........................136 4.4.4 Pan/Tilt/Zoom (PTZ) Panel ......................137 4.4.5 Image Setup ............................139 4.4.6 Alarm Output ............................ 140 Playback (Search) ............................141 Alarm ................................144 4.6.1 Alarm Type ............................144 4.6.2 Operation ............................145 4.6.3 Alarm Sound ............................. 145 Set ..................................
Page 7 4.7.5.2 Account ..........................204 4.7.5.3 Display ........................... 208 4.7.5.4 Alarm Out ..........................214 4.7.5.5 Default ........................... 214 4.7.5.6 Import & Export ........................215 4.7.5.7 Auto Maintenance ......................215 4.7.5.8 Upgrade ..........................216 4.7.5.9 RS232 ........................... 217 4.7.5.10 PTZ ............................218 4.7.5.11 Preview Control ........................
Page 8 All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. ADT assumes no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.
Page 9 Preface Features Overview NVR32xx-P Series network video recorder is an excellent digital monitor product designed for ® security applications. It adopts embedded Linux OS to maintain reliable operation and the H.264 compression algorithm to provide high quality, low bit streams. The unique frame-by-frame playback function is ideal for detail analysis.
Page 10 Preface o Alarm input can be derived from various connected peripheral devices o Can alert you via email or SMS • Network Monitor o Compresses video data by IPC or NVS and sends through the network to the client where the data is decompressed and displayed o Latency is less than 500ms, depending on bandwidth o Support 20 connections at the same time max...
Page 11: Nvr Overview
1 NVR Overview 1 NVR Overview This chapter provides information about front panel and rear panel. Refer to this section first when installing the NVR. 1.1 Front Panel The front panel is shown in Figure 1-1. Figure 1-1 Refer to the following table for detailed information. Group Symbol Function...
Page 12 1 NVR Overview Group Symbol Function Shift. Press to toggle between character types: number 0-9, upper case letter Shift or lower case letter. Record. Press to manually start/stop recording. Use the direction keys or number keys to select the recording channel. In playback mode: Press to playback the previous video.
Page 13: Rear Panel
+48 VDC input. Switch power port Input 48VDC/1.04A (32-P) or 48VDC/2.5A (32-8P) * ADT does not support Audio functions at this time Note: When connecting the Ethernet port, use the crossover cable to connect the PC and use the straight cable to connect to the switcher or router.
Page 14: Alarm Connection
1 NVR Overview 1.3 Alarm Connection 1.3.1 Alarm Port Please refer to the following figure for detailed information about the alarm port. Figure 1-3 Description 1-4, 1-8 or 1-16 Alarm Inputs (active low) Earth ground CTRL 12V Control power output. For an external alarm, close the device power to cancel the alarm.
Page 15: Alarm Input Port
1 NVR Overview 1.3.2 Alarm Input Port To connect an alarm: 1. Connect the positive end (+) of the alarm input device to the alarm input port (ALARM IN 1-16) of the NVR. 2. Connect the negative end (–) of the alarm input device to the ground end ( ) of the NVR.
Page 16: Alarm Input And Output Port
1 NVR Overview 1.3.3 Alarm Input and Output Port • There is peripheral power supplied for the external alarm device. • To avoid an overload resulting in NVR damage, please refer to the following relay specifications for detailed information. • A/B cable of the RS485 is for the A/B cable connection of the speed PTZ.
Page 17: Network Connection
1 NVR Overview 1.3.4 Network Connection Figure 1-5 NVR32xx-P Series User Guide...
Page 18: Remote Control
1 NVR Overview 1.4 Remote Control The remote control interface is shown as in Figure 1-6. Figure 1-6 Symbol Function Power button. Press to power up or shut down the NVR. Address. Use to input the device number of the unit that you want to control with the remote.
Page 19: Context Menu
1 NVR Overview Symbol Function Record. Press to manually start/stop recording. Use the direction keys or number keys to select the recording channel.  Direction Keys. Press to move the selection in the currently-active control   left, right, up or own. During playback, click to control the playback bar. ...
Page 20: Virtual Keyboard
1 NVR Overview 1.6 Virtual Keyboard The system displays three input modes: upper case and lower case alpha characters and numeric. Switch between modes by clicking the button to the right of the field. It toggles from to display lower case letters and numbers. └┘ functions as a space and ← functions as a Select backspace.
Page 21: Getting Started
2 Getting Started 2 Getting Started This section describes how to startup and login to the system, as well as how to set up and perform the most commonly used local menu operations. For information on the full local menu set, refer to section 3 Menu Operations on page 29.
Page 22 2 Getting Started • User Name: 666666. Password: 666666 (Lower authority user who can only use monitor, playback, backup, etc.) • User Name: default. Password: default (hidden user) 3. Use a USB mouse, remote control, or the NVR front panel buttons to complete the login. Using the USB Mouse: 1.
Page 23: Startup Sequence
2 Getting Started 4. Press the Shift key to toggle between upper case letters, lower case letters or numeric input. 5. Use the numeric values on the various keys to enter the desired characters. 6. Press the Enter key. The keyboard disappears. Note: For security reasons, modify your password after your first login.
Page 24 2 Getting Started Figure 2-5 2. Use the drop-down list to select the desired option. Figure 2-6 3. Enter the username and password to complete the operation. 4. Click OK. To log out using the Power button: 1. Press the Power button on the front panel for at least 3 seconds.
Page 25: Live Viewing
2 Getting Started 2.2 Live Viewing After you log in, the system is in live viewing mode. You see the system date, time and channel name. You can change the system date and time in the General Settings Menu (Main Menu > Setting > General).
Page 26 2 Getting Started Name Function Real-time backup Backs up the video of the current channel to the USB device. function The system cannot backup the video of multiple-channels at the same time. The currently selected backup channel displays and the free channel is shown with Once the backup started, the free channel is shown with the icon.
Page 27: Search And Playback
2 Getting Started 2.3 Search and Playback Click the Search button in the Main Menu, or else right mouse-click and select Search from the context menu. The Search screen appears. Figure 2-8 There are three file types: R: Regular recording file M: Motion Detection recording file A: External alarm recording file Refer to the following table for detailed information.
Page 28 2 Getting Started No. Name Function Calendar In any play mode, click the date you want to see files for. The corresponding record file trace appears in the time bar. If a date is highlighted in blue date, a picture or file exists for this date. Playback Playback mode:1/4/9/16, depending on your model: mode and...
Page 29 2 Getting Started No. Name Function Reverse Play In normal play mode, left-click this button and the file begins reverse  play. Click again to pause the current playback. • In reverse play mode, Click ►/ to restore normal play. Previous Play •...
Page 30: Other Functions
2 Getting Started No. Name Function Backup 1. Select the file(s) you want to backup from the file list. 2. Click the Backup button. The backup menu appears. 3. Browse to or create a new destination folder. 4. Click the Start button to begin the backup operation. The record file(s) are saved to the specified folder.
Page 31: Smart Search
2 Getting Started 2.3.2 Smart Search While the NVR is in playback mode, you can select the smart search feature enables you to search for and playback motion detect files. To use the Smart Search feature: 1. During multiple-channel playback mode, double-click a channel, and then click the button located in the Playback control panel (item #8 in Figure 2-8 on page 17).
Page 32: Playback By Time
2 Getting Started During the motion detect play process, you cannot implement operations such as change time bar, begin backward playback or frame by frame playback. IMPORTANT: • The system does not support motion detect zone setup during the full-screen mode. •...
Page 33 2 Getting Started To playback recordings using the time bar: 1. Select the recordings for one day. 2. In the time bar double-click on the time of day you want to view. The vertical lines represent the hour of the day; the horizontal lines separate the channels, with channel 1 at the top. If the Synch box is checked, playback for all channels will be for the same time period.
Page 34: Snapshot
2 Getting Started 2.4 Snapshot The NVR enables you to take a snapshot photo either at a scheduled interval or when triggered by a pre-determined event. 2.4.1 Schedule Snapshot 1. In the Encode screen, click the Snapshot button to input snapshot mode, size, quality and frequency.
Page 35: Activation Snapshot
2 Getting Started Figure 2-13 3. In Schedule screen, enable the Snapshot function by checking the Snapshot checkbox. Figure 2-14 2.4.2 Activation Snapshot This function triggers a snapshot when the corresponding detection event occurs. 1. In the Encode screen, click Snapshot to input snapshot mode, size, quality and frequency. NVR32xx-P Series User Guide...
Page 36 2 Getting Started Figure 2-15 2. In the FTP screen (Main Menu > Setting > Network), input the upload interval. Figure 2-16 3. In the Detect screen, enable the snapshot and then specify the channels for which snapshots are to be taken. NVR32xx-P Series User Guide...
Page 37: Image Ftp
