- Page 1 Installation and Operation Manual Intraplex® VF-25 Four-Port PCM E&M Voice Module VF-25 Voice Frequency Module MA-305C, MA-306C, MA-308C, MA-309C, & MA-310 Module Adapters Version 7.1...
- Page 3 ©2014 GatesAir, Inc. . Proprietary and Confidential. GatesAir considers this document and its contents to be proprietary and confidential. Except for making a reasonable number of copies for your own internal use, you may not reproduce this publication, or any part thereof, in any form, by any method, for any purpose, or in any language other than English without the written consent of GatesAir.
- Page 4 Version Date Revision History Section Pages Editor 3/31/09 Put manual into new format. Updated appendix for new module adapters, dividing appendix into current and discontinued MAs. 11/03/09 Changed “EB Lead” to “SG Lead” in two occurrences.
-
Page 5: Table Of Contents
A.1.5 MA-309C Two-Wire, 50-pin Connector ............ A-11 A.1.6 MA-310 Two-Wire, RJ-45 Connector ............A-16 A.2 Discontinued Module Adapters ............A-22 A.2.1 MA-305B Four-wire, 50-pin Connector ............ A-22 A.2.2 MA-306 Four-Wire, RJ-45 Connector ............A-23 A.2.3 MA-308 Four-Wire, RJ-45 Connector ............A-26 GatesAir, Inc. Intraplex Products... - Page 6 Intraplex VF-25 Voice Module Table of Contents Version 7.1, November 2009 A.2.4 MA-308B Four-Wire, RJ-45 Connector ............ A-29 A.2.5 MA-309 Two-Wire, 50-pin Connector ............A-34 Figures Figure 2-1. VF-25 Voice Module, Block Diagram ................ 2-2 Figure 2-2. E&M Signaling Types ..................... 2-3 Figure 2-3.
- Page 7 Table of Contents Intraplex VF-25 Voice Module Version 7.1, November 2009 Table 2-9. Remote Status Messages (S Codes) ............... 2-13 Table 3.1 Sample VF-25 Response To A CONFIG? Query ............3-2 Table A-1. Module Adapters for VF-25 Module ................A-1 Table A-2.
- Page 8 Intraplex VF-25 Voice Module Table of Contents Version 7.1, November 2009 Table A-45. Selectable Attenuation Control for Nominal Input Levels of -16 dBm & 0 dBm ... A-38 Table A-46. MA-309 Technical Specifications ................A-39 GatesAir, Inc. Intraplex Products...
-
Page 9: Section 1 - Introduction
No header here Section 1 – Introduction This manual describes the setup and installation procedures for the Intraplex VF-25 Voice Frequency Module. Experienced users may refer directly to the Section 2 tables for configuration data. Your Intraplex multiplexer operation manual contains additional information about this system. - Page 11 No header here This page is left blank intentionally. GatesAir, Inc. Intraplex Products...
-
Page 13: Section 2 - Functional Description & Setup
The E-Lead signal goes to the E Lead driver. When active in Type I, III, and V signaling modes, ground equals BUSY; open equals IDLE. In Type II signaling, the E-Lead and SG-Lead are both used. When signaling is active, the E-Lead and SG-Lead are tied together through the E-Lead relay. GatesAir, Inc. Intraplex Products... -
Page 14: Figure 2-1. Vf-25 Voice Module, Block Diagram
Intraplex VF-25 Voice Module 2 – Functional Description & Setup Version 7.1, November 2009 TDM Bus Serial Control Bus Drivers & Receivers FPGA TERM Local SELECT Loopback TIME SLOT SET SCB SIG OFF ADDRESS REMOTE AUX (LOCAL SERVICE LOOPBACK) CODEC... -
Page 15: E&M Signaling
2 – Functional Description & Setup Intraplex VF-25 Voice Module Version 7.1, November 2009 The control output passes to an amplifier stage and finally through the output transformer to the output connectors on the module adapter. With 0 dBm at the transmitter input, the output level is 0 dBm referenced to 600 ohms. -
Page 16: Drop/Insert Operation
Intraplex VF-25 Voice Module 2 – Functional Description & Setup Version 7.1, November 2009 Figure 2-1 shows these loopback locations. Section 4 - “Testing and Troubleshooting” gives procedures for using these loopbacks. 2.6 Drop/Insert Operation A drop/insert multiplexer operates at a central point on a three (or more) point system. In Figure 2-3, Site 2 has a drop/insert multiplexer with a DI/A port connected to the transmission line to Site 1 and a DI/B port connected to the transmission line to Site 3. -
