Summary of Contents for ADT NVR7400 Series

  • Page 1 ® NVR7400 Series Network Video Recorder User Guide...
  • Page 2: Typographic Conventions

    ©2015 ADT LLC dba ADT Security Services. All rights reserved. ADT, the ADT logo, 800 ADT.ASAP and the product/service names listed in this document are marks and/or registered marks. Unauthorized use is strictly prohibited.
  • Page 3: Table Of Contents

    Playback by Time ..........................25 2.5.4 Mark Playback .............................26 Backup ................................28 2.6.1 File Backup ............................28 2.6.2 USB Device Auto Pop-up........................29 Snapshot .................................30 2.7.1 Schedule Snapshot ..........................31 2.7.2 Activation Snapshot ...........................32 2.7.3 Manual Record/Snapshot ........................34 2.7.4 Holiday Record/Snapshot ........................36 NVR7400 Series User Guide...
  • Page 4 General ..............................94 3.6.2 Display Setup ............................98 3.6.3 RS232 ..............................101 3.6.4 Pan/Tilt/Zoom (PTZ) ........................102 3.6.5 Account .............................. 111 3.6.6 Auto Maintenance ........................... 115 3.6.7 Import/Export ........................... 116 3.6.8 Default ..............................117 3.6.9 Upgrade ............................. 118 NVR7400 Series User Guide...
  • Page 5 Setting ..............................203 Information (Info) ............................222 Logout ................................224 4.10 Un-install Web Service ..........................224 Appendix A Troubleshooting, Daily Maintenance and Glossary..........225 Appendix B Specifications ........................ 233 Appendix C Compatible Network Cameras .................. 235 NVR7400 Series User Guide...
  • Page 6 Appendix D Compatible Backup Devices ..................239 Appendix E Compatible SATA HDDs ....................241 Appendix F Compatible CD/DVD Devices ..................245 Appendix G Compatible Displays ....................246 Index ................................ 247 NVR7400 Series User Guide...
  • Page 7 All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. ADT assumes no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.
  • Page 8 Features Overview The ADT NVR7400 Series network video recorder is a digital monitoring product designed for ® security applications. It adopts embedded Linux OS to maintain reliable operation and the H.264 compression algorithm to provide high quality, low bit streams. The frame-by-frame playback function is ideal for detailed analysis.
  • Page 9 Support log file. o Local GUI output. Shortcut menu operation via mouse. o IR control function (For some series product only.). Shortcut menu operation via remote control. o Support IPC or NVS remote video preview and control NVR7400 Series User Guide...
  • Page 10 Preface • Peripheral Equipment Management o Supports peripheral equipment management such as protocol setup and port connection o Supports transparent data transmission such as RS232, RS422, and RS485 NVR7400 Series User Guide...
  • Page 11: Nvr Overview

    Also serves as the Backspace function to delete the previous character (to the left of the cursor) when pressed for 1.5 seconds. In HDD management screen: switches between HDD recordings and other information (Menu prompt). NVR7400 Series User Guide...
  • Page 12 1-16 channel is recording. Status Operation indicator. Lights to indicate that the DVR is operating properly. Remote Active indicator. Lights to indicate that remote control is active. IR receiver. Receives the signal from the remote control. NVR7400 Series User Guide...
  • Page 13: Rear Panel

    RS-232 port for general COM debug to configure IP address or transfer transparent COM data Note: When connecting the Ethernet port, use the crossover cable to connect the PC and use the straight cable to connect to the switcher or router. NVR7400 Series User Guide...
  • Page 14: Alarm Connections

    485 communication port: controls the PTZ decoder Note: When your alarm input device is using external power, make sure the device and the NVR have the same ground. Also, make sure that there is power to the external alarm device. NVR7400 Series User Guide...
  • Page 15: Alarm Input Port

    When connecting the ground port of the alarm device to the NVR, you can use either of the GND ports ( • When there is peripheral power supplied for the alarm device, please make sure it is grounded with the NVR. NVR7400 Series User Guide...
  • Page 16: Alarm Input And Output Port

    1000VAC 1minute Between touches with same Surge voltage 1500V (10 x 160us) polarity Open time 3ms max Close time 3ms max Longevity Mechanical 50 x 106 times (3Hz) Electrical 200 x103 times (0.5Hz) Temperature -40°C to +70°C NVR7400 Series User Guide...
  • Page 17: Network Connection

    2 Getting Started 1.3.4 Network Connections Figure 1-5 NVR7400 Series User Guide...
  • Page 18: Bidirectional Talk

    Login to the Web Service and click the Start Talk button to enable Bidirectional Talk (as described on page 134). Listening Speak into the microphone or pickup connected to the remote PC and the audio is received at the earphone or speaker connected to the DVR. Figure 1-7 NVR7400 Series User Guide...
  • Page 19: Remote Control

    2 Getting Started 1.5 Remote Control The following describes the remote control. Figure 1-8 NVR7400 Series User Guide...
  • Page 20 Alpha Numeric Characters. Press to input a number 0-9, upper case letter or lower case letter, using the Shift key to toggle between character types. Shift -/- - To enter a number greater than 9, first press the key, and then input the -/- - desired number. NVR7400 Series User Guide...
  • Page 21: Getting Started

    The initial login credentials are: User Name: admin. Password: admin. Note: The user will be forced to change the credentials after the first login. 3. Use a USB mouse, remote control, or the NVR front panel buttons to complete the login. NVR7400 Series User Guide...
  • Page 22 6. Press the Enter key. The keyboard disappears. Note: For security reasons, modify your password after your first login. • Three (3) sequential login failures will result in a system alarm • Five (5) sequential failures will result in account lockout NVR7400 Series User Guide...
  • Page 23: Virtual Keyboard

    This keypad appears only when the entry must be numeric. Note: Because the numeric pad appears on both upper case and lower case virtual keyboards, you do not need to change keyboards to make numeric entries at login. NVR7400 Series User Guide...
  • Page 24: Righ Menu

    3. If you click Cancel to exit the startup sequence, a popup message asks if you are sure. Click OK. 4. If you do not want the Startup Wizard to appear the next time you start up the system, clear the Startup box. NVR7400 Series User Guide...
  • Page 25: Logout / Shutdown

    To log out using the Power switch: Toggle the Power switch on the rear panel to turn off the NVR. This method does not require that you enter the username and password to complete the operation. NVR7400 Series User Guide...
  • Page 26: Preview (Live Viewing)

    Click to initiate audio between the NVR and the remote PC. Refer to section 1.4 on page 8. Remote device Click to open the remote device connection interface. Refer to section 3.2.1 on page 41 for detailed information. NVR7400 Series User Guide...
  • Page 27: Navigation Bar

    Opens the Remote Camera screen; see section 3.2.1 on page 41 Network Opens the Network screen; see section 3.3 on page 52 HDD Manager Opens the HDD Manager screen; see section 3.5.2 on page 91 USB Manager See section 2.6 on page 28 NVR7400 Series User Guide...
  • Page 28: Channel Info

    Click the button or right mouse click and select Color Setting from the Right-click menu to control the color settings. Here you can set hue, brightness, contrast, saturation, gain, white level and color mode. Figure 2-7 NVR7400 Series User Guide...
  • Page 29 OK but contrast is not. Please note the video may become hazy if the value is too low. If this value is set too high, dark sections may lack brightness while bright sections may be over- exposed. The recommended value ranges from 40 to 60. NVR7400 Series User Guide...
  • Page 30: Search And Playback

    2.5 Search and Playback Click Search in the Main Menu, or else right mouse-click and select Search from the Right-click menu. The Search screen appears. Figure 2-9 NVR7400 Series User Guide...
  • Page 31 The first 16G of each partition cannot be locked. • The system can only lock one file at one time. • The system cannot lock extra stream. • The file that is currently being written or overwritten cannot be locked. NVR7400 Series User Guide...
  • Page 32 Click the Start button. The snapshot picture is saved to the specified path. When in playback mode, click this button to Mark the record. This feature is not available in all models. See section 2.5.4 on page NVR7400 Series User Guide...
  • Page 33: Other Functions

    During the file playback process, you can switch to other channels via the dropdown list or by rolling the mouse. This function is not valid if there is no recording file or Smart Search is in progress. Note: Some NVR versions do not support all functions (playback speed, channel, time, progress, etc.). NVR7400 Series User Guide...
  • Page 34: Smart Search

