Important Notice; Product Information; In The Box; Additional Accessories Needed And Not Included - MTX RNGRPOD65 Owner's Manual

IMPORTANT NOTICE

If you have any questions regarding wire routing in a vehicle, please contact MTX Technical Support
at 1-800-225-5689.When connecting power and ground wires ensure that the red power wire is fused
at the point where it is connected to the vehicle's battery. Failure to do so can result in damage to the
vehicle if a short circuit develops between the vehicle connection point and the product.

PRODUCT INFORMATION

Model #
Serial #
Dealer's Name
Date of Purchase

IN THE BOX

• Dash Speakers (Left and Right Enclosures, Speakers, Grilles)
• (4) #10x3/4" Self-Tapping Stainless Steel Screws
• (8) #8x3/4" Torx Pan Head Screws (Grille)
• (2) 0.156 Female Bullet Connectors (22-18AWG)
• (2) 0.156 Male Bullet Connectors (22-18AWG)

ADDITIONAL ACCESSORIES NEEDED AND NOT INCLUDED

• 14-16 AWG Speaker Wire for Connection to Amplifier

INSTALLATION TOOLS

The following is a list of suggested tools needed for installation:
• Torx - T15, T40
• 8mm Nut Driver or Socket
• Phillips Screwdriver

INTRODUCTION

Thank you for purchasing the MTX Audio 6" 2-way coaxial weatherproof dash speakers designed for
the Polaris RANGER
®
Polaris RANGER
® ®

FITS THE FOLLOWING VEHICLES

• RANGER 570 Full-Size (2014 and up)
®
• RANGER XP 900 (2014 and up)
®
• RANGER XP 1000 EPS (2014-2017)
®
• RANGER Diesel (2014 and up)
®
• RANGER CREW
• RANGER CREW
• RANGER CREW
Will not fit 2018 Northstar Fullsize, Northstar Crew, or High Lifter Edition.

FEATURES

• All Weather Construction with UV Inhibitor
• Custom Fit for RANGER
• No Cutting or Drilling Required

SPECIFICATIONS

• RMS Power Handling: 65-Watts
• Peak Power Handling: 130-Watts
• Sensitivity (2.83V/1m): 95dB
2
. These easy to install dash speakers are the perfect OEM fit solution for your
®
. Congratulations and enjoy the ultimate audio experience with MTX!
570-4 / 570-6 (2014 and up)
®
XP 900 / XP1000 (2014 and up)
®
Diesel (2014 and up)
®
Dashboard
®
• Sensitivity (1W/1m): 90.7dB
• Frequency Response: 85Hz - 22kHz
• Impedance: 4Ω
M T X . C O M