Page 17: Figure 2-5. Vf-25 Voice Module, Top View
2 – Functional Description & Setup Intraplex VF-25 Voice Module Version 7.1, November 2009 IMPORTANT!!! All modules must be inserted so that the white eject tab is at the bottom in a full size (5 1/4" high) shelf, and at the right in a compact (1 3/4"... -
Page 18: Table 2-1. Configuration Switches
Intraplex VF-25 Voice Module 2 – Functional Description & Setup Version 7.1, November 2009 Table 2-1. Configuration Switches Switch#/ Position Label Setting Description SW1/1 - 5 TIME SLOT Table 2-4 Select the desired starting time slot. SELECT SW1/6 NORMAL: Local loopback off DOWN Activate local loopback. -
Page 19: Remote Control Interface
2 – Functional Description & Setup Intraplex VF-25 Voice Module Version 7.1, November 2009 Table 2-4. Starting Time Slot Selection – SW1, Positions 1-5 Positions** Positions** Time Time Slot* Slot* 1 2 3 4 5 1 2 3 4 5... -
Page 20: P Codes
Intraplex VF-25 Voice Module 2 – Functional Description & Setup Version 7.1, November 2009 Table 2-5. Card Address Setting – SW3 Positions* Positions* Time Time Slot 1 2 3 4 5 6 Slot 1 2 3 4 5 6 0 0 0 0 0 1... - Page 21 2 – Functional Description & Setup Intraplex VF-25 Voice Module Version 7.1, November 2009 A typical VF-25 response to a query looks like this: CONFIG? * OK CHANNEL CARD 3, TYPE 103 UNDER REMOTE CONTROL SRVC = ON P01 = 195 (B11000011)
-
Page 22: Table 2-6. Remote Configuration Settings (P Codes)
Intraplex VF-25 Voice Module 2 – Functional Description & Setup Version 7.1, November 2009 Table 2-6. Remote Configuration Settings (P Codes) (continued) P Code Digit(s) and Effect Value* Description B00000000 0 – 255 Adjusts the input level for Channel 1 (Section 2.8.1.1 - ... -
Page 23: Figure 2-6. Attenuation Level Controls (P3 - P10)
2 – Functional Description & Setup Intraplex VF-25 Voice Module Version 7.1, November 2009 consecutive time slots are used, depending on the number of active channels. Starting time slots 22, 23, or 24 may be used only when fewer than four channels are active. -
Page 24: S Codes
Intraplex VF-25 Voice Module 2 – Functional Description & Setup Version 7.1, November 2009 Table 2-8. Suggested P Codes to Achieve Desired dB Gain Gain P Code Gain P Code Gain P Code + 6.0 dB 0 dB 124* - 6.0 dB + 5.5 dB... -
Page 25: Table 2-9. Remote Status Messages (S Codes)
2 – Functional Description & Setup Intraplex VF-25 Voice Module Version 7.1, November 2009 Table 2-9. Remote Status Messages (S Codes) Position Value Description B00000000 M-Lead for Channel 1 is idle. ------- M-Lead for Channel 1 is busy. B00000000 M-Lead for Channel 2 is idle. - Page 27 No header here This page is left blank intentionally. 2-14 GatesAir, Inc. Intraplex Products...
-
Page 29: Section 3 - Installation
CONFIG? typical VF-25 response to a query. CONFIG? h. Set service ON by remote control (ISiCL command, with in the SRVC = ON parameter field). You can now change the operating parameters for the module using GatesAir, Inc. Intraplex Products... -
Page 30: Mounting
Intraplex VF-25 Voice Module 3 – Installation Version 7.1, November 2009 ISiCL commands. Your multiplexer operation manual gives details on using the Intraplex Simple Command Language (ISiCL) for remote access and control. 3.3 Mounting Insert the module into the selected slot in the Intraplex multiplexer. -
Page 31: Section 4 - Testing & Troubleshooting
6. If you are performing a remote loopback, deactivate the loopback for this channel and activate the loopback for the next channel to be tested. If you are using a local loopback, leave the loopback up until all channels have been tested. GatesAir, Inc. Intraplex Products... - Page 32 Intraplex VF-25 Voice Module 4 – Testing & Troubleshooting Version 7.1, November 2009 7. Repeat the previous steps for each active channel. 8. Remove the test equipment and deactivate all loopbacks. If there is an apparent malfunction, first check that the configuration is appropriate for the transmission system in use.
