Red Shield
S
H
MART
AL
Wire-Free Home Alarm System with Phone Dialer
Patent Pending
User Guide
www.redshieldsecurity.com
© 2014 Red Shield Security Limited. All rights reserved. Red Shield logo is the trademark owned by Red Shield Security Limited.
Model # WS-98X-01
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries.
Android and Google Play are trademarks of Google Inc.
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for RED SHIELD SMART HALO
Summary of Contents for RED SHIELD SMART HALO
-
Page 1: User Guide
User Guide www.redshieldsecurity.com © 2014 Red Shield Security Limited. All rights reserved. Red Shield logo is the trademark owned by Red Shield Security Limited. Model # WS-98X-01 Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. -
Page 2: Table Of Contents
2.3 Understanding the battery and AC adapter icon Section 3 – Using the SMART HALO Home Protection System 3.1 Programming your 4-digit PIN 3.1.1 Use Smart Halo App to set up or set up with the panel keypad 3.2 Operating different modes 3.2.1 STANDBY mode ... - Page 3 4.4 Zone Code settings Section 5 - Troubleshooting 5.1 FAQ 5.2 Troubleshooting Section 6 – General Information 6.1 Product information 6.2 Specifications 6.2.1 Smart Halo Panel 6.2.2 Key Fob Remote Control 6.2.3 Door/Window Sensor 6.2.4 Motion Sensor 6.3 Maintenance 6.4 Batteries...
-
Page 4: Section 1 - Getting Started
The system is controlled by a Smart Halo Panel, which gathers information from wireless sensors placed inside and at the entry points of your home or office. If the Smart Halo Panel detects a security breach, indicator lights will flash and the siren(s) will sound. Details of how to correctly install and operate the system are contained within this User Guide. - Page 5 1.4 Introduction Front view LCD screen Mode buttons Number buttons Microphone Programming buttons Key Pad Icon Brief descriptions PIN setting Add additional keychain remote or additional keypad control Dialing cycle or add recipient numbers Exit delay timer setting Remove additional keychain remote or keypad control Inquiry recipient number Entry delay timer setting Querying the ID number of a remote control or keypad control...
-
Page 6: Introduction To The Smart Halo Panel Sound Alert And Backlight
Siren LINE PHONE 4 X House code 9V Battery connector 1.5 Introduction to the Smart Halo Panel sound alert and backlight Operating Mode Situation Sound alert and backlight indication Zone triggered • Alarm duration: Adjustable between 1 – 6 minutes (siren). -
Page 7: Section 2 - Installing The Smart Halo Home Protection System
WARNING: The Red Shield Smart Halo Panel has a built-in tamper-proof switch to prevent the system being disabled by an intruder. When fixing the Smart Halo Panel to a wall, first ensure that it is in Standby mode to avoid the alarm sounding. - Page 8 • One beep will sound and the backlight will blink within 1 second (White) • The Smart Halo Panel will display the below image: • The Smart Halo Panel will enter “STANDBY” mode after the automatic self-checking is complete. Then will appear on the LCD screen.
