Intelligent Cube Hopper MKII

8. Optional add-ons

8.1. Cup extension (Part No. 10-0200)

A 65mm high extension together with standard coin-cup increases the
capacity of the cup from 300 to 500 coins of €2.00 (25.75mm in
diameter, 2.2mm thick). It can be used with all coins with diameters up
to 31mm.
A second extension is possible for coins with a maximum diameter of
25.75mm. This increases the capacity to 700 coins of €2.00.
Hopper dimensions - with one extension:
D: 122mm W: 122mm
Hopper dimensions - with two extensions:
D: 122mm W: 122mm

8.2. Cube Hopper spillage cover (Part No. 10-0005)

Designed to prevent coin spillage.
Nominal Operating Voltage
Minimal Operating Voltage
Storage temperature
Operating temperature
Humidity
Motor Duty Cycle
Payout speed
Payout position
Max. current not loaded
Max. current loaded
Max. current
Machine Connector
Payout signal
Coin Diameter size
Coin Thickness size
Min. time between coins
Min. time obstructs optics
MCBF
Maintainable life
Maintainable disk
H: 218mm
H: 284mm
TECHNICAL SPECIFICATIONS
Page 16
Weight
860 grams
940 grams
12VDC ±10% or 24VDC -25% +10%
10.8VDC by 12V or 18V DC by 24V
- 20ºC to + 70ºC.
- 0ºC to + 50ºC.
Min. 20% - Max. 75%
2:1
6 to 7 coins per second
4 sides
400mA
850mA
2A (when jamming)
9-way connector, Part No. 22-01-2095
+ Pins, Part No. 08-50-0032
Open collector-active low 25mA-35V
15.40mm – 31.00mm
1.3mm - 3.2mm
100ms
30ms
500.000
>3 millions
750.000 – 1.000.000
Rev 2.0