    When the motion ceases, the playback fast forwards to the next instance of motion detection and repeats the process. 4. If you select another file in the file list to play, the system plays that file. 5. Click again to stop Smart Search playback. NVR7400 Series User Guide...
  • Page 35: Playback By Time

    If the Synch box is checked, playback for all channels will be for the same time period. If Synch is not checked, you can choose separate playback periods for each channel by clicking on different time periods and channels. NVR7400 Series User Guide...
  • Page 36: Mark Playback

    4. If desired, enter a value in seconds in the Play time before the mark field. Playback will actually begin the number of seconds you have entered before the marked time. 5. Double click one of the marked files to begin playback from the marked time. NVR7400 Series User Guide...
  • Page 37 When the Mark Management screen is initiated, the current playback is paused. The system resumes playback after you exit the Mark Management screen. • If the marked file you want to playback has been removed, the system begins playback from the first file in the list. NVR7400 Series User Guide...
  • Page 38: Backup

    2. Select the device you want to backup. 3. Set the channel, file start time and end time. 4. Click the Add button. The system begins a search, and then lists all matching files. The system automatically calculates the capacity needed and remaining. NVR7400 Series User Guide...
  • Page 39: Usb Device Auto Pop-Up

    2.6.2 USB Device Auto Pop-up After you insert the USB device, the system automatically detects it and pops up the following dialog box. It allows you to conveniently backup file, log, configuration or update system. Figure 2-17 NVR7400 Series User Guide...
  • Page 40: Snapshot

    Image Size: Set the snapshot picture size. • Image Quality: Set the snapshot quality. The value ranges from 1 to 6. • Snapshot Frequency: Set the timing (schedule) snapshot interval. The value ranges from 1-7 picture(s) per second. 3. Click Save. NVR7400 Series User Guide...
  • Page 41: Schedule Snapshot

    From the Live Preview screen, right click and select Record from the menu that appears Figure 2-19 3. Enable the channels that you want to take the snapshot. 4. Click Save. 5. Open the Schedule Snapshot screen (Main Menu > Setting > Storage > Schedule >Snapshot). NVR7400 Series User Guide...
  • Page 42: Activation Snapshot

    The Activation (or Trigger) function triggers a snapshot when the corresponding detection event occurs. To set up an Activation / Trigger snapshot: 1. Open the Snapshot screen from the Main Menu (Setting > Remote > Encode > Snapshot). NVR7400 Series User Guide...
  • Page 43 5. Open the Event screen from the Main Menu (Setting > Event). NVR7400 Series User Guide...
  • Page 44: Manual Record/Snapshot

    To set up a Manual Record snapshot: 1. Open the Record screen using one of these methods: • From the Main Menu select Setting > Storage > Record • Click the Rec button on the front panel NVR7400 Series User Guide...
  • Page 45 2. In the Manual row, select the channels for which you want to enable manual recording. 3. In the Snapshot field, select the channels for which you want to enable manual snapshots. 4. Open the Snapshot screen from the Main Menu under Setting > Remote > Encode > Snapshot. Figure 2-24 NVR7400 Series User Guide...
  • Page 46: Holiday Record/Snapshot

    To set up a Manual Record snapshot: 1. Open the Holiday setup screen from the Main Menu: Setting > System > General. Figure 2-25 2. Click Add New Holidays. The Add New Holidays screen opens. NVR7400 Series User Guide...
  • Page 47 5. From the Main Menu, open the Snapshot Schedule screen (Setting > Storage > Schedule > Snapshot). 6. Set the period and record type for the holiday time. Please refer to section 3.6.1.3 on page 97 for detailed setup information. NVR7400 Series User Guide...
  • Page 48 7. Click the OK button to set holiday record setup. 8. Set the Holiday Snapshot type: • Scheduled (Timing)as described in section 2.7.1 on page 31 • Activation (Trigger), as described in section 2.7.2 on page 32 NVR7400 Series User Guide...
  • Page 49: Local Menu Operations

    Main Menu from the menu that appears. Figure 3-1 The NVR7400 Series local menu tree structure is shown on the next page. For information on operations via the internet, refer to section 4 Web Service on page 129.
  • Page 50 Hybrid Standalone NVR User Guide 3 Local Menu Operations NVR7400 Series User Guide...
  • Page 51: Remote

    Right mouse-click and select Remote Device from the menu that appears • For channels with no IPC connection, click the + icon in the center of the live view screen The Remote Device screen opens. Figure 3-2 NVR7400 Series User Guide...
  • Page 52 Manual Add button Click to add the IPC manually. The port number is 37777. The default user name is admin and password is admin. Figure 3-3 NVR7400 Series User Guide...
  • Page 53 The front end device supports this function and is functioning properly. There is an alarm event at the front end device Connection status Connection succeeded Connection failed Refresh. Click to get the latest front end channel status. Figure 3-4 NVR7400 Series User Guide...
  • Page 54 1. Click the Select button and choose the upgrade file. 2. Check the box for the desired channel. Select the Device Type filter to select several devices at the same time. 3. Click the Begin button to initiate the upgrade. NVR7400 Series User Guide...
  • Page 55: Image

    Hybrid Standalone NVR User Guide 3 Local Menu Operations Figure 3-6 3.2.2 Image Open the Image screen by navigating to Setting > Remote > Image in the Main Menu. Figure 3-7 NVR7400 Series User Guide...
  • Page 56 OK but the contrast is not proper. Please note the video may become hazy if the value is too low. If this value is too high, the dark section may lack brightness while the bright section may over exposure .The recommended value ranges from 40 to 60. NVR7400 Series User Guide...
  • Page 57: Encode

    Compression The system supports H.264, MPEG4 and MJPEG. Resolution The mainstream resolution type is the IPC’s encoding configuration. Generally this is D1/720p/1080p. The system supports various resolutions that you can select from the dropdown list. NVR7400 Series User Guide...
  • Page 58 Use this checkbox to enable or disable the video/audio. 3.2.3.2 Overlay Click the Overlay tab to open the Overlay dialog, which determines whether the following items are displayed on the monitor screen. Figure 3-9 Channel. Select the target channel from the dropdown list. NVR7400 Series User Guide...
  • Page 59 2.7 Snapshot on page 30. Figure 3-10 Manual Snap. Click the dropdown menu to select the quantity of snapshots (1-5) that will be taken per Snapshot click when taken manually. Channel. Select the target channel from the dropdown list. NVR7400 Series User Guide...
  • Page 60 Copy. After you complete the setup, you can click Copy button to copy the current setup to other channel(s). Check the number to select specific channel(s) or else check the All box. The current channel number is grayed out. Click the OK to complete the setup. Figure 3-11 NVR7400 Series User Guide...
  • Page 61: Cam Name

    3 Local Menu Operations 3.2.4 Cam Name Use this screen to modify the Camera Name for each channel. The system supports a maximum of 31 characters. You can only modify the channel name of connected network cameras. Figure 3-12 NVR7400 Series User Guide...
  • Page 62: Network

    1500: This is the Ethernet information packet maximum value and the default. It is the typical setup when there is no PPPoE or VPN. It is also the default setup of some routers, switches and network adapters. • 1492: Recommended value for PPPoE. • 1468: Recommended value for DHCP. NVR7400 Series User Guide...
  • Page 63 IMPORTANT: For the following four ports (TCP, UDP, HTTP and RTSP), the system must be rebooted after you have changed and saved any setup parameter. Make sure that these four port values do not conflict with one another. NVR7400 Series User Guide...
  • Page 64: Connection

    Select from a range of 1–65535. The default value is 80. HTTPS Port Select from a range of 128–65535. The default value is 443. RTSP Port Select from a range of 128–65535. The default value is 554. NVR7400 Series User Guide...
  • Page 65: Wifi

    Click this button to open the WIFI Connection dialog, as shown below in the figure below. Click the Connection button to connect to the selected hotspot. Click OK. The WIFI Setting interface is restored, as shown below. In the WIFI Working Information field you can view the current connection status. NVR7400 Series User Guide...
  • Page 66: Pppoe

    After the device successfully connects to the WIFI, you can view the hotspot name, IP address, subnet mask, and default gateway in the WIFI Setting interface. 3.3.4 3G This feature is not supported by ADT. 3.3.5 PPPoE The PPPoE (Point to Point Protocol over Ethernet) dialog is shown in Figure 3-16.
  • Page 67: Ddns