-
Page 9: Understanding The Battery And Ac Adaptor Icon
Low - AC Adaptor icon • When the AC adaptor to the Smart Halo Panel is connected to a wall socket, the AC symbol will appear. • The backlight will be ‘ON’ for 10 seconds while the AC adapter connects to the power supply. -
Page 10: Use Smart Halo App To Set Up Or Set Up With The Panel Keypad
3.1.1 Use Smart Halo App to set up or set up with the panel keypad Smart Halo Set-up Guide ℠ ™ Download “Smart Halo” app on App Store or Google Play Download and Install ‘Smart Halo’ App on your smartphone or tablet... -
Page 11: Operating Different Modes
A. Adjusting Exit Delay The default setting of the Smart Halo Panel allows the user 20 seconds to exit the property before the alarm is ARMED. However, this Exit Delay can be adjusted to between 10 and 60 seconds as follows,make sure you are in standby mode before the setting. -
Page 12: C.adjusting The Alarm Duration
A. Entering ALERT mode • On the Key Fob Remote: Press to activate. • On the Smart Halo Panel: First make sure the Smart Halo Panel is in STANDBY mode, and then enter into ALERT mode by taking the following steps:... -
Page 13: Exiting The Alert Mode
A. Entering the HOME mode • On the Key Fob Remote Control: Press to activate. • On the Smart Halo Panel: First make sure the Smart Halo Panel is in STANDBY mode, and then enter HOME mode by taking the following steps: Keys... -
Page 14: B.exiting The Home Mode
A. Arming the system On the Key Fob Remote Control: Press to ARM the system. On the Smart Halo Panel: First make sure the Smart Halo Panel is in STANDBY mode, and then ARM the system by taking the following steps: Keys... -
Page 15: B.disarming The System
3.3 Introduction of Key Fob Remote Control A. Introduction The Red Shield SMART HALO Home Protection System Remote Control allows you to operate the systems Smart Panel remotely, from inside or outside the property. Using the control the system can be armed or disarmed and the siren can be activated instantly if required (using the Panic function). -
Page 16: Enrolling The Remote Control Onto The Smart Halo Panel
ALERT – Pressing the ALERT button on the remote will put the system into Alert mode and a chime will sound if any of the sensors are triggered. The Green light on the Smart Halo Panel LED display will flash and indicate the triggered zone. -
Page 17: Querying The Id Number Of A Remote Control
The Auto-Dialler is designed to allow a pre-recorded message to be transmitted to up to 8 pre-programmed telephone lines when triggered. The device allows limited two way communication to help those in the household to communicate with the alerted individuals. This feature is activated when the Red Shield alarm system is activated. 3.4.2 Telephone number + Dialing cycle Program mode allows you to change recipient contact numbers (up to 8) as well as change the number of dialing cycles (attempts to call each recipient). -
Page 18: Record + Playback Mode
3.4.7 Muting the Audible Countdown When the Smart Halo Panel is ARMED the audible countdown (beeper) can be silenced by pressing the button, during the countdown. To reactivate the audible countdown (beeper) simply press the... -
Page 19: Transmitting An Emergency (Panic) Alarm
3.5.2 Using the Panic alarm without activating the siren If you are forced to disarm the system, enter the Duress Password to stop the siren from sounding. The Smart Halo Panel will then silently transmit an alarm signal to the optional response devices (Auto Dialer & Outdoor Bell Box) to request emergency assistance. -
Page 20: Installing The Door/Window Sensor
B. Installing the Door/Window Sensor • Mount the transmitter on a fixed surface such as a door or a window frame. • Mount the magnet on a movable surface such as a door or a window. • Ensure the >/< marks on the sides of the transmitter and magnet match up as shown in the diagram. -
Page 21: Walk Test
4.3 House Security Code settings In most cases the factory settings of the House Security Code will NOT need to be changed. However, if the Smart Halo Panel and Sensors activate intermittently or do not work at all, this may be due to interference with other systems, which can be avoided by changing the House Security Code. -
Page 22: Section 5 - Troubleshooting
5.1 FAQs Q.1: What is the best way to set up my system? Where should I put my Smart Halo Panel and the sensors? A.1: We recommend that you take some time in advance to think about the placement of the Smart Halo Panel and Sensors. -
Page 23: Troubleshooting
Smart Halo Panel power saving: In order to save battery power, the blue light surrounding Smart Halo Panel will not turn on if a battery is used. The blue light will only be turn on if the AC adaptor is connected to Smart Halo Panel. -
Page 24: Door/Window Sensor
12V alkaline battery x 1pc RF working transmission frequency: 433.92MHz +/-0.5MHz House Code: 4 Jumpers Wireless range to Smart Halo Panel: <65 meters (open area) 6.2.3 Door/Window Sensor Power source: AAA alkaline battery 1.5V x 2pcs each RF working transmission frequency: 433.92MHz +/-0.5MHz... - Page 25 Wire-Free Home Alarm System with Phone Dialer Smart Halo Home Alarm System guarantees peace of mind. Compatible with a wide range of sensors and accessories from Red Shield, the system can work under various conditions protecting your home anytime. More accessories available on: www.redshieldsecurity.com...