2 Getting Started Figure 2-17 Note: An Activation Snapshot has higher priority than a Schedule Snapshot. If both types are enabled at the same time, the system will initiate the activation snapshot when alarm occurs and initiate the schedule snapshot when there is no active alarm. 2.4.3 Image FTP This feature sets up the FTP server and enables you to upload snapshot image files to it.
Page 38 2 Getting Started Input the corresponding information to upload the image to an FTP server. Figure 2-18 NVR32xx-P Series User Guide...
Page 39: Menu Operations
Hybrid Standalone NVR User Guide 3 Menu Operations 3 Menu Operations 3.1 Menu Tree The NVR32XX-P NVR local menu tree structure is shown below. For information operations via the internet, refer to section 4 Web Service on page 129. NVR32xx-P Series User Guide...
Page 40: Main Menu
Hybrid Standalone NVR User Guide 3 Menu Operations 3.2 Main Menu After you have logged in, the system Main Menu appears. There are seven icons: Search, Info, Setting, Remote Device, Advanced, Backup and Shutdown. You can also open the Main Menu by right-clicking and selecting Main Menu form the context menu. Figure 3-1 Click an icon to enter the corresponding sub-menu.
Page 41: Backup
Hybrid Standalone NVR User Guide 3 Menu Operations 3.4 Backup 3.4.1 File Backup The NVR supports USB device backup. USB backup devices include USB burners, flash drives, SD cards and portable hard disk drives (HDD). To setup USB Backup: 1. Click the Backup button on the Main Menu. The Backup screen appears, showing all the backup device information.
Page 42 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-4 5. Set the channel, file start time and end time. 6. Click the Add button. The system begins a search, and then lists all matching files. The system automatically calculates the capacity needed and remained. The system can only backup files with a √...
Page 43: Config Backup
Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-5 • One key backup. This process includes three steps: search, select all and start the backup. This allows you to skip the above three steps and copy all the searched files directly.
Page 44 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-6 Export 1. Connect the peripheral device. 2. Initiate Config Backup. 3. Click the Export button. A corresponding Config_Time folder appears. 4. Double-click the Config_Time folder. Backup files are visible. Import Here you can import the configuration files from the peripheral device to current device.
Page 45: Remote Device
Hybrid Standalone NVR User Guide 3 Menu Operations Remote Device To set up a remote device, open the dialog in one of the following ways: • In the main menu, click the Remote Device icon • Right mouse-click and select Remote Device from the context menu •...
Page 46: Ip Search
Hybrid Standalone NVR User Guide 3 Menu Operations 3.5.1 IP Search Figure 3-8 1. Click this button to search for an IP address. This includes the device IP address, port, device name, manufacturer and type. 2. Click the item name to refresh the display order. 3.
Page 47: Ipc Config
Hybrid Standalone NVR User Guide 3 Menu Operations Manual Add button Click to add the IPC manually. The port number is 37777. The default user name is admin and password is admin. Figure 3-9 Channel: The dropdown list here displays unconnected channel numbers. Select the channel number and then set the remote channel connection in the main screen (see Figure 3-7).
Page 48 Hybrid Standalone NVR User Guide 3 Menu Operations The IPC Config dialog opens. Figure 3-11 Config File. Click the dropdown to select the network camera configuration file. The options include day/night/normal/switch by period. If you select Switch by Period from the dropdown list, you must set the Sunrise Time and Sunset Time.
Page 49: Ipc Upgrade
Hybrid Standalone NVR User Guide 3 Menu Operations Contrast. Use the slider to adjust monitor window contrast. The value ranges from 0 to 100. The default value is 50. The larger the number, the higher the contrast is. You can use this function when the whole video bright is OK but the contrast is not proper.
Page 50: Information (Info)
Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-12 3.7 Information (Info) Click the Info icon on the Main Menu to view system information. There are seven items: HDD (hard disk drive information), BPS (data stream statistics), Log, Version, Online Users, Remote and Network Information.
Page 51: Hdd Information (Info)
Hybrid Standalone NVR User Guide 3 Menu Operations 3.7.1 HDD Information (Info) HDD Info lists the hard disk type, total space, free space, video start time and status. See Figure 3-14. Figure 3-14 Status ○ HDD is working normally X HDD error –...
Page 52: Bps
Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-15 3.7.2 BPS The BPS screen enables you to view current video data stream (KB/s) and occupied hard disk storage (MB/h) information. Click the BPS icon on the Info screen. Figure 3-16 3.7.3 Log The Log screen enables you to view system log files.
Page 53 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-17 Start Time/End Time Select the start time and end time, and then click Search. The log files are displayed in a list. The system displays a maximum of 100 logs in one page and can save a maximum of 1024 log files. Use the page up/down button in the dialog or on the front panel to view more.
Page 54 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-18 Details Click Details or double-click the log item to view detailed information. Use the slider or Page up/Page down to view other log information. To playback the alarm event log such as video loss, click the Playback button at the bottom right corner.
Page 55: Version
Hybrid Standalone NVR User Guide 3 Menu Operations 3.7.4 Version Version enables you to view hardware features, software version, built date, release SN information, etc. You can also update system here. See Figure 3-20. Click the Version icon on the Info screen (see Figure 3-13 on page 40) to open the screen.
Page 56: Remote Device Information
Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-21 3.7.6 Remote Device Information In this screen you can view the channel status and connection log of the remote device. To set up the remote device, see section 3.5 Remote Device on page 35. Channel Status tab Here you can view the IPC status of the corresponding channel, which includes motion detection, video loss, camera masking and alarm.
Page 57 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-22 Connection Log tab On this tab, you can search the IPC log information of the corresponding channel, both online and offline. Select a channel from the dropdown list and then set the start time and end time. Click the Search button to view the remote connection log of the current channel.
Page 58: Network Information
Hybrid Standalone NVR User Guide 3 Menu Operations 3.7.7 Network Information In this screen, you can see the Network Test and Network Load information. Click the Network icon on the Info screen (see Figure 3-13 on page 40) to open the dialog. Also refer to section 3.8.5 Network on page 62.
Page 59 3. Click the Browse button to select the snapshot path. The steps here are the same as for the backup operation. You can view all connected network adapter names including Ethernet and PPPoE. (WIFI and 3G are not supported by ADT at this time). 4. Click the button on the right panel to begin the Sniffer.
Page 60: Setting
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8 Setting In the Main Menu, click the Setting icon. The Setting screen opens. Figure 3-26 3.8.1 General General setting includes the following items. See Figure 3-27. After completing all settings, click the OK button.
Page 61 Hybrid Standalone NVR User Guide 3 Menu Operations System Time This section is for setting the system time. Date Format There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY. Date Separator There are three denotations to separate date: dot, beeline and solidus. This section is for setting DST time and date.
Page 62 Hybrid Standalone NVR User Guide 3 Menu Operations Device ID Input a corresponding device name here. HDD Full In this section you can select the working mode when the hard drive is full. There are two options: stop recording or rewrite. If the current working HDD is overwritten or the current HDD is full while the next HDD is not empty, then the system stops recording, If the current HDD is full and the next HDD is not empty, then the system overwrites the previous files.
Page 63: Encode
Hybrid Standalone NVR User Guide 3 Menu Operations Mouse Property Click the Mouse Property Setup button to open the Mouse Setup dialog. Set the Double-click Speed by dragging the slider. Click the Default button to restore the default setup. Figure 3-31 Auto Logout This enables you to set auto logout interval once login user remains inactive for a specified time.
Page 64 Only appears when VBR is selected above. There are six levels ranging from 1 to 6. The sixth level has the highest image quality. Audio / Video Use this checkbox to enable or disable the video/audio. Note: ADT does not support Audio functions at this time. NVR32xx-P Series User Guide...
Page 65 Hybrid Standalone NVR User Guide 3 Menu Operations Overlay Click the Overlay button to open the Overlay dialog, which determines whether the following items are displayed on the monitor screen. Figure 3-33 • Cover Area (Privacy Mask). This section is for setting the Privacy Mask. In the dialog, use your mouse to set the desired mask size and location.
Page 66 Hybrid Standalone NVR User Guide 3 Menu Operations • Image Quality: Set the snapshot quality. The value ranges from 1 to 6. • Snapshot Frequency: Set the timing (schedule) snapshot interval. The value ranges from 1-7 picture(s) per second. Copy. After you complete the setup, you can click Copy button to copy the current setup to other channel(s).
Page 67: Schedule
