ADT
®
NVR32xx-P Series
Network Video Recorder
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NVR32xx-P Series and is the answer not in the manual?

Questions and answers

Related Manuals for ADT NVR32xx-P Series

Summary of Contents for ADT NVR32xx-P Series

  • Page 1 ® NVR32xx-P Series Network Video Recorder Quick Start Guide...

  • Page 2: Table Of Contents

    About PoE Address Setup, Operation and Allocation ..............25 Login ................................26 Preview Tab (Live Viewing) .........................28 3.3.1 LAN Mode ............................29 3.3.2 WAN Mode ............................32 3.3.3 Real-time Monitor ..........................33 Schedule .................................34 Recording ................................37 Playback (Search) ............................38 Logout ................................40 NVR32xx-P Series Quick Start Guide...

  • Page 3: Nvr Overview

    Also serves as the Backspace function to delete the previous character (to the left of the cursor) when pressed for 1.5 seconds. In HDD management screen: switches between HDD recordings and other information (Menu prompt). NVR32xx-P Series Quick Start Guide...
  • Page 4 Network indicator. Glows to alert you of a loss of the network connection. IR receiver. Receives the signal from the remote control. USB Port. Connects a USB storage device or USB mouse. NVR32xx-P Series Quick Start Guide...

  • Page 5: Rear Panel

    +48 VDC input. Switch power port Input 48VDC/1.04A (32-P) or 48VDC/2.5A (32-8P) * ADT does not support Audio functions at this time Note: When connecting the Ethernet port, use the crossover cable to connect the PC and use the straight cable to connect to the switcher or router.

  • Page 6: Network Connection

    1 NVR Overview 1.3 Network Connection Figure 1-3 NVR32xx-P Series Quick Start Guide...

  • Page 7: Gui Operation

    • Click Cancel if you would like to skip the startup routine and go directly to the Login screen. Figure 2-1 2. Enter your User Name and Password in the System Login dialog. Figure 2-2 NVR32xx-P Series Quick Start Guide...
  • Page 8 Click OK on the System Login dialog to enter. Note: For security reasons, modify your password after your first login. • Three (3) sequential login failures will result in a system alarm • Five (5) sequential failures will result in account lock NVR32xx-P Series Quick Start Guide...

  • Page 9: Remote Device

    Right mouse-click and select Remote Device from the context menu • For channels with no IPC connection, click the + icon in the center of the live view screen The Remote Device screen opens, as in Figure 2-4. Figure 2-4 NVR32xx-P Series Quick Start Guide...

  • Page 10: Ip Search

    Delete button If you select a device on the Added Device list, and then click the Delete button, the device is disconnected and then its name is removed from the list. NVR32xx-P Series Quick Start Guide...

  • Page 11: Ipc Config

    Connect the IPC to the PoE port of the device rear panel. The system automatically connects to the network camera. Double click the on the IPC Config column to open the IPC setup interface, or else right mouse- click and select IPC Config from the context menu. Figure 2-7 NVR32xx-P Series Quick Start Guide...
  • Page 12 The default value is 50. The larger the number, the brighter the video. You can use this function when the video is too dark or too bright as a whole. Note that the video may become hazy if the value is too high. The recommended value ranges from 40 to 60. NVR32xx-P Series Quick Start Guide...
  • Page 13 Delete. Select one device in the Added Device list and then click Delete to remove it. Manual Add. Click this to add the IPC manually. The port number is 37777. The default user name is admin and password is admin. NVR32xx-P Series Quick Start Guide...

  • Page 14: Live Viewing (Preview)

    . To zoom: left mouse-click and drag to select a zone, and then release to zoom in on the selected zone. After you have zoomed in the zone, you can left mouse-click and drag to browse. NVR32xx-P Series Quick Start Guide...
  • Page 15 During the playback, you cannot switch the displayed channel or change current window- display mode. Note: The tour function has higher priority than the instant playback. You cannot control the playback until the tour function has ended. NVR32xx-P Series Quick Start Guide...

  • Page 16: Manual Recording

    Schedule. The channel records for the period you have set up (Main Menu > Setting > Schedule) Manual. The channel records immediately until you select Stop. Manual recording has highest priority. Stop. All channels stop recording. NVR32xx-P Series Quick Start Guide...

  • Page 17: Enable/Disable Recording

    ○ (filled) means the channel is in recording mode ● (empty) means that it is not in recording mode Use the mouse or arrow keys to highlight the desired channel number. See Figure 2-11. Figure 2-11 NVR32xx-P Series Quick Start Guide...

  • Page 18: Schedule

    Note: This function is not available if there is only one HDD. Snapshot. When selected, a snapshot photo is created at the scheduled interval. Holiday. Click this box to enable a unique recording schedule for the days you established as holidays in the General menu. NVR32xx-P Series Quick Start Guide...
  • Page 19 Note: Holiday settings have priority over non-holiday schedules. If the selected day is a holiday, then the system records according to the Holiday setting. If it is not a holiday, the system records according to the regular Schedule. NVR32xx-P Series Quick Start Guide...

  • Page 20: Search And Playback

    In any play mode, click the date you want to see files for. The corresponding record file trace appears in the time bar. If a date is highlighted in blue date, a picture or file exists for this date. NVR32xx-P Series Quick Start Guide...
  • Page 21 Stop Reverse Play In normal play mode, left-click this button and the file begins reverse  play. Click again to pause the current playback. • In reverse play mode, Click ►/ to restore normal play. NVR32xx-P Series Quick Start Guide...
  • Page 22 Use this feature to set the range of the time bar for playback. The options are: 24H, 12H, 1H and 30M. The smaller the unit, the larger the zoom. The time bar begins at 0 hour when setting the configuration, and then zooms in on the current period during playback. NVR32xx-P Series Quick Start Guide...