-
Page 33: Section 5 - Specifications
Idle = Open Type II: Busy = Contact closure to SG Idle = Open Time slots One to four sequential time slots (one for each active channel). Starting time slot is user-selectable. Loopbacks Local and remote analog loopbacks GatesAir, Inc. Intraplex Products... -
Page 34: Notice Of Fcc Compliance
Intraplex VF-25 Voice Module 5 – Specifications Version 7.1, November 2009 Indicator light Green light indicates Service On Environmental Temperature: 0° - 50°C Operating Humidity: 0% - 90% Non-condensing Power Consumption 2.0 Watts nominal with all four channels active Specifications are subject to change without notice. -
Page 35: Current Module Adapters
Figure A-1 shows how to position the adapter and set the jumpers. Table A-2. MA-305 Pin Assignments Pin Assignment Signal Ch. 1 Ch. 2 Ch. 3 Ch. 4 Input (Ring) Input (Tip) Output (Ring) Output (Tip) E-Lead M-Lead Signal Ground Signal Battery GatesAir, Inc. Intraplex Products... -
Page 36: Ma-305C Four-Wire, 50-Pin Connector
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 For Jumper JMP5: For Jumpers JMP1, 2, 3, and 4 = Type II only = Type I, III, or V = Type I, II, or III... -
Page 37: Figure A-2. Ma-305C Jumper Settings And Face Plate
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-3. MA-305C Pin Assignments Pin Assignment Signal Ch. 1 Ch. 2 Ch. 3 Ch. 4 Input (Ring) Input (Tip) Output (Ring) Output (Tip) -
Page 38: Ma-306C Four-Wire, Rj-45 Connector
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 To utilize the signal battery polarity option, remove the jumpers in applications where the external signaling battery is positive (+) with respect to chassis ground. In cases of positive (+) signaling battery applications, both jumpers must be removed. -
Page 39: Table A-4. Ma-306C Channel 1 Jumper Settings
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-4. MA-306C Channel 1 Jumper Settings Jumper JP2 Jumper JP6 Type II Type V Type I, III, and V Type I, II, and III Table A-5. -
Page 40: Figure A-4. Ma-306C Pin Assignments
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Table A-7. MA-306C Channel 4 Jumper Settings Jumper JP5 Jumper JP9 Type II Type V Type I, III, and V Type I, II, and III A.1.3.2... -
Page 41: Ma-308C Four-Wire, Rj-45 Connector
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 A.1.3.4 Signal Battery Polarity To utilize the signal battery polarity option, remove the jumpers in applications where the external signaling battery is positive (+) with respect to chassis ground. In cases of positive (+) signaling battery applications, both jumpers must be removed. -
Page 42: Figure A-5. Ma-308C Jumpers And Face Plate
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Figure A-5. MA-308C Jumpers and Face Plate The MA-308C module adapter provides modular connectors for each of the four circuits and is two card slots in width. The MA-308C module adapter is designed to meet the needs for interface signal monitoring and additional attenuation. -
Page 43: Figure A-6. Ma-308C Pin Assignments
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-10. MA-308C Alternate Jumper Settings Jumper JP1 Jumpers JP2, JP3, and JP5 Type V only Type I, III, or V A.1.4.2 Circuit Connectors The MA-308C module adapter provides four RJ-45 circuit jacks on the right. -
Page 44: Table A-11. Ma-308C Pin Assignments
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Table A-11. MA-308C Pin Assignments Pairing Description Comments Pin 1 Pair 3 T1 & R1 send signal from CO side (trunking) to user side (signaling) -
Page 45: Ma-309C Two-Wire, 50-Pin Connector
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 2. Once it is seated securely, secure the unit with screws provided. 3. Plug the connector into the adapter. A.1.5 MA-309C Two-Wire, 50-pin Connector The MA-309C 2-wire E&M interface module adapter provides 2-wire to 4-wire conversion for Intraplex... -
Page 46: Figure A-8. Ma-309C Jumper Settings For Signaling Type Selection
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 ● Jumpers 1 and 9 (JMP1 and JMP9) control the type of signaling for channel 1. ● JMP2 and JMP10 determine the type of signaling for channel 2. -