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.3 Schedule You can set the recording type and time in the Schedule screen. 3.8.3.1 Schedule Menu In the Main Menu, click the Setting button and then select Schedule. The Schedule menu appears.
Page 68 Hybrid Standalone NVR User Guide 3 Menu Operations Period. There are eight options: ranges from Saturday to Sunday and all. Period. Select the day you want to schedule: Saturday to Sunday or All. Select Holiday to schedule a unique recording schedule for the days you established as holidays in the General menu. Period 1 - 6.
Page 69: Quick Setup
Hybrid Standalone NVR User Guide 3 Menu Operations Note: Holiday settings have priority over non-holiday schedules. If the selected day is a holiday, then the system records according to the Holiday setting. If it is not a holiday, the system records according to the regular Schedule.
Page 70 Hybrid Standalone NVR User Guide 3 Menu Operations 4. After completing the setup, click the OK button. The system returns to the previous menu. Figure 3-39 5. Use one of these two methods to playback or search in the redundant disk: •...
Page 71: Rs232
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.4 RS232 This dialog is for setting up the RS232 connections. Figure 3-40 The dialog contains five items: Function There are various devices for you to select from the dropdown: • Console (the default) is for use with the COM or software to upgrade or debug the program. •...
Page 72: Network
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.5 Network This section is for inputting the network information. The single network adapter dialog is shown in Figure 3-41 and the dual network adapter dialog is shown in Figure 3-42. Also see section 3.7.7 Network Information on page 48. Figure 3-41 Figure 3-42 NVR32xx-P Series User Guide...
Page 73 Hybrid Standalone NVR User Guide 3 Menu Operations Default Network Card Select eth0/eth1/bond0 (optional) after enabling the multiple-access function. Main Network Card Select eth0/eth1 (optional) after enabling the multiple-access function. IP Version There are two options: IPv4 and IPv6. At this time, the system only supports IPv4. MAC address The LAN host has a unique MAC address.
Page 74 Hybrid Standalone NVR User Guide 3 Menu Operations Max Connection The system supports a maximum of 128 users. Displays the Maximum Transmission Unit (MTU) value of the network adapter. The value ranges from 1280-7200 bytes. The default setup is 1500 bytes. MTU modification can affect current network service and may result in a reboot of the network adapter.
Page 75: Network Setting
Hybrid Standalone NVR User Guide 3 Menu Operations Load balance: In this mode, device uses bond0 to communicate with the external device. The eth0 and eth1 are both working now and bearing the network load. Their network load are general the same.
Page 76: Ip Filter
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.5.2 IP Filter The IP filter dialog is shown in Figure 3-44. You can add IP in the following list. The list supports a maximum 64 IP addresses. The system only supports IPv4 at this time. Figure 3-44 After you enabled trusted sites function, only the IP listed below can access current NVR.
Page 77 Hybrid Standalone NVR User Guide 3 Menu Operations • The system only checks the start address if you add an IP address. The system checks the start address and end address if you add an IP section. The end address must be larger than the start address.
Page 78: Ntp
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.5.3 NTP You must install an SNTP server (such as Absolute Time Server) in your PC first. In Windows XP OS, you can use command net start w32time to boot up the NTP service. NTP setup dialog is shown in Figure 3-46.
Page 79: Multicast
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.5.4 Multicast Multicast is a transmission mode for data packets. Multicast sends IP datagrams to a group of receivers in a single transmission. When there are multiple hosts to receive the same data packet, multicast is the best option to reduce the bandwidth and the CPU load.
Page 80: Pppoe
Hybrid Standalone NVR User Guide 3 Menu Operations After you have logged onto the Web, the Web can automatically get a multicast address and add it to the multicast groups. You can enable real-time monitor function to view the view. 3.8.5.5 PPPoE The PPPoE (Point to Point Protocol over Ethernet) dialog is shown in Figure 3-48.
Page 81 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-49 Note that NNDS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS and Dyndns DDNS. You can setup all DDNS clients to be valid at the same time. The Quick DDNS function works with a special DDNS server and special Professional Surveillance Software (PSS).
Page 82: Upnp
Hybrid Standalone NVR User Guide 3 Menu Operations 3. Operation Before you use Quick DDNS, you must enable this service and set the proper server address, port value and domain name. • Server address: www.quickddns.com • Port number: 80 • Domain name: There are two modes: Default domain name and customized domain name.
Page 83 Hybrid Standalone NVR User Guide 3 Menu Operations Status When UPNP is offline, this field displays “Unknown”. When UPNP is online, it shows “Success”. Router LAN IP This is the router IP in the LAN. WAN IP This is the router IP in the WAN. Port Mapping List This represents the one-to-one relationship with the router’s port mapping setting.
Page 84: Wifi
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.5.8 3G This feature is not supported by ADT. 3.8.5.9 WIFI This feature is not supported by ADT. 3.8.5.10 Email The email dialog is shown below in Figure 3-52. Figure 3-52 SMTP Server Enter your email SMTP server IP.
Page 85 Hybrid Standalone NVR User Guide 3 Menu Operations Receiver Enter the receiver’s email address. The system supports a maximum of 3 email boxes and automatically filters out duplicate addresses. Sender Enter the sender’s email address. Title Enter the email subject line (32 alphanumeric characters max). SSL Enable Check to enable SSL encryption.
Page 86: Ftp
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.5.11 You must download or buy an FTP service tool (such as Ser-U FTP SERVER) to establish the FTP service. Install the Ser-U FTP SERVER first. (Start > All Programs > Serv-U FTP Server > Serv-U Administrator). Then set the user password and FTP folder.
Page 87 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-56 To use the FTP feature: 1. Highlight the Enable box to activate the FTP function. 2. Input the FTP server address, port and remote directory. When a remote directory is not available, the system automatically creates folders according to the IP, time and channel.
Page 88: Alarm Center
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.5.12 Alarm Center This feature is not supported by ADT at this time. 3.8.5.13 SNMP SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management framework of the network management system. SNMP is widely used in many environments, network devices, software and systems.
Page 89: Auto Register
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.5.14 Auto Register This function enables the device to automatically register to the proxy you have specified. In this way you can use the client end to access the NVR via the proxy. In the network service, the device supports a server address of IPv4 protocol.
Page 90: Switch Settings
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.5.15 Switch Settings The built-in switch function is for product of PoE port. Navigate to Network > Network Setting > Switch Settings to set switch IP address, subnet mask, gateway, etc. Figure 3-60 3.8.6 Alarm Setup and Activation 1.
Page 91 Hybrid Standalone NVR User Guide 3 Menu Operations Event Type Make your selection from the dropdown: Local Alarm, Net Alarm, IPC Ext Alarm or IPC Offline Alarm. • Local Alarm. The system detects the alarm signal from the alarm input port. •...
Page 92 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-63 Anti-dither This feature sets a delay period before triggering the next alarm, to avoid re-triggering on the same event for screen prompt, alarm upload, and email notifications. The delay period begins when the current event has ended, not including the latch time.
Page 93 Hybrid Standalone NVR User Guide 3 Menu Operations PTZ Activation Select this feature to set Pan/Tilt/Zoom movement when an alarm occurs. Click the Setup button to open the PTZ Activation screen for setting up the camera. Figure 3-64 Delay To avoid rerecording the same event, enter the number of seconds to wait after the event has ended before a new recording can begin.
Page 94: Detect
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.7 Detect The Detect screen is used for setting up the type of events for which you want to trigger a response, such as triggering an alarm, sending an email or taking a snapshot. There are three detection types that you can set as an event: •...
Page 95 Hybrid Standalone NVR User Guide 3 Menu Operations Enable Check the box to enable the event type. Region (Motion Detection only) Click the Setup button to set Motion Detection zone. There are 396(PAL)/330(NTSC) small zones. The blue zone is the motion detection zone; the white zone is the disarmed zone.
Page 96 Hybrid Standalone NVR User Guide 3 Menu Operations Record Channel The system automatically activates the designated channel(s) to record once a Motion Detection event occurs. Make sure you have set MD Record in Schedule screen (Main Menu > Setting > Schedule) and Schedule Record on the Manual Record screen (Main Menu >...
Page 97: Motion Detection
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.7.2 Motion Detection The system can set a Motion Detection event to trigger an alarm and initiate recording. The Motion Detect icon appears on the live video screen if the current channel has the motion detect alarm enabled.
