- Page 1 Alexis Large Sideboard White High Gloss PVC H72xW155xD42cm...
-
Page 2: Dear Customer
DEAR CUSTOMER Thank you for purchasing your new piece of furniture from Dunelm. We put a lot of effort in the design and construction of our products to ensure they set the standard for quality, durability and ease of assembly. - Page 3 Parts & Fittings for the Alexis Large Sideboard (30477969) Panel- exploded view...
- Page 4 Panels-plan view Top x1 Left side x1 420x1550mm 419x518mm Left Middle divider x1 Right Middle divider x1 Right side x1 388x518mm 388x518mm 419x518mm Base x1 Middle Back x1 L/R Back x2 420x1550mm 504x526mm 493x526mm Metal Bar x2 Metal Leg x2 Adjustable Leg x2 25x1300mm 160x383mm...
-
Page 5: Tools Required
Fittings 12mm 35mm Ø8x30mm Ø6x50mm Ø6x38mm Wooden Dowel x8 screw x8 Handle screw x8 Cam lock x8 Cam bolt x8 Ø4x16mm Ø5x16mm Ø6x12mm screw x4 Shelf support x12 Back wedge x9 screw x3 screw x4 Ø4mm Ø4.5x15mm Ø3x14mm Allen Key x1 screw x6 screw x36 Magnetic catch x3... - Page 6 Ready? Follow this step-by-step guide Rear edge Note:Insert cam bolt as shown Rear edge...
- Page 7 Rear edge 10mm Ensure the cam is pressed fully into the hole and arrow pointing towards the short edges Cam lock in open Cam lock in closed position position Rear edge...
- Page 8 Front edge Front edge...
- Page 10 Ensure all screws are well insert before fasten Front edge Front edge Two people required to turn unit over...
- Page 11 Front edge Ensure the finished surface is facing the outside...
- Page 12 Adjust the hinge to ensure the grain of wave panel on the same level Adjust Hinge Position...
- Page 13 Remove the plastic film on all panels after assembly. Front edge Rear edge...
- Page 14 Nearly there! Rear edge Important note It is essential that this product is fixed to a wall using the plastic zip ties supplied. Wall fixing is not supplied.
- Page 15 Wall Fixings...
- Page 16 For use with plaster board tting in this case. For light partitions or hollow loads, a General Purpose Plug wooden doors. can be used. dunelm.com...
-
Page 17: Care And Maintenance
From time to time check that there are no loose screws on this unit. This product should not be discarded with household waste. Take to your local authority waste disposal centre. Finally, we hope you enjoy your furniture for many years to come and thanks again for your purchase. dunelm.com...