    Note that NNDS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS and Dyndns DDNS. You can setup all DDNS clients to be valid at the same time. The Quick DDNS function works with a special DDNS server and special Professional Surveillance Software (PSS). NVR7400 Series User Guide...
  • Page 68 Do not register frequently. The interval between two registrations must be more than 60 seconds. • The system may revoke a domain name that is idle for one year. You will receive an email notification before the cancellation occurs. NVR7400 Series User Guide...
  • Page 69: Ip Filter

    Newly added IP addresses are enabled by default. Remove the √ before the item to remove it from the list. • The system supports a maximum of 64 items. • The system automatically removes space if there is any space before or after the newly added IP address. NVR7400 Series User Guide...
  • Page 70 If you enabled trusted sites, only the IP in the trusted sites list can access the device. • If you enabled blocked sites, the IP in the blocked sites cannot access the device. • The system supports add MAC address. NVR7400 Series User Guide...
  • Page 71: Email

    Enter the receiver’s email address. The system supports a maximum of 3 email boxes and automatically filters out duplicate addresses. Sender Enter the sender’s email address. Title Enter the email subject line (32 alphanumeric characters max). NVR7400 Series User Guide...
  • Page 72: Ftp

    Install the Ser-U FTP SERVER first. (Start > All Programs > Serv-U FTP Server > Serv-U Administrator). Then set the user password and FTP folder. Note that you must grant write rights to the FTP upload user. Figure 3-21 NVR7400 Series User Guide...
  • Page 73 FTP://10.10.7.7 folder. Figure 3-22 The system also supports upload multiple NVRs to one FTP server. You can create multiple folders under this FTP. Select FTP and then double-click it. The following dialog appears. Figure 3-23 NVR7400 Series User Guide...
  • Page 74: Snmp

    Enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You will need two MIB files: BASE-SNMP-MIB, NVR-SNMP-MIB) to connect to the device. You can get the device’s corresponding configuration information after a successful connection. NVR7400 Series User Guide...
  • Page 75: Multicast Setup

    CPU load. The source host can send out just one data packet. This function also depends on the relationship of the group member and the group. Figure 3-25 NVR7400 Series User Guide...
  • Page 76: Alarm Center

    You can enable real-time monitor function to view the view. 3.3.12 Alarm Center This feature is not supported by ADT at this time. 3.3.13 Register This function enables the device to automatically register to the proxy you have specified. In this way you can use the client end to access the NVR via the proxy.
  • Page 77 When the network status is Y, the registration is successful. You can view the proxy server when the device is online. IMPORTANT: The server IP address can also be the domain but you must register a domain name before you run the proxy device server. NVR7400 Series User Guide...
  • Page 78: Switch

    The Video Detect actions include set up parameters for Motion Detection, Tampering (aka Masking) and Video Loss. To set up a video event for triggering a response: 1. Select Main Menu > Setting > Event > Video Detect. The Video Detect menu appears. NVR7400 Series User Guide...
  • Page 79 396(PAL)/330(NTSC) small zones. The blue zone is the motion detection zone; the white zone is the disarmed zone. The system can only detect motion detect signal from the armed region. See section 3.4.1.1 Motion Detection on page 71.) NVR7400 Series User Guide...
  • Page 80 Schedule Record on the Manual Record screen (Main Menu > Storage > Manual Record). Delay To avoid rerecording the same event, enter the number of seconds to wait after the event has ended before a new recording can begin. This value ranges from 10s to 300s. NVR7400 Series User Guide...
  • Page 81 The Default function is only available for the current event type. For example, if you click the Default button in the Tampering dialog, only the default Tampering setup is restored to default settings. It does not affect other detection types. NVR7400 Series User Guide...
  • Page 82 The default setup is the entire screen (all blue). 5. Set the motion detection zone, using one of the following methods. The currently selected grid cell is highlighted in green. NVR7400 Series User Guide...
  • Page 83 The red flashing area shows motion has been detected in this area. Figure 3-31 9. In the Period area, select the Setup button. The Setup dialog opens for setting the motion detection period. NVR7400 Series User Guide...
  • Page 84 Select the box to the left of a time period to enable it. b. Set the start and end times for each motion detect period. c. When finished, select Save to return to the Detect screen. NVR7400 Series User Guide...
  • Page 85 To set up a Tampering event: 1. Open the Motion Detect screen by selecting Main Menu > Setting > Detect. The Detect screen opens. 2. Select the Tampering tab. NVR7400 Series User Guide...
  • Page 86 3. In the Channel area, select the channel you want to set up from the drop-down list. 4. Check the Enable checkbox to enable the Tampering feature for this channel. 5. In the Period area, select the Setup button. The Setup dialog opens for setting the motion detection period. NVR7400 Series User Guide...
  • Page 87 Select the box to the left of a time period to enable it. b. Set the start and end times for each motion detect period. c. When finished, select Save to return to the Detect screen. NVR7400 Series User Guide...
  • Page 88 This function informs you when no video signal is detected. To set up a Video Loss event: 1. Open the Motion Detect screen by selecting Main Menu > Setting > Video Detect. The Video Detect screen opens. 2. Select the Video Loss tab. NVR7400 Series User Guide...
  • Page 89 3. In the Channel area, select the channel you want to set up from the drop-down list. 4. Check the Enable checkbox to enable the Video Loss feature for this channel. 5. In the Period area, select the Setup button. The Setup dialog opens for setting the motion detection period. Figure 3-38 NVR7400 Series User Guide...
  • Page 90 Loss alarm enabled. Note: • There is no Detection Region, Sensitivity or Anti-dither setup for Video Loss. • Video Loss is only enabled during the time period set. It is disabled for Motion Detection and Tampering. NVR7400 Series User Guide...
  • Page 91: Alarm Setup

    4. Click Save when complete. Figure 3-40 Enable Check the box to activate the Alarm function. Alarm In Select the channel number from the dropdown, or else select All. Alarm Alias Enter the Alarm name. NVR7400 Series User Guide...
  • Page 92 Setup button. See Figure 3-42. For example, you can set Monday to Friday as working days and Saturday and Sunday as non-working days. Click the Save button to return to the previous screen. NVR7400 Series User Guide...
  • Page 93 This feature sets a postponement period before another external alarm can be activated. Value ranges from 10 to 300 seconds. Show Message Enable Show Message to pop up a warning dialog on the local monitor displaying which alarm has occurred. NVR7400 Series User Guide...
  • Page 94 Display screen. Snapshot Enable this function to take a snapshot image on the designated channel when an alarm occurs: 1. Go to Setting > Encode. Select Snapshot as the activation mode, and then set corresponding parameters. NVR7400 Series User Guide...
  • Page 95: Abnormality

    There is no type, anti-dither or alarm upload function. 3.4.3 Abnormality The Abnormality screen enables you to set how you would like to notified when specified events occur. Select between the HDD or Network tabs. Figure 3-44 NVR7400 Series User Guide...
  • Page 96 If this box is checked, a pop up message appears in the local screen to alert you that the event has occurred. Alarm Upload This option uploads an alarm signal to the network if your enabled event occurs. NVR7400 Series User Guide...
  • Page 97: Alarm Out

    For each alarm, click to select whether recording is scheduled, manual or stopped (not recorded). Status for each alarm is indicated at the bottom. After the setup is complete, click OK. Figure 3-46 NVR7400 Series User Guide...
  • Page 98: Storage

    Channel. Select the channel number that you want to schedule. Select All if you want to set for all channels. Pre-record. The system can pre-record the video before the event occurs into the file. The value ranges from 1 to 30 seconds depending on the bit stream. NVR7400 Series User Guide...
  • Page 99 , indicating that settings made to one date will follow to the other selected dates. Click this icon to delete a record type from one period. Click this icon to set up the time period. The following dialog appears. Figure 3-48 NVR7400 Series User Guide...
  • Page 100 The Copy function enables you to copy one channel setup to another. To use the Copy function: 1. After making your selections or the first channel, click the Copy button. The Copy dialog opens, as shown in Figure 3-49. NVR7400 Series User Guide...
  • Page 101: Hdd Manager