  • Page 23: Other Functions

    1. During multiple-channel playback mode, double-click a channel, and then click the button located in the Playback control panel (item #8 in Figure 2-13 on page 18). A grid appears on the screen. Note: The system supports 396(22*18 PAL) and 330(22*15 NTSC) zones. NVR32xx-P Series Quick Start Guide...
  • Page 24 IMPORTANT: • The system does not support motion detect zone setup during the full-screen mode. • During multiple-channel playback, the system stops playback of the rest of the channels if you implement one-channel smart search. NVR32xx-P Series Quick Start Guide...

  • Page 25: Playback By Time

    If the Synch box is checked, playback for all channels will be for the same time period. If Synch is not checked, you can choose separate playback periods for each channel by clicking on different time periods and channels. Figure 2-16 NVR32xx-P Series Quick Start Guide...

  • Page 26: Logout / Shutdown

    7. Toggle the Power button on the rear panel to turn off the NVR. This method does not require that you enter the username and password to complete the operation. NVR32xx-P Series Quick Start Guide...

  • Page 27: Web Service

    If it is your first time to insert the PoE, the system maps it to the first idle channel. After the mapping, the channel memorizes the MAC address of the IPC ( <Channel>---<IPC mac> map). If the current channel does not connect to other device, the system can memorize the current NVR32xx-P Series Quick Start Guide...

  • Page 28: Login

    1. Open the browser and input the NVR IP address. For example, if your NVR IP is 192.168.1.108, then input http://192.168.1.108 Input your IP address here Figure 3-1 A pop up window appears asking you whether to install the webrec.cab control. 2. Click Yes to install webrec.cab. NVR32xx-P Series Quick Start Guide...
  • Page 29 Scroll down the list and Enable the following options: • Download signed ActiveX controls • Download unsigned ActiveX controls • Initialize and script ActiveX controls Figure 3-2 4. Click OK in both dialogs. 5. After installation, the Web Service page appears. Figure 3-3 NVR32xx-P Series Quick Start Guide...

  • Page 30: Preview Tab (Live Viewing)

    The system automatically closes the monitor or playback screen when you are conducting a search, in order to enhance search speed. To skip to the discussion of LAN Mode and move on to WAN Mode, go to page 32. NVR32xx-P Series Quick Start Guide...

  • Page 31: Lan Mode

    In the sample screens that follow, CAM1, CAM2, CAM3 and CAM 6 have all been selected to output sub stream. The icon for each selected camera becomes yellow and the S designation (for Sub Stream) appears to the right of each. M would appear for HD Main Stream. NVR32xx-P Series Quick Start Guide...
  • Page 32 Video Display Parameters. From the left to the right are buttons that control screen display parameters, as described below. –Video quality –4-window screen —9-window screen –Video fluency –6-window screen –13-window screen –Full screen mode –8-window screen –16-window screen –1-window screen Section 7 Pan/Tilt/Zoom (PTZ) operation panel. NVR32xx-P Series Quick Start Guide...
  • Page 33 3. Alternatively, click the Reset button to restore system default settings. brightness contrast saturation Figure 3-5 Alarm Out. Enable or disable the alarm signal of the corresponding port. Figure 3-6 NVR32xx-P Series Quick Start Guide...

  • Page 34: Wan Mode

    M stands for main stream; S stands for sub stream (extra stream). 5. When you login via WAN mode, the system does not support alarm activation to open the video function in the Alarm setup interface. NVR32xx-P Series Quick Start Guide...

  • Page 35: Real-Time Monitor

    PictureDownload . 4–Audio. Turn audio on or off. Note: ADT does not support Audio functions at this time. 5–Close video. Turn off the video. NVR32xx-P Series Quick Start Guide...

  • Page 36: Schedule

     Redundancy. The system supports a redundancy backup function, which enables you to backup a recorded file in two disks. Highlight Redundancy to activate this function. Snapshot. Check this box to enable the snapshot function. Holiday. Click this box to enable holiday dates. NVR32xx-P Series Quick Start Guide...
  • Page 37 1. Select the channel number you want to set up in the Channel dropdown menu. 2. Make selections from options above. 3. Click the Setup button for the desired day. Six 24-hour time periods appear in the resulting dialog. NVR32xx-P Series Quick Start Guide...
  • Page 38 7. If you would like for these same settings to be used for other days of the week, check the box(es) corresponding to those day(s). 8. Click Save. The system reverts to the Schedule page. 9. Click Save. NVR32xx-P Series Quick Start Guide...

  • Page 39: Recording

    1. Locate the channel you wish to control in the Record Mode row. The settings below the channel number correspond to that channel. 2. Click the radio button for the desired recording mode for each channel. Settings in the All column are applied to all channels. 3. Click Save. NVR32xx-P Series Quick Start Guide...

  • Page 40: Playback (Search)

    The system begins playback. You can select to playback in full screen. Note that for one channel, the system cannot playback and download at the same time. The recording is automatically saved at the Download folder of the installation directory. NVR32xx-P Series Quick Start Guide...
  • Page 41 7. Select the file(s) you want to download and then click Download button. A dialog as shown in Figure 3-14 appears. The Download button becomes the Stop button and a process bar appears. Go to the default file saved path to view the files. Figure 3-14 NVR32xx-P Series Quick Start Guide...

  • Page 42: Logout

    3 Web Service 3.7 Logout Click the Logout button to log out of the Web Service. The system reverts to the Login dialog. You must input your username and password to log in again. Figure 3-15 NVR32xx-P Series Quick Start Guide...