Page 98 Hybrid Standalone NVR User Guide 3 Menu Operations 6. Set the motion detection zone, using one of the following methods. The currently selected grid cell is highlighted in green. a. Left mouse-click and drag it to set the desired region. If the area is already blue (armed), dragging the mouse sets the cells clear (disarmed).
Page 99 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-69 11. Select Work Day from the drop down list. 12. Select the Setup button. The Setup dialog appears. 13. Enable the working and free (non-business) days. Figure 3-70 14. Select Save to return to the Setup screen (Figure 3-69). Six periods appear for you to set for each day.
Page 100: Video Loss
Hybrid Standalone NVR User Guide 3 Menu Operations 18. Select the desired alarm types: Alarm Out, Show Message, Record Channel, PTZ Activation, Tour, Snapshot, Buzzer, Alarm Upload, or Send Email (as described in section 3.8.7 Detect Setup on page 84). 19.
Page 101 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-72 6. Select Work Day from the drop down list. 7. Select the Setup button. The Setup dialog appears. 8. Enable the working and free (non-business) days. Figure 3-73 9. Select Save to return to the Setup screen (Figure 3-69). Six periods appear for you to set for each day.
Page 102: Camera Masking
Hybrid Standalone NVR User Guide 3 Menu Operations 13. Select the desired alarm types: Alarm Out, Show Message, Record Channel, PTZ Activation, Tour, Snapshot, Buzzer, Alarm Upload, or Send Email. 14. Select the Save button to enact the current setup. The Video Loss icon appears on the live video screen if the current channel has the Video Loss alarm enabled.
Page 103 Hybrid Standalone NVR User Guide 3 Menu Operations 5. In the Period area, select the Setup button. The Setup dialog opens for setting the time period during which Camera Masking will be a trigger event. Figure 3-75 6. Select Work Day from the drop down list. 7.
Page 104: Pan/Tilt/Zoom (Ptz)
Hybrid Standalone NVR User Guide 3 Menu Operations 13. Select the desired alarm types: Alarm Out, Show Message, Record Channel, PTZ Activation, Tour, Snapshot, Buzzer, Alarm Upload, or Send Email. 14. Select the Save button to enact the current setup. Note: •...
Page 105 Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-77 The PTZ Setup screen contains the following items: Channel. Use the drop-down list to select the desired channel number. Make this channel selection first. Protocol. Select corresponding PTZ protocol (such as Pelco D) Address: Input corresponding PTZ address.
Page 106: Ptz Menu
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.8.3 PTZ Menu In one window display mode, right mouse-click and select Pan/Tilt/Zoom from the context menu, or press the Fn button on either the front panel or on the remote. Figure 3-78 Main PTZ Control Interface The Pan/Tilt/Zoom main control interface appears.
Page 107: Direction Keys
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.8.5 Direction Keys Click one of the eight the direction arrows to adjust the Pan/Tilt/Zoom (PTZ) position. The camera moves accordingly. Note that there are only four direction arrows on the NVR front panel. Figure 3-80 3.8.8.6 3D Intelligent Positioning Key The PTZ function supports 3D intelligent positioning, which enables you to use the mouse to position...
Page 108: Ptz Trace
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.8.8 PTZ Trace Figure 3-82 The PTZ Trace function shows a single video screen. As you move the mouse around the screen, the actual camera movement follows your mouse movement. 3.8.8.9 Page Switch The Page Switch button toggles through the three PTZ dialog screens.
Page 109: Set Button
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.8.10 Set Button Click the Set button in the Main PTZ screen shown in Figure 3-82. The setup dialog appears. Here you can set the following items: • Preset • Patrol • Pattern •...
Page 110 Hybrid Standalone NVR User Guide 3 Menu Operations 2. Click Set. 3. In the Set Screen that appears, click the Preset button. 4. Click within the Preset field. The numeric keypad appears. Input the preset number (1, 2, 3, etc.). NVR32xx-P Series User Guide...
Page 111 Hybrid Standalone NVR User Guide 3 Menu Operations 5. Click Set. 6. Return to step 1 and continue this pattern to set all desired Presets. To activate the Preset: 1. Right-click to return to the Main PTZ Control dialog. Click the Page Switch button. 2.
Page 112 Hybrid Standalone NVR User Guide 3 Menu Operations 3. Click Preset to initiate the selected preset. The camera moves to that Preset location. Patrol Presets can be strung together to move the camera in a designed movement called a Patrol. To setup the Patrol: 1.
Page 113 Hybrid Standalone NVR User Guide 3 Menu Operations 3. Set the patrol number (for example, “1”). 4. Input a preset number you want to add to the patrol (for example, “3”). 5. Click Add Preset to add Preset 3 to Patrol 1. 6.
Page 114 Hybrid Standalone NVR User Guide 3 Menu Operations To activate the Patrol: 1. Right-click to return to the Main PTZ Control dialog. Click the Page Switch button. 2. In the No. field, enter the Tour (Patrol) No. you want to playback, using the numeric keypad. 3.
Page 115 Hybrid Standalone NVR User Guide 3 Menu Operations Pattern Setup A pattern is much like a patrol but does not use presets. Instead, the Pattern is recorded by the camera movement design that you record using the Direction Keys on the Main PTZ Control interface.
Page 116 Hybrid Standalone NVR User Guide 3 Menu Operations 4. Now click the Begin button to start recording your pattern. 5. Right-click to return to the Main PTZ Control dialog. Use the arrow keys to move the camera to the desired view pattern, using the Zoom, Focus, and Iris settings as needed. The pattern that the camera follows is recorded.
Page 117 Hybrid Standalone NVR User Guide 3 Menu Operations 7. In the Set Screen that appears, click the End button to terminate recoding the pattern. To activate the Pattern: 1. Right-click to return to the Main PTZ Control dialog. Click the Page Switch button. 2.
Page 118 Hybrid Standalone NVR User Guide 3 Menu Operations 3. Click Pattern to initiate. The camera moves to all the locations that were recorded in the selected Pattern. Border Border is the right and left limitations that you set for camera movement. Borders determine the pattern limits for Auto Scan.
Page 119 Hybrid Standalone NVR User Guide 3 Menu Operations 2. Click Set. 3. In the Set Screen that appears, click the Border button. 4. In the Set Screen that appears, click the Left button. The Left limit is defined. 5. Repeat steps 1-5, this time setting the Right side border. NVR32xx-P Series User Guide...
Page 120 Hybrid Standalone NVR User Guide 3 Menu Operations To activate the Borders: 1. Right click to return to the Main PTZ Control dialog. Click the Page Switch button. 2. Click the Auto Scan button. The Auto Scan button changes to a Stop button as the camera automatically begins to pan left to the left border you have set, stop, and then pan right until it reaches the right limit.
Page 121: Display Setup
Hybrid Standalone NVR User Guide 3 Menu Operations 3.8.9 Display Setup The Display Setup screen is split into two tabs: GUI and Tour. The GUI screen is shown in the following figure. GUI Tab Figure 3-83 Resolution There are four options: 1920 x1080, 1280 x1024 (default), 1280 x720 and1024 x768. You must reboot to activate the new setup.
Page 122 Hybrid Standalone NVR User Guide 3 Menu Operations Click the Modify button, to the right of the Channel Name. The Channel Name dialog opens, as shown in Figure 3-84. Note that all your modifications here apply to the local end only. You will need to refresh web or client end to get the latest Channel Name.
Page 123: Default
Hybrid Standalone NVR User Guide 3 Menu Operations Motion/Alarm Tour Type Select from the dropdown the motion or alarm tour combination set up in the Tour Setup screen below. • Enable Tour. Check the box to enable this function. • Interval.
Page 124: Advanced
Hybrid Standalone NVR User Guide 3 Menu Operations Advanced Click the Advanced icon in the main window. The Advanced screen appears. There are 7 function keys: HDD Management, Abnormality, Alarm Output, Manual Record, Account, Auto Maintenance, and Config Backup. Figure 3-87 3.9.1 HDD Management The HDD Management section is used to view and edit settings for the hard disk drive.
Page 125: Hdd Setting
Hybrid Standalone NVR User Guide 3 Menu Operations HDD status Figure 3-88 Note: • Each channel’s recordings can be stored in the specified HDD Group. • Each HDD Group corresponds to several hard disks, while each hard disk is only included in only one HDD Group.
Page 126: Hdd Channel
Hybrid Standalone NVR User Guide 3 Menu Operations HDD Group. This lists the HDD Group number of the current hard disk. To set the HDD Group: 1. Check the box of the hard disk. 2. Select the corresponding HDD Group number 3.
Page 127: Abnormality
Hybrid Standalone NVR User Guide 3 Menu Operations TIP: There is an easy way for you to test whether the recordings from the corresponding channel are being saved in the specified HDD. Remove the HDD and then check whether the channel can record.
Page 128 Hybrid Standalone NVR User Guide 3 Menu Operations Select the desired event from the Event Type field and then indicate the way(s) you would like to be notified that the event has occurred. Click Save after making your selections. Event Type Use the drop-down menu to select the event that triggers the Abnormality.
Page 129: Alarm Output
Hybrid Standalone NVR User Guide 3 Menu Operations 3.9.3 Alarm Output If Alarm Out has been enabled to record for either Setting > Detect or Setting > Alarm, this dialog can be used to set up recording status. For each alarm, click to select whether recording is scheduled, manual or stopped (not recorded).
Page 130: Basic Operation
Hybrid Standalone NVR User Guide 3 Menu Operations 3.9.4.2 Basic Operation Highlight the ○ icon to select corresponding channel for the desired mode. Alternatively, click All to set all channels to the desired mode. There are two modes of operation: •...