    X—HDD error 1. Select a HDD and select the format from the dropdown list. 2. Click the Execute button. 3. Click OK button to complete the setup. Note: The system must restart to activate the setup. NVR7400 Series User Guide...
  • Page 102 HDD groups do not include redundancy or read-only HDDs. Refer to section 3.7.1 HDD Information on page 119. Alarm Set / Release Click to set / clear the Disk Error alarm in the Abnormality dialog. Refer to Abnormality on page 85. NVR7400 Series User Guide...
  • Page 103: Manual Recording

    Schedule. The channel records for the period you have set up (Main Menu > Setting > Schedule) Manual. The channel records immediately until you select Stop. Manual recording has highest priority. Stop. All channels stop recording. NVR7400 Series User Guide...
  • Page 104: System

    Input a corresponding device number. Language The system supports various languages: Chinese (simplified), Chinese (Traditional), English, Italian, Japanese, French and Spanish. All languages listed here are optional. Video Standard There are two formats: NTSC and PAL. NVR7400 Series User Guide...
  • Page 105 If this box is checked, the system opens with the Startup Wizard when the device boots up the next time. Otherwise, the system opens with the System Login dialog. Mouse Sensitivity Set the mouse double-click speed by dragging the slider. NVR7400 Series User Guide...
  • Page 106 Port. The NVR supports TCP transmission only. The port default value is 123. • Interval. Minimum update value is 1, in minutes; maximum value is 65535 • Manual Update. Enables you to synchronize the time with the server manually. NVR7400 Series User Guide...
  • Page 107 Click the Add New Holidays button to display the dialog for selecting the dates you want to include as holidays. Refer to section 3.5.1 Schedule on page 88 for instructions on how to set recording schedules for holidays you have set up. Figure 3-55 NVR7400 Series User Guide...
  • Page 108: Display Setup

    Drag the slider to select a value for GUI’s transparency over the viewing window, ranging from 128 to 255. Time Display Select to display the time during playback. Channel Display Select to display the channel name during playback. Image Enhance Check the box to optimize the live video image quality. NVR7400 Series User Guide...
  • Page 109 The TV Adjust dialog enables you to make adjustments to the monitor screen. To set or edit TV Adjust: 1. Drag the slide bar to adjust each item to the desired setting. 2. After completing the setup, click the OK button. The system reverts to the previous menu. NVR7400 Series User Guide...
  • Page 110 Default. Click to restore the default setup. After completing the settings, click the Save button. The system returns to the previous menu. Tip: On the navigation bar, click to enable/disable Tour. Click Save to save the current setup. NVR7400 Series User Guide...
  • Page 111: Rs232

    Select 1 or 2. The default is 1. Parity Select from five choices: None, Odd, Even, Mark or Null. The default is None. After completing the setup, click the Save button. The system returns to the previous menu. NVR7400 Series User Guide...
  • Page 112: Pan/Tilt/Zoom (Ptz)

    Decoder address setup is correct • Decoder A (B) line connects with the NVR A (B) line 1. In the Main Menu, click Setting and then Pan/Tilt Control. The PTZ dialog opens. 2. Complete the setup as follows: Figure 3-60 NVR7400 Series User Guide...
  • Page 113 The system reverts to the previous menu. 3.6.4.3 PTZ Menu In one window display mode, right mouse-click and select Pan/Tilt/Zoom from the Right-click menu, or press the Fn button on either the front panel or on the remote. Figure 3-61 NVR7400 Series User Guide...
  • Page 114 2. Drag the mouse in the screen to adjust the section size. PTZ initiates automatically to adjust to the dragged area. The dragged zone supports 4X to 16X speeds. The smaller the zone you drag, the higher the speed. Figure 3-63 NVR7400 Series User Guide...
  • Page 115 Right mouse click or click the ESC button on the front panel to return to the main PTZ control interface. Icon Function Icon Function Preset Flip Tour Reset Pattern Scan Aux on / off Rotate Go to menu NVR7400 Series User Guide...
  • Page 116 3. Click within the Preset field. 4. Use the numeric keypad to input the preset number (1, 2, 3, etc.). 5. Click Set. 6. Return to step 1 and continue this pattern to set all desired Presets. NVR7400 Series User Guide...
  • Page 117 3. Input a Preset number you want to add to the tour (for example, “3”). 4. Click Add Preset to add Preset 3 to Tour 1. 5. Return to step 3 to add other presets in the order you want them to occur. NVR7400 Series User Guide...
  • Page 118 1. In the Main PTZ Control screen, click the Pattern tab. 2. Click in the Pattern field and enter a value for this Pattern number. 3. Now click the Begin button to start recording your pattern. NVR7400 Series User Guide...
  • Page 119 1. In the PTZ Control panel, select the Border tab. 2. Use the arrow keys to move the camera to the desired left-most limit. 3. Click the Left button. The Left limit is defined. 4. Repeat steps 1-3, this time setting the Right side border. NVR7400 Series User Guide...
  • Page 120 The Auxiliary function interfaces special functions in your camera, which are defined by the protocol. Click the button to open the Aux interface. The aux number corresponds to the aux on/off button of the decoder. Refer to your camera’s user manual for Aux definition. Figure 3-73 NVR7400 Series User Guide...
  • Page 121: Account

    The system allows multiple users use the same account to login. After the settings have been made, click the Save button. The system returns to the previous menu. Separate tabs enable you to modify the user or group. Figure 3-74 NVR7400 Series User Guide...
  • Page 122 3 Local Menu Operations Figure 3-75 3.6.5.1 Add/Modify Group A group is a convenient method for assigning a set of rights to multiple users. Usually a user would be assigned to a single group. To add a new group: NVR7400 Series User Guide...
  • Page 123 There are 60 different rights, such as control panel, shut down, real-time monitor, playback, record, PTZ, user account, etc. 5. Click Save. To modify a group: 1. Double click the appropriate group in the Account screen. The Modify Group dialog appears. 2. Make the desired changes. 3. Click Save. NVR7400 Series User Guide...
  • Page 124 6. Select the Group this user belongs to from the dropdown list. 7. Select the corresponding rights for the current user. 8. Click Save. It is recommended that the user rights are set lower than the administrative rights. NVR7400 Series User Guide...
  • Page 125: Auto Maintenance

    3. To Auto-Delete Old Files, select from dropdown list the type of files to be deleted and the number of days-old that these files must be before being deleted. 4. After completing the setup, click the OK button. The system reverts to the previous menu. Figure 3-78 NVR7400 Series User Guide...
  • Page 126: Import/Export

    After a successful import, the system needs to reboot to activate new setup. Format Click the Format button. A dialog box appears for you to confirm the current operation. The format process begins after you click the OK button. NVR7400 Series User Guide...
  • Page 127: Default

    Click the Default button. The Default dialog box opens. Check the box for the corresponding item that you want to restore to the default factory setup. Figure 3-80 After completing the setup, click the OK button. The system reverts to the previous menu. NVR7400 Series User Guide...
  • Page 128: Upgrade

    3 Local Menu Operations 3.6.9 Upgrade From the Main Menu select Setting > System >Upgrade. 1. Insert the USB device that contains the upgrade file. 2. Click the Upgrade button and then select the .bin file. Figure 3-81 NVR7400 Series User Guide...
  • Page 129: Information (Info)

    TIP: Click the Fn button on the front panel or left mouse-click to view HDD record time and HDD type and time. Double-click an item in the list to display the HDD Smart information screen for that HDD. NVR7400 Series User Guide...
  • Page 130: Bps

    3 Local Menu Operations Figure 3-83 3.7.2 BPS The BPS screen enables you to view current video data stream (KB/s) and occupied hard disk storage (MB/h) information. Click the BPS icon on the Info screen. Figure 3-84 NVR7400 Series User Guide...
  • Page 131: Version

    Version enables you to view hardware features, software version, built date and release SN information. To initiate an update, insert the USB device that has the update file to the device, and then click the Start button to begin. Figure 3-85 NVR7400 Series User Guide...
  • Page 132: Remote Device Information

    Hybrid Standalone NVR User Guide 3 Local Menu Operations 3.7.4 Remote Device Information From the Main Menu select Info > Event to view the channel status of the remote device, connection log and so forth. Figure 3-86 NVR7400 Series User Guide...
  • Page 133: Online Users