Page 47: Table A-13. Selectable Attenuation Control For Nominal Input Level Of 0Dbm
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-13. Selectable Attenuation Control for Nominal Input Level of 0dBm Jumper / Position Output of MA-309C Channel JMP 5 / Position 1-2 -10dBm attenuation... -
Page 48: Figure A-9. Ma-309C Jumper Settings For Attenuation Control
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 A.1.5.4 Attenuation Control Figure A-9 shows the jumper settings available to control output attenuation. The top of the figure shows Pin A. The default setting is 0dBm in and 0dBm out. Table A-16 shows the attenuation for nominal output level of 0dBm. -
Page 49: Table A-17. Selectable Attenuation Control For Nominal Input Levels Of -16 & 0 Dbm
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 A.1.5.5 Additional MA-309C Input/Output Options In the situation where the VF-25 module and MA-309C module adapter are used for transport of 2- Wire Audio with E&M signaling on the output side of the circuit, there are two possibilities to adjust the output signal level (one on the VF-25 module and one on the module adapter). -
Page 50: Ma-310 Two-Wire, Rj-45 Connector
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 A.1.5.6 Signal Battery Polarity To utilize the signal battery polarity option, remove the jumpers in applications where the external signaling battery is positive (+) with respect to chassis ground. In cases of positive (+) signaling battery applications, both jumpers must be removed. -
Page 51: Figure A-11. Ma-310 Jumper Settings For Signaling Type Selection
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 A.1.6.1 Jumper Settings Figure A-10 shows jumper locations on the MA-310 module adapter. Two sets control signaling and one set controls output levels. The first set of jumpers that control signaling is JMP1, JMP2, JMP3, and JMP4. -
Page 52: Figure A-12. Ma-310 Pin Assignments
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Table A-19. Selectable Attenuation Control for Nominal Input Level of 0dBm Jumper / Position Output of MA-310 Channel JMP 5 / Position 1-2 -10dBm attenuation... -
Page 53: Figure A-13. Ma-310 Jumper Settings For Attenuation Control
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-21. MA-310 Pin Assignments Pairing Description Comments Pin 1 Pair 3 T1 & R1 send signal from CO side (trunking) to user side (signaling) -
Page 54: Table A-22. Selectable Attenuation Control For Nominal Input Level Of 0Dbm
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Table A-22. Selectable Attenuation Control for Nominal Input Level of 0dBm Jumper/Position MA-310 Output Channel JMP 5/Position 1-2 -10dBm attenuation JMP 5/Position 3-2 -3dBm attenuation... -
Page 55: Table A-24. Ma-310 Technical Specifications
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-24. MA-310 Technical Specifications Condition Value Input Impedance 600 Level tracking +3dBm0 to –37dBm0 input < 0.5dB+/- Tx level 0 dBm from 4W to 2W <... -
Page 56: Discontinued Module Adapters
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 A.2 Discontinued Module Adapters A.2.1 MA-305B Four-wire, 50-pin Connector The MA-305B module adapter accepts a 50-pin connector, Amphenol 57-30500 or equivalent (Figure A-14). Table A-25 shows the pin assignments on this connector. Jumpers JMP1 through JMP9 are used to select the signaling type (JMP5 is not used on the MA-305B). -
Page 57: Figure A-15. Ma-306 Jumpers And Face Plate
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 1. At the rear of the chassis, insert the adapter into the same slot position in which the VF-25 module has been installed. 2. Once it is seated securely, secure the unit with screws provided. -
Page 58: Table A-26. Ma-306 Channel 1 Jumper Settings
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Table A-26. MA-306 Channel 1 Jumper Settings Jumper JP2 Jumper JP6 Type II Type V Type I, III, and V Type I, II, and III Table A-27. -
Page 59: Figure A-16. Ma-306 Pin Assignments
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-29. MA-306 Channel 4 Jumper Settings Jumper JP5 Jumper JP9 Type II Type V Type I, III, and V Type I, II, and III A.2.2.2... -
Page 60: Ma-308 Four-Wire, Rj-45 Connector
