- Page 1 User Manual DCS-3021 Conference System...
-
Page 2: Table Of Contents
Contents Chapter 1 Introduction ......... . Chapter 2 Congress Server . - Page 3 DCS-3021 Congress System Chapter 8 FAQs ............24 Appendix: .
- Page 4 Safety Notes 1. Please carefully read this document before 16. All GONSIN products shall be maintained installing and using the equipment. against the warranty card based on system category, except for product issues resulting 2. Please keep this document for future reference.
- Page 5 Remove the batteries and make sure they are fully charged every three months. Notes: GONSIN reserves the right to change this document without prior notice. To obtain more documentary materials, contact the local after-sale service center. GONSIN welcome your feedback.
-
Page 6: Chapter 1 Introduction
Chapter 1 Introduction GONSIN DCS congress system boasts superior performance, and it is applicable to conferences of different sizes. The congress terminal is easy to operate: press the speaking key to speak and rotate the volume knob in two directions (“+” and “-”) to adjust the volume of the built-in loudspeaker; system maintenance does not need much skill as well: technicians can operate the terminal after a short period of training. -
Page 7: Chapter 2 Congress Server
DCS-3021 Congress System This document is applicable to the following product models: Congress server GONSIN30000 Wireless AP WAP-30 Pluggable Gooseneck Microphone Stem MIC-310*￠14. 5-Y 310mm Pluggable Microphone Stem (Black) MIC-410*￠14.5-Y 410mm Pluggable Microphone Stem (Black) MIC-510*￠14. 5-Y 510mm Pluggable Microphone Stem (Black) MIC-310*￠14.5-Y 310mm Pluggable Microphone Stem (Silver) -
Page 8: Overview
Chapter 2 Congress Server 2.1 Overview The DCS congress server GONSIN30000 is the core of a congress system. It can be connected to WAP-30 or WAP-30I (for increasing the number of listening units and simultaneous interpretation units) as well as HD matrix, mixer, power amplifier, and PC over corresponding interface. -
Page 9: Installation
DCS-3021 Congress System Front side Back side: 1. Power switch (POWER); 8. RS-485 interface (RS-485 TO CAMERA). This interface has two pairs of connection terminals Note: The server takes a period of time to start up. and it is used for connecting to cameras that Before the server is fully started up, do not operate support SONY\PELCO-P. -
Page 10: Connection
2.4 Connection 2.4.1 Connection with Congress Terminal To connect the congress server with a wireless terminal, use an 8PS-03/05/10/20/40 extension cable to connect the 8P interface (female connector) of the congress server to a WAP-30 AP, with one male connector of the cable connected to congress server ，and the other female connector connects the male connector of 8P2-01 male-male connector cable, the other male connector of 8P2-01 connects to the female connector of WAP-30 AP, as shown in the following figure: GONSIN30000... -
Page 11: Connection With Mixer Or Amplifier
DCS-3021 Congress System 2.4.3 Connection with Mixer or Amplifier The audio output interface of the server is used to connect to a mixer or an amplifier for loud speaking. Use an audio cable to connect the “LINE OUT” RCA interface of the server with corresponding interface of a mixer or an amplifier. -
Page 12: Connection With The Dome Controller
Use 8I+8O HD matrix with the SDIOUTPUT，which is BNC connector. Connect the matrix to a display device (such as monitor or converter) using an HD video cable. Refer to the following figure: When connecting the congress server to a SONY EVI-D70/D70 camera, set the COM mode of the camera to RS- 422 and baud rate to 9600bps;... - Page 13 DCS-3021 Congress System (3) Speaking mode setting: on the setting interface, press arrow keys to select the value after Mode and press ▲ or ▼ to change a speaking mode: AUTO or FIFO. 4 HostID: enter the "HostID" interface to set the host ID (4) System setting: on the setting interface, press of the system.