    The maximum disconnection setup time is 65535 seconds. The system refreshes every five seconds to detect whether a user has been added or deleted. You can click the button to disconnect or block a user, if you have proper system rights. Figure 3-87 NVR7400 Series User Guide...
  • Page 134: Network Load

    Here you can view information of all connected network adapters. The connection status is shown as offline if the connection is disconnected. Click a network adapter to view the flow statistics, such as send rate and receive rate in the top panel. Figure 3-88 NVR7400 Series User Guide...
  • Page 135: Network Test

    3. Click the Browse button to select the snapshot path. The steps here are the same as for the backup operation. You can view all connected network adapter names including Ethernet and PPPoE. (3G is not supported by ADT at this time). 4. Click the button on the right panel to begin the Sniffer.
  • Page 136: Log

    5. Select the log items you want to save, and then click the Backup button. 6. Click Start to backup. After the backup, a folder named Log_time appears in the backup path. Double click the folder to view the log file. NVR7400 Series User Guide...
  • Page 137 Hybrid Standalone NVR User Guide 3 Local Menu Operations Figure 3-90 NVR7400 Series User Guide...
  • Page 138: Shutdown

    To log out using the Power switch: Toggle the Power button on the rear panel to turn off the NVR. This method does not require that you enter the username and password to complete the operation. NVR7400 Series User Guide...
  • Page 139: Web Service

    If it is your first time to insert the PoE, the system maps it to the first idle channel. After the mapping, the channel memorizes the MAC address of the IPC ( <Channel>---<IPC mac> map). If the current channel does not connect to other device, the system can memorize the current NVR7400 Series User Guide...
  • Page 140: Login

    1. Open the browser and input the NVR IP address. For example, if your NVR IP is 192.168.1.108, then input http://192.168.1.108. Input your IP address here Figure 4-1 A pop up window appears asking you whether to install the Webrec.cab control. 2. Click Yes to install Webrec.cab. NVR7400 Series User Guide...
  • Page 141 Scroll down the list and Enable the following options: • Download signed ActiveX controls • Download unsigned ActiveX controls • Initialize and script ActiveX controls Figure 4-2 4. Click OK in both dialogs. 5. After installation, the Web Service page appears. Figure 4-3 NVR7400 Series User Guide...
  • Page 142: Preview Tab

    The system automatically closes the monitor or playback screen when you are conducting a search, in order to enhance search speed. To skip to the discussion of LAN Mode and move on to WAN Mode, go to page 135. NVR7400 Series User Guide...
  • Page 143: Lan Mode

    For sample, click on IPC 1 and select either Main Stream for full HD or Sub Stream for lower bandwidth display. The icon for each selected camera shows the S designation for Sub Stream or M for HD Main Stream. NVR7400 Series User Guide...
  • Page 144 Pan/Tilt/Zoom (PTZ) operation panel. Refer to Pan/Tilt/Zoom (PTZ) Panel on page 137. Section 9 Image. Refer to Image Set on page 139 for detailed information. Alarm Out. Refer to Alarm Out on page 140 for detailed information. NVR7400 Series User Guide...
  • Page 145: Wan Mode

    1. The Web Service opens the Main Stream of the first channel only. 2. The Open/Close button in the left pane is removed. 3. You select different channel and different monitor modes at the bottom of the screen: NVR7400 Series User Guide...
  • Page 146: Real-Time Monitor

    View the recorded file in the system folder named RecordDownload. 3–Snapshot picture. Click to take a still image of what is currently appearing on the screen. By default, all snapshot images are stored in the system client folder named PictureDownload . NVR7400 Series User Guide...
  • Page 147: Pan/Tilt/Zoom (Ptz) Panel

    Use the direction buttons to move the camera to the desired location and then click the left limit button. b. Move the camera again and then click the right limit button to set the right limit. NVR7400 Series User Guide...
  • Page 148 1. Select Pattern from the dropdown list. 2. Enter the pattern value, from 1-5. 3. Start to begin PTZ movement, such as zoom, focus, iris, direction, etc. 4. Click the Add button to set one pattern. NVR7400 Series User Guide...
  • Page 149: Image Settings

    1. Select one monitor channel video and then locate the Image area on the right side of the screen. 2. Use the slides to adjust the brightness, contrast, hue and saturation. The border of the currently selected channel border becomes green. 3. Alternatively, click the Reset button to restore system default settings. NVR7400 Series User Guide...
  • Page 150: Alarm Out

    4.4.6 Alarm Out Here you can enable or disable the alarm signal of the corresponding port. 4.4.7 Multi Preview Select a window, and then click the Multi Preview button. All available channels are displayed within the selected window. NVR7400 Series User Guide...
  • Page 151: Playback (Search)

    The system begins playback. You can select to playback in full screen. Note that for one channel, the system cannot playback and download at the same time. The recording is automatically saved at the Download folder of the installation directory. NVR7400 Series User Guide...
  • Page 152 7. Select the file(s) you want to download and then click Download button. A dialog appears, as shown below. The Download button becomes the Stop button and a process bar appears. Go to the default file saved path to view the files. NVR7400 Series User Guide...
  • Page 153 Hybrid Standalone NVR User Guide 4 Web Service Load More This interface is for searching records or pictures. You can select record channel, record type and recording time to download. Figure 4-8 NVR7400 Series User Guide...
  • Page 154 Hybrid Standalone NVR User Guide 4 Web Service Watermark The Watermark Screen is shown in Figure 4-9. Select a file and then click Verify to see whether the file has been tampered with. Figure 4-9 NVR7400 Series User Guide...
  • Page 155: Alarm

    Prompt. An alarm icon pops up on the Alarm button on the main screen when there is an alarm. 4.6.3 Alarm Sound Play Alarm Sound. The system sends out an audible alarm when an alarm occurs. Sound Path. Specify the alarm sound file. NVR7400 Series User Guide...
  • Page 156: Setup

    Click to connect to the selected device and add it to the Added Device list in the lower half of the screen. Note: The system cannot add a new device if the device you want to add has the same IP and TCP port as another device in the list. NVR7400 Series User Guide...
  • Page 157 The system default IP address is 192.168.0.0. If you do not input an IP address, the system will not add the current IP address. • You cannot add more than one device at a time using the Manual Add feature. NVR7400 Series User Guide...
  • Page 158 Sunny: The threshold of the white balance is in the sunny mode. • Night: The threshold of the white balance is in the night mode. • Customized: Set the gain of the red/blue channel. The value ranges from 0 to 100. NVR7400 Series User Guide...
  • Page 159 The recommended value ranges from 40 to 60. This setting adjusts monitor video brightness and darkness level. The default value is 50. The greater the value is, the greater the contrast between the bright and dark sections. NVR7400 Series User Guide...
  • Page 160 Compression Main Stream video supports H.264. The Sub Stream supports H.264, MJPG. Resolution The system supports various resolutions. Make your selection from the dropdown list. NVR7400 Series User Guide...
  • Page 161 Select a single channel number or All from the dropdown list. Mode Select Timing (schedule) or Event (activation).Timing snapshot is valid during the specified period you set. Activation snapshot is only valid for a motion detection alarm. NVR7400 Series User Guide...
  • Page 162 Select a single channel number from the dropdown list. Cover-Area (Privacy Mask) This setting enables a privacy mask for the specified video in the Monitor (playback) video. The system supports a maximum of 4 privacy mask zones NVR7400 Series User Guide...
  • Page 163: Camera Name

    2. Click the Save button to save the current setup. Figure 4-17 4.7.1.4 Camera Name Use this screen to set a name for the camera on each channel. Click the Save button to store your settings. Figure 4-18 NVR7400 Series User Guide...
  • Page 164 Use this interface to upgrade the network camera. 1. Click the Browse button to select upgrade file. Alternatively, you can use the filter to select several network cameras at the same time. 2. Click Upgrade to initiate. Figure 4-19 NVR7400 Series User Guide...
  • Page 165: Network