Page 131: All Channel Schedule Recording
Hybrid Standalone NVR User Guide 3 Menu Operations 3.9.4.5 All Channel Schedule Recording Highlight the ○ below All and to the right of Schedule to schedule recording on all channels. See Figure 3-94. When system is in schedule recording, all channels will record as you have previously set (Main Menu>Setting>Schedule).
Page 132: Stop All Channel Recording
Hybrid Standalone NVR User Guide 3 Menu Operations Figure 3-95 3.9.4.7 Stop All Channel Recording Highlight the ○ below All and to the right of Stop. See Figure 3-96. The system stops all channel recording no matter what mode you have set in the menu (Main Menu>Setting>Schedule).
Page 133: Account
Hybrid Standalone NVR User Guide 3 Menu Operations 3.9.5 Account The Account screen provides account management access. Here you can: • Add new user • Modify a user • Add a group • Modify a group • Modify your password. You can assign different rights to different groups and thereby apply the same rights to all users assigned to that group.
Page 134: Modify Password
Hybrid Standalone NVR User Guide 3 Menu Operations 3.9.5.1 Modify Password To modify the account password: 1. Click the Modify Password button. The Modify Password dialog appears as shown in Figure 3-98. 2. Select the account from the dropdown list, 3.
Page 135: Add/Modify Group
Hybrid Standalone NVR User Guide 3 Menu Operations 3.9.5.2 Add/Modify Group A group is a convenient method for assigning a set of rights to multiple users. Usually a user would be assigned to a single group. To add a new group: 1.
Page 136: Add/Modify User
Hybrid Standalone NVR User Guide 3 Menu Operations 3.9.5.3 Add/Modify User To add a new user: 1. Click the Add User button in the Account screen. The Add User dialog appears. Figure 3-100 2. Enter the User name Note: • The maximum length for the user name string is 6-bytes.
Page 137: Auto Maintenance
Hybrid Standalone NVR User Guide 3 Menu Operations It is recommended that the user rights are set lower than the administrative rights. To modify a user: 1. Click the Modify User button in the Account screen. The Modify User dialog appears. 2.
Page 138: Shutdown
Hybrid Standalone NVR User Guide 3 Menu Operations 3.10 Shutdown Double click the Shutdown icon in the Main Menu. The following dialog appears. Figure 3-102 Make your selection from the drop down menu. Logout Menu User Click this to log out. You must enter your password when you log in the next time. Restart Application Select to reboot the NVR.
Page 139: Web Service
Hybrid Standalone NVR User Guide 4 Web Service 4 Web Service The web service contains the same functions as are available in local operation. Note: There might be a slight difference in the screen depending on the model. The following examples are for the 8-channel product.
Page 140: Login
Hybrid Standalone NVR User Guide 4 Web Service MAC address. Otherwise it can refresh to the newly added device and memorize the <PoE port>---<Channel>. b) If it is your second time to insert the PoE, the system can check the saved MAC address according to the <Channel>---<IPC mac>...
Page 141 Hybrid Standalone NVR User Guide 4 Web Service 3. If you can’t download the ActiveX file, modify your browser settings as follows (Figure 4-2). a. Select Internet Options from the Tools menu. The Internet Options dialog appears. b. Click the Security tab and click Custom level. The Security Settings dialog appears. c.
Page 142: Preview Tab
Hybrid Standalone NVR User Guide 4 Web Service 6. Input your Username and Password. 7. The default factory name is admin and password is admin. 8. Select the login mode: LAN or WAN. Note: For security reasons, modify your password after you first login. The Main web service window opens in the Preview Tab for live viewing, which is discussed in the ensuing suction.
Page 143: Lan Mode
Hybrid Standalone NVR User Guide 4 Web Service 4.4.1 LAN Mode After logging into the LAN mode, the main window appears. Figure 4-4 Section 1 Click the tab of the function you want to switch to: Preview, Playback, Alarm, Set, Info or Logout. Section 2 This section displays the available individual camera channels that you can select.
Page 144 Hybrid Standalone NVR User Guide 4 Web Service Section 3 Alternatively, you can use the Open All/Close All button to enable/disable all-channels at once. When you click the button, it becomes yellow. Section 4 Instant Record button. When you click this button, it becomes yellow and the system begins manual record mode.
Page 145: Wan Mode
Hybrid Standalone NVR User Guide 4 Web Service Section 8 Image. Refer to Image Setup on page 139 for detailed information. Alarm Out. Refer to Alarm Output on page 140 for detailed information. 4.4.2 WAN Mode After logging into the WAN mode, the main window appears. Figure 4-5 Differences in WAN mode from LAN mode: 1.
Page 146: Real-Time Monitor
PictureDownload . 4–Audio. Turn audio on or off. Note: ADT does not support Audio functions at this time. 5–Close video. Turn off the video. NVR32xx-P Series User Guide...
Page 147: Pan/Tilt/Zoom (Ptz) Panel
Hybrid Standalone NVR User Guide 4 Web Service 4.4.4 Pan/Tilt/Zoom (PTZ) Panel Before initiating the Pan/Tilt/Zoom (PTZ) operation, make sure that you have properly set the PTZ protocol. Refer to the section titled PTZ on page 217. There are eight direction keys. In the middle of the eight direction keys, there is a 3D intelligent positioning key.
Page 148 Hybrid Standalone NVR User Guide 4 Web Service Preset 1. Select Preset from the dropdown list. 2. Turn the camera to the corresponding position and enter the pre-set value from 1-80. 3. Click the Add button to add the preset. Tour 1.
Page 149: Image Setup
Hybrid Standalone NVR User Guide 4 Web Service 1. Input the corresponding aux value, 1-8. 2. You can select one option. 3. Click the Aux On or Aux Off buttons. Light / Wiper 1. Turn on or turn off the light/wiper. Reset 1.
Page 150: Alarm Output
Hybrid Standalone NVR User Guide 4 Web Service brightness contrast saturation 4.4.6 Alarm Output Here you can enable or disable the alarm signal of the corresponding port. NVR32xx-P Series User Guide...
Page 151: Playback (Search)
Hybrid Standalone NVR User Guide 4 Web Service 4.5 Playback (Search) This section describes how to search for a recorded file and then view it. 1. Click the Playback Tab button. The screen shown in Figure 4-6 appears. 2. Set the record type, record date, window display mode and channel name. 3.
Page 152 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-7 6. Use the Playback Control Bar to implement various operations such as Play, Pause, Stop, Slow Play, and Fast Play. During playback you can view the playback channel and device IP. 7.
Page 153 Hybrid Standalone NVR User Guide 4 Web Service Load More This interface is for searching records or pictures. You can select record channel, record type and recording time to download. There are two download types: the download by file interface is shown in Figure 4-9 and the download by time interface is shown in Figure 4-10.
Page 154: Alarm
Hybrid Standalone NVR User Guide 4 Web Service Figure 4-11 4.6 Alarm The Alarm tab enables you to set the device alarm type and alarm sound setup. Figure 4-12 Refer to the following for detailed information. 4.6.1 Alarm Type Motion Detect. The system alarms when a motion detection alarm occurs. Video Masking.
Page 155: Operation
Hybrid Standalone NVR User Guide 4 Web Service Disk Full. The system alarms when the hard disk is full. IPC External Alarm. The system detects the alarm signal from the front-end device and activates the local NVR. No Signal. The system alarms when the network camera and the NVR are disconnected. 4.6.2 Operation Prompt.
Page 156 Hybrid Standalone NVR User Guide 4 Web Service name, manufacturer and type. 2. Click the item name to refresh the display order. 3. Click the IP address and the system displays the IP addresses from small to large. 4. Click the IP address again and the icon appears. The system displays IP addresses from large to small.
Page 157: Conditions
Hybrid Standalone NVR User Guide 4 Web Service Note: • This NVR supports the IPC from many popular manufacturers such as Sony, Hitachi, Axis, Samsung, Dynacolor, Arecont, Onvif and Dahua. • The system default IP address is 192.168.0.0. If you do not input an IP address, the system will not add the current IP address.
Page 158 Hybrid Standalone NVR User Guide 4 Web Service • Auto: The auto white balance is on. The system can automatically compensate the color temperature. • Sunny: The threshold of the white balance is in the sunny mode. • Night: The threshold of the white balance is in the night mode. •...
Page 159: Video And Audio
Hybrid Standalone NVR User Guide 4 Web Service 4.7.1.2 Video and Audio Encode Video compression settings are made in the Encode screen. Figure 4-16 Refer to the following for detailed information. After making your selections, click Save. Channel Select a single channel number or All from the dropdown list. Video Enable Check the box to enable Sub Stream (lower bandwidth) video.
Page 160 This lists the recommended bit rate range according to the resolution and frame rate you have set. Audio Enable Check the box to enable audio recording. Note: ADT does not support Audio functions at this time. Audio Encode If enabled, make your selection from the dropdown: G711a, PCM or G711u.
Page 161 Hybrid Standalone NVR User Guide 4 Web Service Snapshot You can use the Snapshot screen for setting parameters for taking still images. Figure 4-17 Refer to the following for detailed information. After making your selections, click Save. Channel Select a single channel number or All from the dropdown list. Mode Select Timing (schedule) or Event (activation).Timing snapshot is valid during the specified period you set.
Page 162 Hybrid Standalone NVR User Guide 4 Web Service Video Overlay The Overlay screen provides options to be displayed over the video screen. Figure 4-18 Refer to the following for detailed information. After making your selections, click Save. Channel Select a single channel number from the dropdown list. Cover-Area (Privacy Mask)—Monitor Click the Set button to enable a privacy mask for the specified video in the Monitor (playback) video.