-
Page 14: Chapter 3 Compositions Of The Wireless Conference System
Chapter 3 Compositions of the Wireless Conference System 3.1 Functions and Indicators of the Wireless Congress Terminal 3.1.1 Overview The congress terminal is essential for a conference participant and it connects with a congress server via the wireless AP. Functions available to participants vary with the type of a conference unit, including listening, speaking, and requesting to speak. -
Page 15: Functions And Indicators Of Wireless Ap
DCS-3021 Congress System 3.2 Functions and Indicators of Wireless AP The wireless AP can transmit signal and is the transit device between the GONSIN30000 server and DSC- 3021congress terminals. The device utilizes the advanced selecting-hopping technology. The wireless AP has super- strong emissivity and anti-interference capacity. -
Page 16: Wap-30
3.2.3 WAP-30 3.2.3.1 WAP-30 Wireless AP Installation Wireless transmission is at all directions and cannot be affected by visible rays. So this wireless AP could be used outdoors. The longest connection distance between the wireless access point and the server can reach 30m. The best way is to wall hung 2.5m above ground. -
Page 17: Indicators
DCS-3021 Congress System 3.3.2 Indicators 1、Battery grid 2、LED indicator (red indicates "being charging"; green indicates "charging completed") 3、Power interface(AC 110-220v 50Hz) 4、 Power switch(power) 3.4 Connection of Congress Terminal To connect the congress server with wireless terminals, use an 8PS-03/05/10/20/40 extension cable to connect the... -
Page 18: Chapter 4 Wireless Network Design
Chapter 4 Wireless Network Design 4.1 Introduction GONSIN30000 system is composed of three parts: GONSIN30000 server, WAP-30 wireless AP, and DCS-3021 congress terminal. This chapter describes how to design a wireless network. 4.2 Control Rules Control rule 1: control capability GONSIN30000 server can control up to 500 devices within a wireless network. -
Page 19: Installation Rules
WAP-30 and DCS-3021. 4.4.2 Installation Distance The communication distance between WAP-30 and DCS-3021 should be as close as possible and within 30m. 4.4.3 Installation Environment Do not set any metal or electronic product that will produce radio wave within 2m range of the WAP-30. - Page 20 4.4.4 Multi-system DCS3021 working in the same building (Several conference system) Wireless DCS3021 have related restrictions if multi-system working in the same building. The indoor environment is complicated due to the wall material, thickness, e.g wood wall, cement wall, glass wall, metal wall will affect audio transmission in different way.
- Page 21 If the wifi environment is high interference, the software will show many red columns, which means, wifi management is necessary, at least reserve one clean channel for DCS-3021 working; in this case, manual setting channel 1-3 channel working is necessary.
-
Page 22: Chapter 5 Accessories
Chapter 5 Accessories 5.1.1 Wireless AP Cable 8P2-1.5 Item Description Color Black Type Connector Male connector x 2 Length 1.5m 5.1.2 Extension Cable 8PS-03\05\10\15\20\40 Item Description Color Black Type Connector Male connector x 1, female connector x 1 Length 5 types, namely 3m, 5m, 10m,15m, 5.1.3 UTP-Five Category Cable (optional) Item Description... -
Page 23: Chapter 6 Technical Indicators
DCS-3021 Congress System Chapter 6 Technical Indicators 6.1 Congress Server GONSIN30000 Product Name GONSIN30000 Congress Server Parameter Item Maximum processing capacity 500 (sets) Communication distance Audio frequency response 30Hz-16KHz Rated power Harmonic distortion (THD) < 0.5% ≥7 5dB (signal to noise ratio based on A weight) LINE... -
Page 24: Congress Terminal 3021
6.2 Congress Terminal 3021 DCS-3021C-W wireless chairman terminal with basic Product Name discussion DCS-3021D-W wireless delegate terminal with basic discussion Item Parameter 2.4GHz frequency hopping COM mode 30Hz-16KHz Audio frequency response ≥7 5dB Signal to noise ratio Sensitivity -46dB±1dB Operating voltage 3.7V Battery capacity 2600mAH lithium-ion battery... -
Page 25: Charging Case Chg-16
DCS-3021 Congress System 6.3 Charging Case CHG-16 Charging case Product Name Item Parameter Power source AC100~240V, 50~60Hz Highest charging voltage 4.2V Power 106W 3.5h Charging duration Weight 6.7 kg (net weight) / 7.4 kg (fully loaded) Dimensions 490mm×320mm×67.5mm Operating temperature 0~45°C... -
Page 26: Chapter 7 Environment And Maintenance
7.2.2 System Operation Requirements GONSIN conference management software must be supported by a PC in order to run. Generally, the system operator is located in an independent room which should reach the standards of an interpreter booth. The room should be configured with simultaneous interpretation devices (microphones) to connect to a PA system so that the operator can remind participants of related operation, for example, voting starts or registration starts. - Page 27 DCS-3021 Congress System Chapter 8 FAQs 1. The congress server does not respond after it is started up and corresponding indicator is on. A: The server is a PC and it should perform a self-check before activating the entire system. The server takes more than 1 minute to start up.
- Page 28 ¤ GONSIN makes every effort to ensure accuracy and conciseness of the contents in this document. For any inaccuracy due to print error, please contact us, and we will correct it in a timely manner. ¤...
- Page 29 DCS-3021 Congress System...
- Page 30 GONSIN Conference Equipment Co., Ltd.