    MTU of the gateway. The MTU of the NVR must be the same as or lower than the MTU of the gateway. In this way, you can reduce packets and enhance network transmission efficiency. NVR7400 Series User Guide...
  • Page 166 If you select DHCP mode, you can view the IP Address, Subnet Mask and Gateway from the DHCP. • If you switch from the DHCP mode to the Static mode, you must reset the IP parameters. • IP Address, Subnet Mask, Gateway and DHCP are read-only when the PPPoE dial is OK. NVR7400 Series User Guide...
  • Page 167 Check the box to enable WIFI function and then click the Search SSID button. Wireless network information appears in the SSID List. Double click a name to connect to it. Click Refresh to view the latest connection status. NVR7400 Series User Guide...
  • Page 168 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-22 4.7.2.4 3G This feature is not supported by ADT. 4.7.2.5 PPPoE To set up PPPoE: 1. Check the Enable box to enable the PPPoE feature. 2. Input the PPPoE User Name and Password you get from the Internet Service Provider.
  • Page 169 Enable. Check the box to enable this function. Server Type. Select the DDNS protocol from the dropdown list and then enable DDNS function Server IP. DDNS server IP address Server Port. DDNS server port. Domain Name. Your self-defined domain name. NVR7400 Series User Guide...
  • Page 170 Do not register frequently. The interval between two registrations must be more than 60 seconds. • The system may take back the domain name that is idle for one year. You can get a notification email before the cancel operation if your email address setup is OK. NVR7400 Series User Guide...
  • Page 171 IP addresses cannot access the current NVR. Figure 4-25 4.7.2.8 Email The Email screen is used to set up email alerts, if you have set them up for sending out an alert in the event of a triggered alarm. Figure 4-26 NVR7400 Series User Guide...
  • Page 172 This function is very useful when there are too many emails activated by the Abnormality events, which may result in heavy load for the email server. Health Mail Enable Check the box to enable this function. NVR7400 Series User Guide...
  • Page 173 Make sure that the device and the proxy are the same. The read community will read all the objects the SNMP supported in the specified name. The default setup is public. NVR7400 Series User Guide...
  • Page 174 CPU load. The source host can send out just one data packet. This function also depends on the relationship of the group member and the group. Figure 4-28 NVR7400 Series User Guide...
  • Page 175: Auto Register

    IMPORTANT: The server IP address can also be the domain but you must register a domain name before you run the proxy device server. 4.7.2.12 Alarm Center This feature is not currently supported by ADT. NVR7400 Series User Guide...
  • Page 176: Create Server Certificate

    1. Click the Create Server Certificate button. 2. Enter the country, state name and other requested information. 3. Click the Create button. Note: Make sure that the IP or domain information is the same as your device IP or domain name. NVR7400 Series User Guide...
  • Page 177 The message appears that the server certificate was successfully created. Figure 4-32 Download Root Certificate 1. Use the following steps to create a Root Certificate. 2. Click the Download Root Certificate button The following dialog box appears. Figure 4-33 NVR7400 Series User Guide...
  • Page 178 3. Click the Open button. The following screen appears. Figure 4-34 4. Click the Install Certificate button to open the Certificate Import Wizard. Figure 4-35 5. Click the Next button to continue. Now select a location for the certificate. NVR7400 Series User Guide...
  • Page 179 Hybrid Standalone NVR User Guide 4 Web Service Figure 4-36 6. Click the Next button. A message appears that the certificate import process is complete. Figure 4-37 7. Click the Finish button. The following security warning dialog appears. NVR7400 Series User Guide...
  • Page 180 8. Click Yes button. A message appears confirming that the certificate download is complete. Figure 4-39 View and Set the HTTPS Port 1. Navigate to Set > Network >Connection. In the Connection screen, you can see that the HTTPS default value is 443. Figure 4-40 NVR7400 Series User Guide...
  • Page 181: Event

    • Motion Detect • Video Loss • Tampering Motion Detect Use the Motion Detect screen for setting up a Motion Detection event to trigger an alarm and initiate recording. Figure 4-41 NVR7400 Series User Guide...
  • Page 182 The delay period begins when the current motion detection event has ended. The system only stores one event during the anti-dither period. The value ranges from 5s to 600s. Sensitivity There are six levels. The sixth level has the highest sensitivity. NVR7400 Series User Guide...
  • Page 183 This value ranges from 10s to 300s. Alarm Out Check the box to enable the external alarm when the event triggers. In the boxes to the immediate right, enable which camera(s) will record when the event occurs. NVR7400 Series User Guide...
  • Page 184 When an alarm occurs, this feature presents an alternating display (much like a slideshow) of the channel(s) you set to record. Check the box to enable, and the click the buttons for the channels that you want included in the tour. The selected channels are highlighted. NVR7400 Series User Guide...
  • Page 185 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when a motion detection event occurs. Note: This feature is not supported by ADT at this time. NVR7400 Series User Guide...
  • Page 186 3. For the selected day, check the box for one of the six 24-hour time periods and set the corresponding recording range. 4. Repeat for other time periods if desired. 5. Click Save. The system reverts to the Video Loss page. NVR7400 Series User Guide...
  • Page 187 This enables you to set Pan/Tilt/Zoom movement when an alarm occurs. To set PTZ activation: 1. Check the box to enable the function. 2. Click the Setup button. The PTZ Activation dialog appears. 3. Make the desired selections for each channel. 4. Click Save. NVR7400 Series User Guide...
  • Page 188 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when a motion detection event occurs. Note: This feature is not supported by ADT at this time. NVR7400 Series User Guide...
  • Page 189 3. For the selected day, check the box for one of the six 24-hour time periods and set the corresponding recording range. 4. Repeat for other time periods if desired. 5. Click Save. The system reverts to the Tampering page. NVR7400 Series User Guide...
  • Page 190 This enables you to set PTZ movement when an alarm occurs. To set PTZ activation: 1. Check the box to enable the function. 2. Click the Setup button. The PTZ Activation dialog appears. 3. Make the desired selections for each channel. 4. Click Save. NVR7400 Series User Guide...
  • Page 191 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when a tampering event occurs. Note: This feature is not supported by ADT at this time. NVR7400 Series User Guide...
  • Page 192 Check the box to activate the Alarm function. Alarm Select the channel number from the dropdown, or else select All. Period Click the Setup button. The Setup dialog opens. Here you can set the time period when detection is enabled. NVR7400 Series User Guide...
  • Page 193 Schedule Record on the Manual Record screen. Delay To avoid rerecording the same event, enter the number of seconds to wait after the event has ended before a new recording can begin. This value ranges from 10s to 300s. NVR7400 Series User Guide...
  • Page 194 Refer to Tour Tab on page 212 for tour interval setup. However, the alarm tour has higher priority than the tour setup you set in the Display screen. Snapshot When an alarm occurs, this feature takes a still image of the channel(s) you set to record. NVR7400 Series User Guide...
  • Page 195 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when an alarm occurs. Note: This feature is not supported by ADT at this time. Network Alarm The system detects the alarm signal from the network.
  • Page 196 Value ranges from 10 to 300 seconds. PTZ Activation Select this feature to set Pan/Tilt/Zoom movement when an alarm occurs. Click the Setup button to open the PTZ Activation screen for setting up the camera. NVR7400 Series User Guide...
  • Page 197 Message. If a 3G network is connected, a message is sent when an alarm occurs. Note: This feature is not supported by ADT at this time. Note: A network alarm is an alarm signal using TCP/IP. You can use NET SDK to activate a network alarm.
  • Page 198 Check the box to activate the Alarm function. Alarm Select the channel number from the dropdown, or else select All. Period Click the Setup button. The Setup dialog opens. Here you can set the time period when detection is enabled. NVR7400 Series User Guide...
  • Page 199 Schedule Record on the Manual Record screen. Delay To avoid rerecording the same event, enter the number of seconds to wait after the event has ended before a new recording can begin. This value ranges from 10s to 300s. NVR7400 Series User Guide...
  • Page 200 Refer to Tour Tab on page 212 for tour interval setup. However, the alarm tour has higher priority than the tour setup you set in the Display screen. Snapshot When an alarm occurs, this feature takes a still image of the channel(s) you set to record. NVR7400 Series User Guide...
  • Page 201 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when an alarm occurs. Note: This feature is not supported by ADT at this time. IPC Offline Alarm The system generates an alarm when the network camera is offline and, if desired, activates a recording, PTZ, snapshot, etc.
  • Page 202 When an alarm occurs, this feature takes a still image of the channel(s) you set to record. Check the box to enable, and then click the buttons for the channels that you want included in the snapshot. The selected channels are highlighted. NVR7400 Series User Guide...
  • Page 203 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when the anomalous event occurs. Note: This feature is not supported by ADT at this time. 3. Click Save.
  • Page 204 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when the anomalous event occurs. Note: This feature is not supported by ADT at this time. 4. Click Save.
  • Page 205 Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when the anomalous event occurs. Note: This feature is not supported by ADT at this time. 3. Click Save.
  • Page 206: Storage

