Dialup Connection

Serial Connection

1. Connect P6 to the iSTAR modem as shown in Table 2.
TABLE 2. DB25-to-P6 Pin Connections
Modem
DB25 Pin Modem DB25 Signal
2
4
5
3
7
2. Connect the host modem to a COM Port.
3. Set the COM Port to 57,600 baud, 8, None, 1, Hardware Flow Control.
4. Configure the RAS login information using ICU.exe
5. Configure the C•CURE 800 Server to accept RAS connections.
6. Configure the controller and cluster using ICU and the C•CURE 800.
1. Connect P6 to the Server COM Port as shown in Table 3.
TABLE 3. DB9-to-P6 Pin Connections
COM Port
DB9 Pin COM Port DB9 Signal
2
8
7 and 1 RTS and CD
3
5
2. Set the COM Port to 57,600 baud, 8, None, 1, Hardware Flow Control.
3. Configure the RAS login information using ICU.exe
4. Configure the C•CURE 800 Server to accept RAS connections.
5. Configure the controller and cluster using ICU and the C•CURE 800.
iSTAR
P6 Pin
Tx 1
RTS 2
CTS 3
Rx 4
GND 5
iSTAR
P6 Pin
Rx 1
CTS 2
3
Tx 4
GND 5
GCM General Control Module
iSTAR P6 Signal
Tx
RTS
CTS
Rx
GND
iSTAR P6 Signal
Tx
RTS
CTS
Rx
GND
