Upgrading Your Computer
Inserting a SIMM
1.
To insert a SIMM module, hold the module by the ends with the contacts
down and the slotted end toward the back of the computer.
Banks A, B, and C can be Þlled in any order as long as both slots in the bank are Þlled with
SIMMs of the same capacity. It is easiest to start with the last clip in Bank C. Insert the
rightmost SIMM of a pair Þrst.
If you are installing SIMMs in bank A, loosen the rightmost SIMM in the motherboard bank
to get the leftmost bank A SIMM in.
2.
Slide the contacts into the slot at about a 60 degree angle and make sure
the contacts are Þrmly seated in the slot,
3.
Gently pull the top of the module toward the ßoppy drive side of the
computer until you hear the metal clips click into place.
4.
If both clips do not click into place, release any clip that did click, pull the
SIMM module out, re-seat it in the slot, and try again.
5.
When you are Þnished, re-connect the ßoppy disk drive connector, the CD
audio connector (below the ßoppy connector), and the speaker connector
(below the CD audio connector) from the I/O board and move those cords
out of the way and replace the cover.
26
Power 100/120 User Guide
SIMM clip
bank A
front
bank B
bank C
SIMM Module
SIMM clip
For Technical Support, Call 1-800-708-6227
ßoppy
drive
area