    Buzzer. If enabled, a buzzer sounds when an alarm occurs. Message. If a 3G network is connected, a message is sent when the anomalous event occurs. Note: This feature is not supported by ADT at this time. 3. Click Save.
  • Page 207 1. After making all your selections in the Schedule page, click the Copy button. The channel selection dialog appears. The current channel name is grayed out. 2. Select the channel(s) to which you want to paste the same setup as for the current channel. 3. Click the OK button. NVR7400 Series User Guide...
  • Page 208 4. Set the corresponding recording range for each time period. 5. Repeat for other time periods if desired. 6. Check the box for the desired type of recordings: Regular, Motion Detect, Alarm or Motion Detect with Alarm. NVR7400 Series User Guide...
  • Page 209 Use the HDD Setting page to assign a hard drive to an HDD Group. See Figure 4-74. To set the HDD to a Group: 1. In the row of the hard drive in question, use the drop-down to select the corresponding HDD Group number. 2. Click Save. Figure 4-74 NVR7400 Series User Guide...
  • Page 210 When interval value is 0, system uploads all corresponding files. 5. Set the Image Upload Interval. 6. Use the drop-down menu to select the upload file Channel. 7. Use the drop-down menu to select the day. NVR7400 Series User Guide...
  • Page 211: Record Control

    2. Click the radio button for the desired recording mode for each channel. Settings in the All column are applied to all channels. 3. Click Save. 4.7.4.4 Storage Main Stream The main stream interface is used to set the corresponding HDD group as main stream. NVR7400 Series User Guide...
  • Page 212 Sub Stream The sub stream interface is used to set the corresponding HDD group as sub stream. Figure 4-78 Snapshot Storage The Snapshot interface is used set the corresponding HDD group to save snapshot pictures. Figure 4-79 NVR7400 Series User Guide...
  • Page 213: Setting

    Overwrite. If the current HDD becomes full and there is no secondary HDD or else it too has insufficient space, the system overwrites the previous files. Pack Duration Specify the recording duration. The value ranges from 1 to 120 minutes; the default value is 60 minutes. NVR7400 Series User Guide...
  • Page 214 This field displays the current system time. Click the Sync PC button to set your PC’s current time as the system time. Check the box to enable Daylight Savings Time (DST). DST Type Set the DST beginning time and ending times, in either a date or week format. NVR7400 Series User Guide...
  • Page 215: Holiday Setup

    Use this tab to set holiday dates. Figure 4-82 1. Check the Holiday Enable box. 2. In the calendar, select the date(s) and year you want to set as a holiday for the current channel. 3. Click Save. NVR7400 Series User Guide...
  • Page 216 4. Use the drop-down list to select a Group for this user. 5. In the Authority field, check the boxes for the rights you want assigned for this user. 6. Enter the MAC and an optional Memo for the User. 7. Click Save. NVR7400 Series User Guide...
  • Page 217 1. Click the Delete button . The Delete User dialog opens. 2. Click Save to confirm. Figure 4-85 The default user cannot be deleted. To modify a user: 1. Click the Modify button . The Modify User dialog opens. NVR7400 Series User Guide...
  • Page 218 4. Check the Modify Password box. Additional fields appear. 5. Enter the Old Password, Enter the New Password, and then Confirm the new Password. 6. Click Save. Figure 4-86 Group Click the Group tab to add/remove groups or to modify a group account. NVR7400 Series User Guide...
  • Page 219 2. Enter the Group Name, which can be a maximum of 6 characters, including alpha-numeric characters and the underline. 3. Add an optional memo. 4. Check the boxes to select the corresponding rights you want to assign to the group. 5. Click Save. Figure 4-88 To delete a group: NVR7400 Series User Guide...
  • Page 220 The Display screen includes tabs for setting the GUI and Tour. Display Tab The GUI tab contains settings that affect the appearance of the graphical user interface. Click the Save button when you have completed setting your parameters. NVR7400 Series User Guide...
  • Page 221 Enter a time in minutes after which the system will automatically logout. Startup Wizard Check the box to enable the wizard to appear at system startup. Navigation Bar Check the box to enable the navigation bar to be displayed on the video monitor. NVR7400 Series User Guide...
  • Page 222 • View 1 displays 1 window • View 4 displays 4 windows • View 8 displays 8 windows NVR7400 Series User Guide...
  • Page 223 Group 2 will simultaneously display channels 5 through 8 2. Click the + button to add a new channel group. The Add Channel Group dialog opens. 3. Click numbers 1, 3, 5, and 7 to select only odd channels for this new group. NVR7400 Series User Guide...
  • Page 224 6. To relocate group 4 to be displayed before group 3 in the tour, select group 4 and then click the up arrow button. Group 4 is now number 3. 7. To remove groups 1 and 2 from the tour without deleting them, click the respective boxes to clear the checkmarks. NVR7400 Series User Guide...
  • Page 225 3 and 4 are now groups 1 and 2, respectively. Motion Tour /Alarm Tour Type Set the type of tour split to show for the Motion Detect Tour/Alarm Tour: • View 1 displays the 1 window mode. • View 8 displays the 8 window mode NVR7400 Series User Guide...
  • Page 226 Here you can select the Channel, Network, Event, Storage, or System sections individually; or else you can check the All box to select all items. Check the boxes for the sections you wish to reset and then click the Default button. Figure 4-93 NVR7400 Series User Guide...
  • Page 227 To setup Auto Delete: 1. Use the drop-down menu to select the frequency of the auto delete. 2. Click Save. 3. If you want to use the auto delete old files function, you must set the file period. NVR7400 Series User Guide...
  • Page 228 During the upgrade process, do not unplug the power cable, network cable, or shutdown the device. Figure 4-96 Note: Improper upgrade program may result in device malfunction. Please make sure the operation is operated under the supervision of the professional engineer. NVR7400 Series User Guide...
  • Page 229 Select 1 or 2. The default is 1. Parity Select from five choices: None, Odd, Even, Mark or Null. The default is None. After completing the setup, click the Save button. The system returns to the previous menu. NVR7400 Series User Guide...
  • Page 230 The PTZ interface is shown in the following images. Figure 4-98 is the Local interface; Figure 4-99 is the Remote interface. Figure 4-98 Figure 4-99 Refer to the following table for detailed information. Channel Select channel to which the PTZ camera is connected. NVR7400 Series User Guide...
  • Page 231 Default setup is 8. Set this according to the PTZ camera dial switch setup. Stop bit Default setup is 1. Set this according to the PTZ camera dial switch setup. Parity Default setup is none. Set this according to the dial switch setup on the PTZ camera. NVR7400 Series User Guide...
  • Page 232: Information (Info)

    You can select one item to view detailed information. Clear You can click this button to delete all displayed log files. Note that the system does not support clear by type. Backup Click this button to backup log files to the local PC. NVR7400 Series User Guide...
  • Page 233: Online User

    Hybrid Standalone NVR User Guide 4 Web Service Figure 4-101 4.8.1.3 Online User The Online User page is shown below in Figure 4-102. Figure 4-102 NVR7400 Series User Guide...
  • Page 234: Logout

    Figure 4-103 4.10 Un-install Web Service You can use Web un-install tool “uninstall Web.bat” to un-install Web control. Note: Be sure to close all Web pages before you un-install. NVR7400 Series User Guide...
  • Page 235: Appendix A Troubleshooting, Daily Maintenance And Glossary

