MTX AAL10 Owner's Manual

AAL Specifications
Model AAL8
System Type 8" 2-Way 10" 3-Way
Woofer 8" Fiber 10" Fiber
Foam Surround Foam Surround
1"Voice Coil 1-1/2"Voice Coil
Midrange
N/A 5" Mid-bass
Tweeter 2"x6" Horn- 2"x6" Horn-
Loaded Quartz Loaded Quartz
Freq. Response 75Hz-22kHz 55Hz-22kHz
Sensitivity 91dB
Nominal Impedance 8 Ohm
Power Handling 50Watts RMS/ 75Watts RMS/
100Watts Total 150Watts Total
Height 17-3/4"
Width 10-1/2"
Depth 8-7/8"
MTX Warranty Statement
MTX loudspeakers are guaranteed against defects in parts and workmanship for a period of ten (10)
years from the date of purchase by the original end user. Speakers found defective during that period
will be repaired by MTX without charge for parts.
This warranty is void if it is determined that unauthorized parties have attempted repairs or alterations
of any nature. This warranty does not extend to cabinets or to grilles. Before assuming that a defect is
present in the speakers, be certain that all associated equipment is operating properly.
Your MTX ten year warranty is factory direct. If a defect is present, you are responsible for providing
transportation to the factory. Your MTX dealer can recommend the safest method of transportation.
Proof of purchase is required when requesting service, so please retain your sales slip. Specifications
subject to change without notice.
All correspondence should be directed to MTX, 4545 E. Baseline Rd., Phoenix, AZ 85040, attention:
Warranty Department, or call (602)438-4545.
© MTX 1999
AAL10 AAL12 AAL15
12" 3-Way 15" 3-Way
12" Fiber 15" Fiber
Foam Surround Foam Surround
1-1/2"Voice Coil 2" Voice Coil
5" Mid-bass 5" Mid-bass
2"x6" Horn- 2"x6" Horn-
Loaded Quartz Loaded Quartz
50Hz-22kHz 40Hz-22kHz
92dB 92dB 92dB
8 Ohm 8 Ohm 8 Ohm
100Watts RMS/ 125Watts RMS/
200Watts Total 250Watts Total
23-1/4" 26-1/4" 28-1/4"
14-1/4" 14-3/4" 17-3/4"
10-3/8" 11-1/8" 15-3/8"
4545 E. Baseline Rd.
Phoenix, AZ 85044
(602)438-4545
AAL212
12" 3-Way
Dual 12" Fiber
Foam Surround
2"Voice Coil
5" Mid-bass
2"x6" Horn-
Loaded Quartz
38Hz-22kHz
93dB
8 Ohm
300Watts RMS/
600Watts Total
38-7/8"
15-3/16"
15-5/8"
21A3455
AAL SERIES
OWNER'S GUIDE
