FDT181C Collective Heat Detector
Product Manual
Overview
Characteristics
Application
The heat detector FDT181C is a collective detector. It is used for fire detection inside a
building.
– Operation modes: A2 (Rate-of-rise and fixed temperature)
– Collective detector, no address setting, polarity free connection
– 360° visible alarm indicator
– Resistant to environment and interference factors such as humidity, corrosive and
vibration, with immunity against electro-magnetic interference.
– Communication with FC18 controller via FDCI183 transponder, each FDCI183 can
connect max. 32 collective detectors.
– Communication with BC80 controller via BDS161 transponder, each BDS161 can
connect max. 10 collective detectors.
Building Technologies
Fire safety and security products
Advertisement
Related Manuals for Siemens FDT181C
Summary of Contents for Siemens FDT181C
- Page 1 FDT181C Collective Heat Detector Product Manual Overview The heat detector FDT181C is a collective detector. It is used for fire detection inside a building. Characteristics – Operation modes: A2 (Rate-of-rise and fixed temperature) – Collective detector, no address setting, polarity free connection –...
- Page 2 Indicator The detector is provided with an internal alarm indicator to show its operating status. Status Indicator Normal Alarm Steady on Installation Easy and time-saving mounting Install the base and finish the wiring during the construction phase. Insert detector into base and turn it clockwisely until positioning pointer on base align with positioning pointer on detector.(see below) Uninstallation: Turn it counterclockwisely and pull the detector out of base.
- Page 3 Color White, RAL 9010 Protection category GB4208-93 IP40 Details for ordering Type Material No. Part No. Designation Weight S54320-F12-A2 FDT181C 101190983 Collective heat detector 0.065Kg S54320-F9-A2 FDB181C 101190980 Collective detector base 0.038Kg Building Technologies A6V10361100_b_en_-- Fire safety and security products...
- Page 4 Beijing Siemens Cerberus Electronics Limited © Data and design subject to change without notice. No.1,Fengzhidonglu, Xibeiwang, HaiDian District, Beijing, 100094, China Tel: +10 6476 8806 Fax: +10 6476 8899 Doc No. A6V10361100_b_en_-- Manual FD18 Edition 07.2012 101190971...