    • Brightness is set to 0. Restore factory default setup. • There is no video input signal or it is too weak • Check the Privacy Mask setup or your screen saver • NVR hardware malfunction NVR7400 Series User Guide...
  • Page 236 Usually this mode is not recommended. • There is a Privacy Mask or channel protection setup • Current user does not have proper rights to monitor • NVR local video output quality is of poor quality NVR7400 Series User Guide...
  • Page 237 15. Alarm function does not work Possible reasons: • Alarm setup is not correct • Alarm cable connection is not correct • Alarm input signal is not correct • There are two loops connected to one alarm device NVR7400 Series User Guide...
  • Page 238 100M or higher. • Your PC resources are insufficient. For 16 channel remote monitor operation, the PC must have the following environment: Quad Core, 2G or higher memory, independent displayer, with display card memory of 256M or higher. NVR7400 Series User Guide...
  • Page 239 27. My admin account has been changed and I cannot log in Possible solution: • Use telnet and then input the following command: cd /mnt/mtd/Config/ rm -rf group rm -rf password • Reboot the device to restore the default password NVR7400 Series User Guide...
  • Page 240 Use the PING command to check whether you can connect to the gateway. Use telnet to access and then use the command “ifconfig –a” to check the device IP address. If you see that the subnet mask and the gateway has changed after the reboot, upgrade the applications and set again. NVR7400 Series User Guide...
  • Page 241 • Locate the device away from the direct sunlight or other heating sources. • Ensure that the device is properly ventilated. NVR7400 Series User Guide...
  • Page 242 3G network such as WCDMA, EVDO, TD-SCDMA. On-off value. This is the non-consecutive signal sampling and output. It includes remote sampling and remote output. It has two statuses: 1/0. NVR7400 Series User Guide...
  • Page 243: Appendix B Specifications

    Time/Date, Alarm, MD and Exact Search (accurate to second), Smart Search Playback Functions Play, Pause, Stop, Rewind, Fast Play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom Backup Mode USB Device/Network/ Internal SATA burner/ External eSATA NVR7400 Series User Guide...
  • Page 244 PoE Ports 16 ports (IEEE802.3at) Network Functions HTTP, TCP/IP, IPv4/IPv6, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search (supports ADT IP cameras, DVR, NVS, etc.) Max User Access 128 users Smart Phone iPhone, iPad, Android...
  • Page 245: Appendix C Compatible Network Cameras

    H264 ONVIF - D100 H264 ONVIF - GE-100-CB H264 ONVIF - FB-100A v1.0.3.9 H264 ONVIF FD-100A v1.0.3.3 H264 ONVIF Cannon VB-M400 H264 Private - MPix2.0DIR XNETM1120111229 H264 ONVIF VIPBL1.3MIRVF XNETM2100111229 H264 ONVIF IGC-2050F XNETM2100111229 H264 ONVIF NVR7400 Series User Guide...
  • Page 246 Private, ONVIF WV-SP105H H264 Private, ONVIF - WV-SP302H 1.41 H264, MPEG4 Private, ONVIF WV-SP306H H264, MPEG4 Private, ONVIF WV-SP508H H264, MPEG4 Private, ONVIF - WV-SP509H H264, MPEG4 Private, ONVIF - WV-SF332H 1.41 H264, MPEG4 Private, ONVIF NVR7400 Series User Guide...
  • Page 247 Private, ONVIF SNB-6004 V1.0.0 H264 ONVIF Sony SNC-DH110 1.50.00 H264 Private, ONVIF SNC-CH120 1.50.00 H264 Private, ONVIF SNC-CH135 1.73.01 H264 Private, ONVIF SNC-CH140 1.50.00 H264 Private, ONVIF SNC-CH210 1.73.00 H264 Private, ONVIF SNC-DH210 1.73.00 H264 Private, ONVIF NVR7400 Series User Guide...
  • Page 248 1.78.00 H264 ONVIF SNC-VM631 1.4.0 H264 ONVIF WV-SP306 1.61.00 H264, MPEG4 WV-SP306 1.61.00 H264 ONVIF SNC-VB600 1.5.0 H264 Private SNC-VM600 1.5.0 H264 Private SNC-VB630 1.5.0 H264 Private SNC-VM630 1.5.0 H264 Private SANYO VCC-HDN4000PC H264 ONVIF - NVR7400 Series User Guide...
  • Page 249: Appendix D Compatible Backup Devices

    Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom SanDisk Cruzer Micro SanDisk Cruzer Micro SanDisk Ti Cool SanDisk Hongjiao Sandisk 16GB Teclast Ti Cool 128M Teclast Ti Cool 256M Teclast Ti Cool 512M Teclast Ti Cool NVR7400 Series User Guide...
  • Page 250 Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Compatible USB DVD Burners Note : Upgrade the NVR firmware to the latest version to ensure the accuracy of the table below. Manufacturer Model Benq TW200D Samsung SE-S084 NVR7400 Series User Guide...
  • Page 251: Appendix E Compatible Sata Hdds

    Seagate Seagate SV35.5 ST3500411SV 500G SATA Seagate Seagate SV35.5 ST31000525SV SATA Seagate Seagate SV35.5 ST31000526SV SATA Seagate Seagate SV35.5 ST1000VX000 SATA Seagate Seagate SV35.5 ST2000VX003 SATA Seagate Seagate SV35.5 ST2000VX002 SATA Seagate Seagate SV35.5 ST2000VX000 SATA NVR7400 Series User Guide...
  • Page 252 ST500NM0031 500G SATA Constellation ES Seagate Seagate ST2000NM0051 SATA Constellation ES Seagate Seagate ST1000NM0051 SATA Constellation ES Seagate Seagate ST500NM0051 500G SATA Constellation ES Seagate Seagate ST33000650NS SATA Constellation ES.2 Seagate Seagate ST32000645NS SATA Constellation ES.2 NVR7400 Series User Guide...
  • Page 253 SATA Western Digital WDAV-GP—EVDS WD10EVDS-63N5B1 SATA Western Digital WDAV-GP—EVDS WD15EVDS-63V9B0 1.5T SATA Western Digital WDAV-GP—EVDS WD20EVDS-63T3B0 SATA Western Digital WDAV-GP—AVDS WD5000AVDS-63U7B0 500G SATA Western Digital WD AV-GP WD30EURS SATA Western Digital WD AV-GP WD25EURS 2.5T SATA NVR7400 Series User Guide...
  • Page 254 WD AV-GP WD10EUCX SATA Compatible 2.5-inch HDDs Manufacturer Series Model Capacity Seagate ST1000LM024 SATA Seagate ST500LM012 500G SATA Seagate ST9320325AS 320G SATA Westem Digital WD10JPVX SATA Westem Digital WD5000LPVX 500G SATA Westem Digital WD3200LPVX 320G SATA NVR7400 Series User Guide...
  • Page 255: Appendix F Compatible Cd/Dvd Devices

    Appendix F Compatible CD/DVD Devices Appendix F Compatible CD/DVD Devices Manufacturer Model Port Type Type BenQ 5232WI DVD-RW Panasonic SW-9588-C SATA DVD-RW Samsung TS-H653A SATA DVD-RW Sony AW-G170S SATA DVD-RW Sony DRX-S50U DVD-RW Sony DRX-S70U DVD-RW Sony DRX-S50U DVD-RW NVR7400 Series User Guide...
  • Page 256: Appendix G Compatible Displays

    P2350 23-inch Samsung (LCD) P2250 22-inch Samsung (LCD) P2370G 23-inch Samsung (LCD) 2043 20-inch Samsung (LCD) 2243EW 22-inch Samsung (LCD) SMT-1922P 19-inch Samsung (LCD) T190 19-inch Samsung (LCD) T240 24-inch SANGSUNG (LCD) 225BW 22-inch (wide screen) NVR7400 Series User Guide...
  • Page 257: Index

    Maintenance, Manual Recording, Video Loss, Mark Playback, Disk Error, Display Menu, List, Motion Detection, Setup, Smart Search, Mouse Click Speed, Multi Preview, Email Setup, Multicast, Encode Setup, Event, Export, Navigation Bar, Network Camera List, Network Disconnection, NVR7400 Series User Guide...
  • Page 258 SNMP Setup, Speed, Specifications, Tour, Startup, Storage Settings, Synchronization, System, Real-time Monitor, Account, Rear Panel, Auto Maintain, Recording Default, Manual, Display, Schedule, General, Redundancy, Import & Export, Remote Device, PTZ, Right-click Menu, RS232, Root Certificate, Upgrade, RS232, NVR7400 Series User Guide...
  • Page 259 Uninstall Login, Web Service, Logout, Upgrade Multi Preview, Camera, Network, System, Playback, Real time Monitor, Search, Setup, Version, Storage Settings, Video Color, System Settings, Video Detect, Uninstall, Video Loss, Version, Video Overlay, Video Detect, Virtual Keyboard, NVR7400 Series User Guide...

Table of Contents