Page 163: Channel Name
Hybrid Standalone NVR User Guide 4 Web Service Path Use the Path screen to set the location if where snapshot images and video recording files are stored. 1. Click the Browse button to set the saved path for the snapshot image ( on the live Preview screen) and the recording storage path ( on the live Preview screen).
Page 164: Network
Hybrid Standalone NVR User Guide 4 Web Service Figure 4-21 4.7.2 Network 4.7.2.1 TCP/IP The TCP/IP screen is for setting up network parameters. Figure 4-22 Refer to the following for detailed information. Mode Select between two modes: Static or DHCP. NVR32xx-P Series User Guide...
Page 165 Hybrid Standalone NVR User Guide 4 Web Service MAC Address Displays the host MAC address. Displays the Maximum Transmission Unit (MTU) value of the network adapter. The value ranges from 1280-7200 bytes. The default setup is 1500 bytes. MTU modification can affect current network service and may result in a reboot of the network adapter.
Page 166: Connection
HTTP Port. The default value is 80. You can input the actual port number. RTSP Port. The default value is 554. 4.7.2.3 WIFI This feature is not supported by ADT at this time. 4.7.2.4 3G This feature is not supported by ADT at this time.
Page 167: Ddns
Hybrid Standalone NVR User Guide 4 Web Service The NVR connects to the internet via PPPoE after reboot. You can get the IP address from the WAN in the IP address column. Note: You must use the previous IP address in the LAN to login the device. Go to the IP address item to see the current device information.
Page 168 Hybrid Standalone NVR User Guide 4 Web Service Refer to the following for detailed information. Enable. Check the box to enable this function. Server Type. Select the DDNS protocol from the dropdown list and then enable DDNS function Server IP. DDNS server IP address Server Port.
Page 169: Ip Filter
Hybrid Standalone NVR User Guide 4 Web Service 4.7.2.7 IP Filter After you have enabled the trusted sites function, only the IPs listed below can access current NVR. If you enable the blocked sites function, the following listed IP addresses cannot access the current NVR.
Page 170 Hybrid Standalone NVR User Guide 4 Web Service Refer to the following for detailed information. Enable Check this box to enable email function. SMTP Server Input the server address and then enable this function. Port Default value is 25. Anonymous Enable for servers that support the anonymity function, which allows you to automatically login anonymously.
Page 171: Upnp
Hybrid Standalone NVR User Guide 4 Web Service Update Period (Interval) This function enables the system to send out a test email for checking the connection. Check the box to enable this function and then set the corresponding interval. The system can send out the email regularly as you set here.
Page 172: Snmp
Hybrid Standalone NVR User Guide 4 Web Service 4.7.2.10 SNMP The SNMP screen enables the communication between the network management work station software and the proxy of the managed device. Figure 4-29 Refer to the following for detailed information. SNMP Port The listening port of the proxy program of the device.
Page 173: Multicast
Hybrid Standalone NVR User Guide 4 Web Service Trap Port The destination port of the Trap information from the proxy program of the device. It is for the gateway device and the client end PC in the LAN to exchange the information. It is a non-protocol connection port.
Page 174: Alarm Center
IMPORTANT: The server IP address can also be the domain but you must register a domain name before you run the proxy device server. 4.7.2.13 Alarm Center This feature is not supported by ADT. 4.7.2.14 HTTPS This page can be used to create a server certificate or download a root certificate.
Page 175: Create Server Certificate
Hybrid Standalone NVR User Guide 4 Web Service A root certificate is either an unsigned public key certificate or a self-signed certificate that identifies the Root Certificate Authority. On this screen you can set to ensure that the PC can successfully login via HTTPS to guarantee communication data security.
Page 176 Hybrid Standalone NVR User Guide 4 Web Service Download Root Certificate 1. Use the following steps to create a Root Certificate. 2. Click the Download Root Certificate button The following dialog box appears. Figure 4-35 3. Click the Open button. The following screen appears. Figure 4-36 4.
Page 177 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-37 5. Click the Next button to continue. Now select a location for the certificate. Figure 4-38 6. Click the Next button. A message appears that the certificate import process is complete. NVR32xx-P Series User Guide...
Page 178 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-39 7. Click the Finish button. The following security warning dialog appears. Figure 4-40 8. Click Yes button. A message appears confirming that the certificate download is complete. Figure 4-41 NVR32xx-P Series User Guide...
Page 179: Event
Hybrid Standalone NVR User Guide 4 Web Service View and Set the HTTPS Port 1. Navigate to Set > Network >Connection. In the Connection screen, you can see that the HTTPS default value is 443. Figure 4-42 Login Open a browser window and enter https://xx.xx.xx.xx:port, where xx.xx.xx.xx: is your device IP or domain name and Port is your HTTPS port.
Page 180 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-43 The following describes the Detect window: Enable Check the box to enable the motion detection function. Then select a channel to be enabled from the dropdown list. Period This feature activates the Motion Detection function in the specified time periods. To set the Motion Detect period: 1.
Page 181 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-44 Note: • Set the Motion Detect record period. • Navigate to Storage > Schedule to set the current channel as a scheduled recording. Anti-dither This feature sets a delay period before triggering the next Motion Detection event, to avoid re- triggering on the same event.
Page 182 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-45 Record Channel Check the box to enable, and the click the buttons for the channels that you want recorded when the event is triggered. The selected channels are highlighted. Delay To avoid rerecording the same event, enter the number of seconds to wait after the event has ended before a new recording can begin.
Page 183 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-46 Tour When an alarm occurs, this feature presents an alternating display (much like a slideshow) of the channel(s) you set to record. Check the box to enable, and the click the buttons for the channels that you want included in the tour.
Page 184 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when a motion detection event occurs. Note: This feature is not supported by ADT at this time. Video Loss Use the Video Loss screen for triggering up alarms when no video signal is detected.
Page 185 Hybrid Standalone NVR User Guide 4 Web Service Period This feature activates the Video Loss function in the specified time periods. To set the Video Loss period: 1. Click the Setup button. 2. In the resulting setup dialog, select a day of the week from the drop-down menu. 3.
Page 186 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when a motion detection event occurs. Note: This feature is not supported by ADT at this time. NVR32xx-P Series User Guide...
Page 187 Hybrid Standalone NVR User Guide 4 Web Service Tampering The Tampering feature alerts you when the detected motion signal exceeds the sensitivity threshold set here. Note: Tampering does not support anti-dither, sensitivity, or region setup. Figure 4-52 Enable Check the box to enable the Tampering function. Then select a channel from the dropdown list. Period This feature activates the Tampering function for the specified periods.
Page 188 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-53 Sensitivity There are six levels. The sixth level has the highest sensitivity. Record Channel The system automatically activates to record selected channels once a motion detection alarm occurs. Check the box to enable, and the click the buttons for the channels that you want recorded. The selected channels are highlighted.
Page 189 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when a tampering event occurs. Note: This feature is not supported by ADT at this time. NVR32xx-P Series User Guide...
Page 190: Alarm
Hybrid Standalone NVR User Guide 4 Web Service 4.7.3.2 Alarm This area provides you with the opportunity to set up and activate various alarms. Select from these setup tabs: Local Alarm, Net Alarm, IPC External Alarm and IPC Offline Alarm. Local Alarm The system detects the alarm signal from the local alarm input port.
Page 191 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-56 Select Sunday to Saturday from the dropdown list. Be sure to check the box to the left of the period to enable it. To set your own business day and non-business days, select work day or non-work day from the drop down list, and then click the Setup button.
Page 192 Hybrid Standalone NVR User Guide 4 Web Service Alarm Out Check the box to enable the external alarm when the event triggers. In the boxes to the immediate right, enable which camera(s) will record when the event occurs. Latch Select the time in seconds that the system delays after the external alarm has ended before turning off the alarm and the activated output.
Page 193 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when an alarm occurs. Note: This feature is not supported by ADT at this time. Network Alarm The system detects the alarm signal from the network.
