LED and Beep Control

External Bi-color LED
Control
12
Switch 3 (S3) on the ACM controls the reader LED display and whether the reader
beeps on a card read.
TABLE 6. S3 LED and Beep Control
S3-1
LED Control
The LED control is for read heads connected to the Wiegand (WG) ports. The LEDs on
read heads that are connected to the STARn ports are controlled by the RM-4 or RM-4E.
S3-1 and S3-2 provide the same LED control that is available on the RM-4 and RM-4E.
Table 7 shows the possible settings of S3-1 and S3-2.
S3-1
OFF
OFF
ON
ON
If both switches are Off, the Function is External Bi-color, which refers to the two LEDs
(Red and Green) in the reader. The function is essentially Tri-color because in some
cases the LEDs will appear as Yellow.
S3-2
LED control
TABLE 7. S3 LED Control
S3-2
OFF
ON
OFF
ON
S3-3
Beep control
Function
External Bi-Color
3-wire (R,G,Y)
1 Wire (A,B,C)
1 Wire (A,B,C)
