Baxi Luna Duo-Tec MP Plus 1.35 Instructions Manual For Users And Installers

Condensing gas wall-hung boilers
Hide thumbs
Table of Contents

Advertisement

Quick Links

A
MP+ 1.35 – 1.50 – 1.60 – 1.70
it
CALDAIA MURALE A GAS A CONDENSAZIONE
Manuale per l'uso destinato all'utente e all'installatore
en
CONDENSING GAS WALL-HUNG BOILERS
Instructions manual for users and installers
de (AT)
KONDENSATIONS-WANDGASHEIZKESSEL
Gebrauchsanleitung für den Benutzer und Installateur
es
CALDERA MURAL DE GAS A CONDENSACIÓN
Manual de uso destinado al usuario y al instalador

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Luna Duo-Tec MP Plus 1.35 and is the answer not in the manual?

Questions and answers

Related Manuals for Baxi Luna Duo-Tec MP Plus 1.35

Summary of Contents for Baxi Luna Duo-Tec MP Plus 1.35

  • Page 1 MP+ 1.35 – 1.50 – 1.60 – 1.70 CALDAIA MURALE A GAS A CONDENSAZIONE Manuale per l’uso destinato all’utente e all’installatore CONDENSING GAS WALL-HUNG BOILERS Instructions manual for users and installers de (AT) KONDENSATIONS-WANDGASHEIZKESSEL Gebrauchsanleitung für den Benutzer und Installateur CALDERA MURAL DE GAS A CONDENSACIÓN Manual de uso destinado al usuario y al instalador...

  • Page 2: Table Of Contents

    7221369.01 (1-03/15Dear Customer, Our company is confident our new product will meet all your requirements. Buying one of our products guarantees all your expectations: good performance combined with simple and rational use. Please do not put this booklet away without reading it first: it contains useful information for the correct and efficient use of your product.

  • Page 3: Description Of Symbols

    CSQ-certified quality management (ISO 9001), environmental (ISO 14001) and health and safety (OHSAS 18001) systems. This means that BAXI S.p.A. includes among its objectives the safeguarding of the environment, the reliability and quality of its products, and the health and safety of its employees.

  • Page 4: General Precautions

    GENERAL PRECAUTIONS This boiler has been designed to heat water to a temperature lower than boiling point at atmospheric pressure. It must be connected to a central heating system and to a domestic hot water supply system according to its performance and power output. Before having the boiler installed by a qualified service engineer, make sure the following operations are performed: •...

  • Page 5: Commissioning The Boiler

    1. COMMISSIONING THE BOILER To light the boiler correctly, proceed as follows: • Check that the system pressure is correct (section 6); • Power the boiler; • Open the gas tap (yellow, positioned under the boiler); • Select the required heating mode (section 1.2). During initial ignition, the burner may not ignite (causing the boiler to shut down) until any air in the gas pipes is vented.

  • Page 6: Prolonged Shutdown. Anti-Freeze Protection

    2. PROLONGED SHUTDOWN. ANTI-FREEZE PROTECTION Do not drain the whole system as filling up with water again could cause unnecessary and harmful scale to build up inside the boiler and the heating elements. If the boiler is not used during winter and is therefore exposed to the danger of frost, add some specific anti-freeze to the water in the system (e.g.: propylene glycol coupled with corrosion and scale inhibitors).

  • Page 7: Boiler Information Menu

    5. BOILER INFORMATION MENU Press to display the information indicated in the following table. Press to exit. Description Description SW Diagnostic Code Ion current Heating flow temperature Burner working hours Outdoor temperature (if the outdoor sensor is fitted) Zone 1 heating mode External storage tank temperature (fitted models) Zone 2 heating mode DHW temperature (fitted models)

  • Page 8: Instructions Prior To Installation

    Lastly, vent any radiators in the system. BAXI declines all liability for damage deriving from the presence of air bubbles in the primary exchanger due to the incorrect or imprecise observance of the above.