Page 194 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-59 Select Sunday to Saturday from the dropdown list. Be sure to check the box to the left of the period to enable it. To set your own business day and non-business days, select work day or non-work day from the drop down list, and then click the Setup button.
Page 195 Message. If a 3G network is connected, a message is sent when an alarm occurs. Note: This feature is not supported by ADT at this time. Note: A network alarm is an alarm signal using TCP/IP. You can use NET SDK to activate a network alarm.
Page 196 Hybrid Standalone NVR User Guide 4 Web Service IPC External Alarm The system detects the alarm signal from the front-end device and activates the local NVR. Figure 4-61 Enable Check the box to activate the Alarm function. Alarm Select the channel number from the dropdown, or else select All. Period Click the Setup button.
Page 197 Hybrid Standalone NVR User Guide 4 Web Service Select Sunday to Saturday from the dropdown list. Be sure to check the box to the left of the period to enable it. To set your own business day and non-business days, select work day or non-work day from the drop down list, and then click the Setup button.
Page 198 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when an alarm occurs. Note: This feature is not supported by ADT at this time. NVR32xx-P Series User Guide...
Page 199 Hybrid Standalone NVR User Guide 4 Web Service IPC Offline Alarm The system generates an alarm when the network camera is offline and, if desired, activates a recording, PTZ, snapshot, etc. The alarm lasts until the IPC and the NVR resume their connection. Figure 4-64 Enable Check the box to activate the Alarm function.
Page 200 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when an alarm occurs. Note: This feature is not supported by ADT at this time. NVR32xx-P Series User Guide...
Page 201: Abnormality
Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when the anomalous event occurs. Note: This feature is not supported by ADT at this time. 3. Click Save.
Page 202 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when the anomalous event occurs. Note: This feature is not supported by ADT at this time. 4. Click Save.
Page 203 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when the anomalous event occurs. Note: This feature is not supported by ADT at this time. 3. Click Save.
Page 204: Storage
Hybrid Standalone NVR User Guide 4 Web Service Figure 4-71 4.7.4 Storage 4.7.4.1 Schedule In the Schedule screen you can add or remove scheduled recordings. See Figure 4-72. There are four recording modes: Regular (auto), Motion Detect, Alarm and Motion Detect with Alarm. Make sure you have enabled the corresponding record mode in the Setup >...
Page 205 Hybrid Standalone NVR User Guide 4 Web Service Options  Channel. Select the desired channel number. Select All if you want to set for all channels.  Pre-record. The system can pre-record the video before the event occurs into the file. The value ranges from 1 to 30 seconds depending on the bit stream.
Page 206: Hdd Manage
Hybrid Standalone NVR User Guide 4 Web Service Figure 4-74 4. Set the corresponding recording range for each time period. 5. Repeat for other time periods if desired. 6. Check the box for the desired type of recordings: Regular, Motion Detect, Alarm or Motion Detect with Alarm.
Page 207 Hybrid Standalone NVR User Guide 4 Web Service HDD Setting Use the HDD Setting page to assign a hard drive to an HDD Group. See Figure 4-76. To set the HDD to a Group: 1. In the row of the hard drive in question, use the drop-down to select the corresponding HDD Group number.
Page 208: Record Control
Hybrid Standalone NVR User Guide 4 Web Service To use the FTP feature: 1. Check the Enable box to activate the FTP function. 2. Input the FTP account information: • FTP Server IP number • Port number • User Name and Password you use to log into the FTP. •...
Page 209: Storage
Hybrid Standalone NVR User Guide 4 Web Service Schedule Channel records as you have set in recording setup (Main Menu > Setting > Schedule) Manual Manual recording has highest priority, overriding the automatic recording setup. Stop Stop recording, overriding the automatic record setup. To use the Record page: 1.
Page 210 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-80 Image Storage The Image Storage interface is used set the corresponding HDD group to save a snapshot picture. Figure 4-81 NVR32xx-P Series User Guide...
Page 211: Setting
Hybrid Standalone NVR User Guide 4 Web Service 4.7.5 Setting 4.7.5.1 General The general screen includes General, Date & Time and Holiday Setup tabs. General Available options contained in the General tab are as follows. After making your selections, click the Save button.
Page 212 Hybrid Standalone NVR User Guide 4 Web Service • Overwrite. If the current HDD becomes full and there is no secondary HDD or else it too has insufficient space, the system overwrites the previous files. Pack Duration Specify the recording duration. The value ranges from 1 to 120 minutes; the default value is 60 minutes.
Page 213: Holiday Setup
Hybrid Standalone NVR User Guide 4 Web Service DST Type Set the DST beginning time and ending times, in either a date or week format. Select the radio button that represents how you want the date displayed: o Date. Uses the format selected in the Date Format field. o Day of Week.
Page 214: Account
Hybrid Standalone NVR User Guide 4 Web Service 1. Check the Holiday Enable box. 2. In the calendar, select the date(s) and year you want to set as a holiday for the current channel. 3. Click Save. 4.7.5.2 Account The Account page enables you to add new users or modify the accounts of existing ones. You can assign add or delete accounts, change rights or change passwords or assign users to groups.
Page 215 Hybrid Standalone NVR User Guide 4 Web Service To add a user: 1. Click the Add User button. The Add User dialog appears. 2. Enter the User Name, which can be a maximum of 6 characters, including alpha-numeric characters and the underline. 3.
Page 216 Hybrid Standalone NVR User Guide 4 Web Service To delete a user: 1. Click the Delete button . The Delete User dialog opens. 2. Click Save to confirm. Figure 4-87 The default user cannot be deleted. To modify a user: 1.
Page 217 Hybrid Standalone NVR User Guide 4 Web Service Group Click the Group tab to add/remove groups or to modify a group account. Figure 4-89 To add a group: 1. Click the Add Group button. The Add Group dialog opens. 2. Enter the Group Name, which can be a maximum of 6 characters, including alpha-numeric characters and the underline.
Page 218: Display
Hybrid Standalone NVR User Guide 4 Web Service To delete a group: 1. Click the Delete button . The Delete Group dialog opens. 2. Click Save to confirm. To modify a group: 1. Click the Modify button . The Modify Group dialog opens. 2.
Page 219 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-92 Resolution Use the drop-down list to make your selection: • 1280x1024 (default) • 1280x720 • 1024x768 • 800x600 Note: The system must reboot to activate the current setup. Transparency Move the slider to adjust transparency. The value ranges from 128 to 255. Time Display Check the box to enable the system time to be displayed on the video monitor.
Page 220 Hybrid Standalone NVR User Guide 4 Web Service Tour The Tour feature presents an alternating display (much like a slideshow) of the channel(s) you have set to record. The Tour tab enables you to set the tour interval, split mode, tour type. Make your selections and then click Save.
Page 221 Hybrid Standalone NVR User Guide 4 Web Service • View 1 displays 1 window • View 4 displays 4 windows • View 8 displays 8 windows, etc. Example using Split The following example details how to set up add channel groups to a 4- window split and then change the order in which the channels will be displayed.
Page 222 Hybrid Standalone NVR User Guide 4 Web Service 3. Click numbers 1, 3, 5, and 7 to select only odd channels for this new group. 4. Click Save. Group number 3 is added, which includes only odd channels. 5. Click the + button again but this time click numbers 2, 4, 6, and 8 to select only even channels for the new group number 4, and click Save.
Page 223 Hybrid Standalone NVR User Guide 4 Web Service 8. To completely remove groups 1 and 2, select them and then click the button. What were – labeled as groups 3 and 4 are now groups 1 and 2, respectively. Motion Tour /Alarm Tour Type Set the type of tour split to show for the Motion Detect Tour/Alarm Tour: •...
Page 224: Alarm Out
Hybrid Standalone NVR User Guide 4 Web Service 4.7.5.4 Alarm Out This function enables you to set the alarm output mode: auto/manual/stop. Figure 4-94 4.7.5.5 Default The Default page enables you to reset default settings to all sections of the web service from one location.
Page 225: Import & Export
Hybrid Standalone NVR User Guide 4 Web Service 4.7.5.6 Import & Export The Import & Export page provides a method for using parameters set for either the Web Service or local PC-based system and transferring them to the other location. Figure 4-96 Browse.
Page 226: Upgrade
Hybrid Standalone NVR User Guide 4 Web Service Figure 4-97 4.7.5.8 Upgrade The Upgrade page enables you to install the latest firmware files. To upgrade you NVR: 1. Click the Browse button. 2. In the ensuing dialog, navigate to and select the upgrade file. The filename will have a .bin extension.
Page 227: Rs232
Hybrid Standalone NVR User Guide 4 Web Service 4.7.5.9 RS232 This dialog is for setting up your RS232 connections. Figure 4-99 The dialog contains five items: Function There are various devices for you to select from the dropdown: • Console (the default) is for use with the COM or software to upgrade or debug the program. •...
Page 228: Ptz
Hybrid Standalone NVR User Guide 4 Web Service 4.7.5.10 PTZ The Pan/Tilt/Zoom (PTZ) interface is shown in Figure 4-100. Before setup, check that the following connections are correct: • PTZ and decoder connection • Decoder address setup • Decoder A (B) line connects with NVR A (B) line Click the Save button after you complete the setup.
