14.0 SCR100 TROUBLESHOOTING

NO DISPLAY INDICATION AFTER CONNECTION OF AC POWER

1.Symptom =>
Possible Cause
Charger connected to low AC voltage.
1.1
Charger connected to high AC voltage.
1.2
2. Symptom =>

DISPLAY INDICATES FAC OR F3 AFTER CONNECTION OF AC POWER

Possible Cause
Charger connected to low / high AC voltage.
2.1
AC power partially missing.
2.2
Failure of one or more of charger's power fuses.
2.3
Phase rotation. (Only if F3 is showing)
2.4
3. Symptom =>

DISPLAY INDICATES FCA BEFORE CONNECTION OF BATTERY

Possible Cause
3.1 Previous charge cycle was interrupted by DC
cable disconnection.
Shorted or leaky SCRs/diodes.
3.2
Instr. 4770-65-95005-00
Verify AC voltage per nameplate of the charger
and electrician's tag.
Verify connection of primary windings of power
transformer and AC fuses of charger per
connected AC voltage and electrician's tag.
Verify AC voltage per nameplate of the charger
and electrician's tag.
Verify connection of primary windings of power
transformer and AC fuses of charger per
connected AC voltage and electrician's tag.
Check AC fuses of charger and replace if needed.
Check fuse F2 of Control Card. If this fuse is blown,
replace Control Card.
Verify AC voltage per nameplate of the charger
and electrician's tag.
Verify connection of primary windings of power
transformer and AC fuses of charger per
connected AC voltage and electrician's tag.
Verify AC voltage at all primary windings of
power transformer and AC fuses of charger per
nameplate of the charger and electrician's tag.
Consult GNB technician.
Replace fault fuse. Verify input AC voltage and
output High Rate current.
Verify phase sequence of input AC source.
Ensure that it follows the sequence indicated at
the charger's input.
Do not interrupt charge by DC cable
disconnection. Use pushbutton Stop for this
purpose.
Connect next battery – charger will start
automatically.
Disconnect battery and AC power.
Consult GNB technician.
Page 17
Action
Action
Action