  • Page 9: Installing The Flue

    10. INSTALLING THE FLUE The boiler is easy and flexible to install thanks to the extensive range of available accessories, as described below. The boiler has been designed for connection to a vertical or horizontal coaxial flue-air duct. The boiler can also be used with separate ducts using the accessory splitting kit.

  • Page 10: Cascade Ducts

    10.3 CASCADE DUCTS This type of duct evacuates the products of combustion of more than one boiler in a cascade connection through a shared fumes collector. The collector may only be used to connect the boilers to the flue duct. Available diameters are: Ø125 mm - Ø160 mm and Ø200 mm.

  • Page 11: Connecting The Room Thermostat

    TERMINAL BLOCK M3 Terminals 1 - 3: not used. Terminal 4 - 5: storage boiler pump connection. Terminal 6 - 7: system heating pump connection (external downline from hydraulic separator). If the appliance is connected to an underfloor system, install a limit thermostat to prevent the latter from overheating. Use the relative cable grommets at the bottom of the boiler to thread the cables through to the terminal blocks.

  • Page 12: Setting Parameters Using The Remote Control

    Use the Remote Control to set the programmable timer for heating and DHW. See the instructions supplied with the accessory. SETTING PARAMETERS USING THE REMOTE CONTROL SYMBOLS FOR REMOTE CONTROL Turn knob B Display shows Press knob B Press button A and knob B together Press button A or C Press buttons A and C together KEY TO FIGURE MENU...
  • Page 13 TEMPERATURE ADJUSTMENT ON LOW TEMPERATURE HEATING SYSTEM For a low temperature system (such as underfloor heating), reduce the maximum CH temperature setpoint on the boiler by setting parameter 741 (point B) to a value not greater than 45°C. 11.2.2 EXTERNAL SENSOR To connect this accessory, see figure to side (terminals 4-5) and the instructions supplied with the sensor.

  • Page 14: Initial Ignition - Special Functions

    12. INITIAL IGNITION - SPECIAL FUNCTIONS When the boiler is powered up, the code “311” appears on the display and the boiler is ready for “initial ignition”. Follow the procedure “GAS EXTRACTION FUNCTION” as described in the section below and enable programme 312. After this operation, the boiler is ready to ignite the burner.

  • Page 15: Parameters Setting

    14. PARAMETERS SETTING To programme the parameters of the boiler electronic board, proceed as follows: • Press together and hold them down for 6 seconds until programme row “P02” appears on the display alternated with the set value (°C); • Press and hold down for 6 seconds until "On"...
  • Page 16 CONFIGURATION 5700 Not used (Do NOT change this parameter) 5710 Zone 1 heating circuit (1=enabled) 5715 Zone 2 heating circuit (1=enabled) 5730 DHW sensor (1=Tank sensor, 2=Thermostat, 3=instantaneous sensor) 5890 Not used (Do NOT change this parameter) 5931 *BX2 sensor input (first auxiliary sensor – section 11) 5932 *BX3 sensor input (second auxiliary sensor –...

  • Page 17: Gas Valve Calibration

    15. GAS VALVE CALIBRATION To calibrate the gas valve, enable the calibration function as described in section 12.2 and carry out the following operations: 1) Calibrating MAXIMUM heat output. Check that the measured on the flue duct, with the boiler operating at maximum heat capacity, matches that indicated in table 2 (allowed tolerance +/- 0.5%).

  • Page 18: Adjustment And Safety Devices

    16. ADJUSTMENT AND SAFETY DEVICES The boiler has been designed in full compliance with European reference standards and in particular is equipped with the following: • Limit thermostat Thanks to a sensor placed on the CH flow line, this thermostat interrupts the flow of gas to the burner if the water in the primary circuit overheats.