Page 229: Preview Control
Hybrid Standalone NVR User Guide 4 Web Service PTZ Type There are two options: Local or Remote. Select the Remote type if you are connecting to the network PTZ. Protocol Select the corresponding dome protocol such as PELCO D. Address Set the corresponding PTZ camera address.
Page 230: Information (Info)
Hybrid Standalone NVR User Guide 4 Web Service 4.8 Information (Info) 4.8.1.1 Version The version screen displays system hardware features, software version, release date, etc. The listed information is for reference only. Figure 4-103 4.8.1.2 Log This screen displays the system log. See Figure 4-104. Refer to the following for parameter information.
Page 231: Online User
Hybrid Standalone NVR User Guide 4 Web Service Backup Click this button to backup log files to the local PC. Figure 4-104 4.8.1.3 Online User The Online User page is shown below in Figure 4-105. Figure 4-105 NVR32xx-P Series User Guide...
Page 232: Logout
Hybrid Standalone NVR User Guide 4 Web Service 4.9 Logout Click the Logout button to log out of the Web Service. The system reverts to the Login dialog. You must input your username and password to log in again. Figure 4-106 4.10 Un-install Web Service You can use web un-install tool “uninstall web.bat”...
Page 233: Appendix A Troubleshooting, Daily Maintenance And Glossary
Appendix A Troubleshooting, Daily Maintenance Appendix A Troubleshooting, Daily Maintenance and Glossary Troubleshooting 1. NVR does not boot up properly Possible reasons: • Input power is not correct • Power connection is not correct • Power switch button is damaged •...
Page 234 • HDD malfunction • NVR hardware malfunction 8. There is no audio when monitoring or during playback ADT does not support Audio functions at this time. 9. Time display is not correct Possible reasons: • Setup is not correct •...
Page 235 Appendix A Troubleshooting, Daily Maintenance 11. Motion detection function does not work Possible reasons: • Period setup is not correct • Motion detection zone setup is not correct • Sensitivity is too low • For some versions, there is a hardware limitation 12.
Page 236 Appendix A Troubleshooting, Daily Maintenance 16. Keyboard cannot control NVR Possible reasons: • NVR serial port setup is not correct • Address is not correct • When there are several switchers, power supply is not sufficient • Transmission distance is too far 17.
Page 237 Appendix A Troubleshooting, Daily Maintenance 22. There is no video. The screen is in black. Possible reasons: • IPC IP address is incorrect • IPC port number is incorrect • IPC account (user name/password) incorrect 23. The displayed video is not complete Possible reasons: •...
Page 238 Appendix A Troubleshooting, Daily Maintenance Daily Maintenance • Check and maintain the device regularly. • Regularly use a brush to clean the board, socket connector and chassis. • Properly ground the device to protect against video disturbances. • Keep the device away from static or induced voltage. •...
Page 239 Appendix A Troubleshooting, Daily Maintenance Glossary DHCP. Dynamic Host Configuration Protocol is one of the TCP/IP network protocols principally used to assign temporary IP addresses to computers on a network. DDNS. Dynamic Domain Name Server is a service that maps Internet domain names to IP addresses. This service is useful to anyone who wants to operate a server (web server, mail server, FTP server, etc.) connected to the Internet with a dynamic IP or to someone who wants to connect to an office computer or server from a remote location with software.
Page 240: Appendix B Specifications
H.264/MPEG4 Standard Compression For H.264, supports 16 channel D1, 8 channel 720, 4 channel 1080P Audio G.711A Compression Note: ADT does not support Audio Functions at this time. Video Monitor Video Input 4 Channel 8 Channel 16 Channel 4-CH composite...
Page 241 Appendix B Specifications Feature Parameter Description Hard Disk Hard Disk 2 built-in SATA port supports 2 HDD up to 8TB Record and Record Mode Manual, Motion Detection, Schedule and Alarm recording Playback Priority: Manual > Alarm > Motion Detection > Schedule Playback Repeat When hard disk is full, system can overwrite previous video file Record Search...
Page 242 Appendix B Specifications Feature Parameter Description Alarm Input 4/8/16 channel product supports 4/8/16 channel alarm inputs, respectively Output 3 channel alarm output Relay output Relay 30VDC, 1A，125VAC, 0.5A (Activation output ), including one controllable +12VDC output Interface USB Interface Two USB 2.0 ports Network RJ45 10M/100M self-adaptable Ethernet port connection...
Page 243: Appendix C Compatible Network Cameras
Appendix C Compatible Network Cameras Appendix C Compatible Network Cameras Please note all the models in the following list are for reference only. Manufacturer Model Version Video Encode Protocol AXIS P1346 5.40.9.2 H264 ONVIF, Private P3344/P3344-E 5.40.9.2 H264 ONVIF, Private P5512 H264 ONVIF, Private...
Page 244 Appendix C Compatible Network Cameras Manufacturer Model Version Video Encode Protocol CP-NC9W-K 6.E.2.7776 H264 Private CP-ND10-R cp20111129ANS H264 ONVIF CP-ND20-R cp20111129ANS H264 ONVIF CP-NS12W-CR cp20110808NS H264 ONVIF VS201 cp20111129NS H264 ONVIF CP-NB20-R cp20110808BNS H264 ONVIF CP-NT20VL3-R cp20110808BNS H264 ONVIF CP-NS36W-AR cp20110808NS H264 ONVIF...
Page 245 Appendix C Compatible Network Cameras Manufacturer Model Version Video Encode Protocol WV-SW355H 1.41 H264, MPEG4 Private, ONVIF WV-SW352H H264, MPEG4 Private, ONVIF － WV-SW152E 1.03 H264, MPEG4 Private, ONVIF WV-SW558H H264, MPEG4 Private, ONVIF － WV-SW559H H264, MPEG4 Private, ONVIF －...
Page 246 Appendix C Compatible Network Cameras Manufacturer Model Version Video Encode Protocol SNC-DH240-T 1.73.01 H264 Private, ONVIF SNC-CH260 1.74.01 H264 Private, ONVIF SNC-CH280 1.73.01 H264 Private, ONVIF SNC-RH-124 1.73.00 H264 Private, ONVIF SNC-RS46P 1.73.00 H264 Private, ONVIF SNC-ER550 1.74.01 H264 Private, ONVIF SNC-ER580 1.74.01 H264...
Page 247: Appendix D Compatible Backup Device List
Appendix D Compatible Backup Device List Appendix D Compatible Backup Device List Compatible USB Drive List Manufacturer Model Capacity Aigo L8315 16GB Kingax Super Stick 128M Kingax Super Stick 256M Kingax Super Stick 512M Kingax Super Stick Kingax Super Stick Kingston DataTraveler II Kingston...
Page 248 Appendix D Compatible Backup Device List Compatible SD Card List Brand Standard Capacity Card Type Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Micro-SD Sandisk Micro-SD Transcend SDHC6 16GB Compatible Portable HDD List Brand Model Capacity Aigo H8169 500GB Iomega Iomega RPHD-CG" RNAJ50U287 250GB Netac Netac...
Page 249 Appendix D Compatible Backup Device List Compatible SATA HDD List Manufacturer Series Model Capacity Port Mode HitachiCinemaStar™ Hitachi HCP725050GLA380 500G SATA 5K500 HitachiCinemaStar™ Hitachi HCT721050SLA360 500G SATA 7K1000.B HitachiCinemaStar™ Hitachi HCT721075SLA360 750G SATA 7K1000.B HitachiCinemaStar™ Hitachi HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G...
Page 250 Appendix D Compatible Backup Device List Manufacturer Series Model Capacity Port Mode Seagate Seagate Pipeline HD2 ST3250412CS 250G SATA Seagate Seagate Pipeline HD2 ST3320311CS 250G SATA Seagate Seagate Pipeline HD2 ST3500414CS 500G SATA Seagate Seagate Pipeline HD2 ST3500312CS 500G SATA Seagate Seagate Pipeline HD2 ST31000424CS SATA...
Page 251 Appendix D Compatible Backup Device List Manufacturer Series Model Capacity Port Mode Western Digital Cariar SE16 WD7500KS 750G SATA Western Digital Cariar SE16 WD5000KS 500G SATA Western Digital Cariar SE16 WD4000KD 400G SATA Western Digital Cariar SE16 WD3200KS 320G SATA Western Digital Cariar SE16 WD2500KS...
Page 252: Appendix E Compatible Cd/Dvd Device List
Appendix E Compatible CD/DVD Device List Appendix E Compatible CD/DVD Device List Manufacturer Model Port Type Type BenQ 5232WI DVD-RW Panasonic SW-9588-C SATA DVD-RW Samsung TS-H653A SATA DVD-RW Sony DRX-S50U DVD-RW Sony DRX-S70U DVD-RW Sony AW-G170S SATA DVD-RW Sony DRX-S50U DVD-RW NVR32xx-P Series User Guide...
Page 253: Appendix F Compatible Display List
Appendix F Compatible Display List Appendix F Compatible Display List Refer to the following table for compatible displays. Brand Model Dimension (in inches) BENQ (LCD) ET-0007-TA 19-inch (wide screen) BENQ (LCD) Q7T4 17-inch BENQ (LCD) Q7T3 17-inch BENQ (LCD) G900HD 18.5-inch BENQ (LCD) G2220HD...
Page 254: Index
Index Index Abnormality, Email, Account Setup, Email Setup, Advanced Menu, Encode Setup, Alarm, eSATA, IPC External, Event, Local, Export, Network, Output, Setup, Status, Features, Alarm Connection, Front Panel, Alarm Out FTP, Setup, FTP Setup, Alarm Output, Auto Maintenance, Auto Network Registration, General Setup, GUI Setup, Backup,...
Page 255 Index Manual Recording, No Disk, Menu, No Disk Space, Advanced NTP, Abnormality, NTP Setup, Account, Alarm Output, Context Menu, Auto Maintain, Features, Config Backup, Front Panel, HDD Management, Keyboard, Manual Record, Overview, Info, Rear Panel, BPS, Specifications, HDD Info, Virtual Keyboard, Log, Network Info, Online Users,...
Page 256 Index Server Certificate, Setting Menu, Tampering, Setup TCP/IP, Abnormality, Tour, Account, Tour Setup, Alarm, Troubleshooting, Alarm Out, Auto Maintain, Channel Name, Conditions, Uninstall Date and Time, Web Service, Default, Upgrade, Display, UPnP, Encode, UPnP Setup, FTP, GUI, Holiday, Import & Export, Version, IPC Upgrade, Video Loss,...

ADT NVR32**-P Series User Manual

1 NVR Overview

2 Getting Started

3 Menu Operations

4 Web Service

Appendix A Troubleshooting, Daily Maintenance and Glossary

Appendix B Specifications

Appendix C Compatible Network Cameras

Appendix D Compatible Backup Device List

Appendix E Compatible CD/DVD Device List

Appendix F Compatible Display List

Quick Links

Need help?

Questions and answers

Related Manuals for ADT NVR32**-P Series

Summary of Contents for ADT NVR32**-P Series

Table of Contents
