Intelligent Cube Hopper MKII

Congratulations on your purchase of this INTELIGENT CUBE HOPPER MKII

and thank you for having confidence in our SUZOHAPP quality products

1. Standard hopper for different applications

The CUBE HOPPER is a single coin payout system made universal by using the relevant payout disc and

coin insert plate (see Reference Chart).

It can be used with all round coins with a diameter between 15.40 and 31.00mm and a thickness ranging

from 1.30 to 3.20mm.

Features

1.1.

The hopper is square and easy to mount by means of a standard mounting-bracket (included).

By using a unique "sun and planet" gearbox system this hopper offers the possibility to contain and count

up to 1,000 coins of €0.50 (if fitted with two cup-extensions).

The hopper is protected by an auto-reverse anti-jam system and has an indirect optical readout.

A low level sensing detection is integrated into the coin cup and can be connected to pin 1 and 2 of the

connector.

When using the correct pin on the connector, the hopper operates on a low safe voltage

(12VDC or 24VDC).

PLEASE NOTE:

This unit was not designed to be used solely as a coin counter. Before starting a payout, there should

already be coins present in the coin cup. These coins should be at rest before payout occurs. The motor

should only be active while a payout is in progress.

Disassembly

1.2.

How to remove the disc

Slide the yellow button on the back to "down" position.

Remove the coin cup by sliding it upwards and lift the cup from the platform.

You are now able to remove the disc from the platform.

How to remove the coin insert plate

Remove the cup and disc from the platform as described above.

Remove the outlet bridge by pulling it up firmly.

Gently lift up the coin insert plate using a small screwdriver.

How to re-configure the Cube Hopper

Remove the coin cup.

Remove the disc and/or coin insert plate (if necessary) and replace them with the ones necessary to

achieve the desired configuration.

Before placing the new disc onto the platform:

I) Please check that the correct coin insert plate is mounted on the platform under the bridge.

(See Reference Chart)

II) Don't forget to put the black Teflon bearing in the centre of the platform. Make sure that the

metal ring in the disc is present as well.

Bring the coin cup onto the platform and slide the yellow button to the up position to lock it in place.

NOTE: Please look up the correct configuration for your hopper in the Reference Chart.