  • Page 19: Annual Servicing

    18. ANNUAL SERVICING The service must be performed only by qualified and competent staff in accordance with the Gas safety, Installation and use regulations. In UK this person need to be approved by the Health and Safety Executive. To optimise boiler efficiency, carry out the following at the annual service: •...

  • Page 20: Checking The Burner

    18.3 CHECKING THE BURNER The burner needs no cleaning. • Check the burner surface for damage, replace the burner if necessary. • Check the positioning of the flame detection probe. • Verify that the distance of the ignition electrode is within tolerance as shown in the figure. •...

  • Page 21: Technical Specifications

    20. TECHNICAL SPECIFICATIONS Model: LUNA DUO-TEC MP+ 1.35 1.50 1.60 1.70 Cat. 2H3P Gas used G20 - G31 Rated heat input 34,8 46,3 56,6 66,9 Reduced heat input Rated heat power 80/60°C 33,8 Rated heat power 50/30 °C 36,6 48,6 59,4 70,2 Reduced heat output 80/60 °C...

  • Page 22: Technical Parameters

    21. TECHNICAL PARAMETERS BAXI LUNA DUO-TEC MP+ 1.35 1.50 1.60 1.70 Condensing boiler Low-temperature boiler B1 boiler Cogeneration space heater Combination heater Prated Rated heat output Useful heat output at rated heat output 33.8 45.0 55.0 65.0 and high temperature regime Useful heat output at 30% of rated heat 11.2...

  • Page 23: Product Fiche

    22. PRODUCT FICHE BAXI LUNA DUO-TEC MP+ 1.35 1.50 1.60 1.70 Space heating - Temperature application Medium Medium Medium Medium Water heating - Declared load profile Seasonal space heating energy efficiency class Water heating energy efficiency class (Prated or Psup)
  • Page 24 7221369.01 (1-03/15)
  • Page 25 Ventilatore Collettore miscela aria-gas Air/gas blend manifold Scambiatore primario Primary exchanger Sonda fumi Flue sensor Convogliatore fumi Flue hood Raccordo scarico fumi coassiale Coaxial flue connector Valvola di sfogo aria automatica Automatic air vent Sonda NTC riscaldamento NTC water heating sensor (mandata e ritorno) (flow and return) Termostato di sicurezza (sovratemperature)
  • Page 26 7221369.01 (1-03/15)
  • Page 27 7221369.01 (1-03/15)
  • Page 28 505 - 377 G 3/4" G 1" G 1" 51,5 75,5 Ed.1-02/2015 G 3/4" G 1" G 1" 7221122.01 7221369.01 (1-03/15)
  • Page 29 CR_0774 51,5 75,5 G 3/4" G 1" G 1" 7221369.01 (1-03/15)
  • Page 30 Lmax = 10 m - Ø 80/125 mm Lmax = 9 m - Ø 80/125 mm Lmax = 10 m - Ø 80/125 mm Lmax = 8 m - Ø 80/125 mm Lmax = 9 m - Ø 80/125 mm (L1+L2) max = 60 m - Ø...
  • Page 31 MP+ 1.35-1.50 MP+ 1.60 30kW 35kW 45kW 50kW 55kW 60kW Q (l/h) Q (l/h) MP+ 1.70 65kW 70kW Q (l/h) 7221369.01 (1-03/15)
  • Page 32 AGU 2.550 CR_0349 AVS 75 CR_0349 7221369.01 (1-03/15)
  • Page 33 Tmax = 50 °C CG_2482 7221369.01 (1-03/15)
  • Page 34 MODIFIZIERTE PARAMETER / PARAMETROS MODIFICADOS VALORE / VALUE / N° / Nr / Núm. NOTA / NOTE / ANMERKUNG WERT / VALOR 36061 Bassano del Grappa (VI) - ITALIA Via Trozzetti, 20 Servizio clienti: tel. 0424-517800 – Telefax 0424-38089 www.baxi.it 7221369.01 (1-03/15)