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 A.2.2.4 Installation To install the MA-306 module adapter, perform these steps: 1. At the rear of the chassis, insert the adapter into the same slot position in which the VF-25 module has been installed. -
Page 61: Table A-31. Ma-308 Alternate Jumper Settings
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 A.2.3.1 Jumper Settings Jumpers JMP1 through JMP5 are used to select the signaling type. Figure A-16 shows how to hold the adapter and set the jumpers. Tables A-31 and A-32 show alternate settings. -
Page 62: Figure A-18. Ma-308 Pin Assignments
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Figure A-18. MA-308 Pin Assignments Table A-33. MA-308 Pin Assignments Pairing Description Comments Pin 1 Pair 3 T1 & R1 send signal from CO side (trunking) to user side (signaling) -
Page 63: Ma-308B Four-Wire, Rj-45 Connector
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-34. MA-308 Switch Settings Channels 1-4 Transmit (T) Receive (R) Gain -23 dB Transmit circuit -23 dB Receive circuit -23 dB Transmit circuit... -
Page 64: Figure A-19. Ma-308B Jumpers And Face Plate
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Figure A-19. MA-308B Jumpers and Face Plate The MA-308B module adapter provides modular connectors for each of the four circuits and is two module slots in width. The MA-308B module adapter is designed to meet the needs for interface signal monitoring and additional attenuation. -
Page 65: Table A-35. Ma-308B Channel 1 Alternate Jumper Settings
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-35. MA-308B Channel 1 Alternate Jumper Settings Jumper JP2 Jumper JP6 Type II Type V Type I, III, and V Type I, II, and III Table A-36. -
Page 66: Figure A-20. Ma-308B Pin Assignments
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Table A-38. MA-308B Channel 5 Alternate Jumper Settings Jumper JP5 Jumper JP9 Type II Type V Type I, III, and V Type I, II, and III A.2.4.2... -
Page 67: Table A-39. Ma-308B Pin Assignments
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-39. MA-308B Pin Assignments Pairing Description Comments Pin 1 Pair 3 T1 & R1 send signal from CO side (trunking) to user side (signaling) -
Page 68: Figure A-21. Ma-309 Jumpers And Face Plate
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 A.2.5 MA-309 Two-Wire, 50-pin Connector The MA-309 2-wire E&M interface module adapter provides 2-wire to 4-wire conversion for Intraplex Products voice frequency channel modules with E&M type signaling. This adapter interfaces four channels with 600termination per channel. -
Page 69: Figure A-22. Ma-309 Jumper Settings For Signaling Type Selection
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 ● JMP2 and JMP10 determine the type of signaling for channel 2. ● JMP3 and 11 control channel 3. ● JMP4 and JMP12 control channel 4. -
Page 70: Table A-41. Selectable Attenuation Control For Nominal Input Level Of 0Dbm
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Table A-41. Selectable Attenuation Control for Nominal Input Level of 0dBm Jumper / Position Output of MA-309 Channel JMP 5 / Position 1-2 -10dBm attenuation... -
Page 71: Figure A-23. Ma-309 Jumper Settings For Attenuation Control
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 A.2.5.4 Attenuation Control Figure A-23 shows the jumper settings available to control output attenuation. Pin A is shown at the top in this table. The default setting is 0dBm in and 0dBm out. Table A-44 shows the attenuation for nominal output level of 0dBm. -
Page 72: Table A-44. Selectable Attenuation Control For Nominal Input Level Of 0Dbm
Intraplex VF-25 Voice Module Appendix A – MAs for VF-25 Voice Module Version 7.1, November 2009 Table A-44. Selectable Attenuation Control for Nominal Input Level of 0dBm Jumper/Position MA-309 Output Channel JMP 5/Position 1-2 -10dBm attenuation JMP 5/Position 3-2 -3dBm attenuation... -
Page 73: Table A-46. Ma-309 Technical Specifications
Appendix A – MAs for VF-25 Voice Module Intraplex VF-25 Voice Module Version 7.1, November 2009 Table A-46. MA-309 Technical Specifications Condition Value Input Impedance 600 Level tracking +3dBm0 to –37dBm0 input < 0.5dB+/- Tx level 0 dBm from 4W to 2W <...
